DVD PLAYER
XV-D2000BK
POWER
OPEN/CLOSE
CATV/SAT
TV
DVD
SET
MUTE
TV/VIDEO
1
2
3
4
5
6
7
8
9
CH RETURN
100+
+
10
0
10
+
+
+
+
TV
AUDIO
SLOW
CH
VOLUME
VOLUME
TV
RESUME
ANGLE
SUB TITLIE
DVD
CATV
ON /OFF
UP
LEFT
RIGHT
DOWN
T
RM-SVD2000U REMOTE CONTROL
XV-2000BK/CoverE
All manuals and user guides at all-guides.com
COMPACT COMPONENT SYSTEM
XV-D2000 DVD PLAYER
STANDBY
POWER
RESUME
DOLBY DIGITAL 5.1
LINEAR PCM
96KHz SAMPLING
ON/STANDBY
PHONES
PHONES LEVEL
DOLBY
D I G I T A L
MIN
MAX
INSTRUCTIONS
1
DOLBY DIGITAL DECODER BUILT-IN
PlayBack
Control
For Customer Use:
Enter below the Model No. and Serial
Enter below the Model No. and Serial No.
No. which are located either on the rear,
which are located on the rear, bottom or
bottom or side of the cabinet. Retain this
side of the cabinet. Retain this information
information for future reference.
for future reference.
Model No.
Serial No.
9/24/97, 1:17 PM
ON SCREEN
DVD MENU
ENTER
'
LET0091-001A
[ J ]
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JVC XV-2000BK
Summary of Contents for JVC XV-2000BK
- Page 1 Retain this side of the cabinet. Retain this information information for future reference. for future reference. Model No. Serial No. LET0091-001A [ J ] XV-2000BK/CoverE 9/24/97, 1:17 PM...
- Page 2 CAUTION To reduce the risk of electrical shocks, fire, etc.: 1. Do not remove screws, covers or cabinet. 2. Do not expose this appliance to rain or moisture. XV-2000BK/CoverE 9/24/97, 1:17 PM...
-
Page 3: Table Of Contents
Screen saver function ........... 20 Controlling TV ..............51 Dolby Digital ..............21 Controlling CATV converter or satellite tuner ....52 Controlling a JVC amplifier or receiver ......52 Basic Operations ........22 Playing back ..............22 Selecting Preferences ......53 Selecting an item from a menu ........ -
Page 4: General Information
If water gets inside the player Turn off the power switch and pull the plug from the electrical socket, then call the store where you made your purchase. Using the player in this state may cause a fire or electrical shock. XV-2000BK/1E 9/24/97, 1:09 PM... -
Page 5: Introduction
• The newly developed K2 interface LSI delivers pure sound with no digital distortion. • 1-bit DD converter that handles 20- bit, 96-kHz Fs audio signals and JVC’s original PEM (Pulse Edge Modulation) circuit achieve more than double the resolution of conventional converters. -
Page 6: Controls And Functions
Indicates the current status of the player. LINEAR PCM indicator DVD indicator Lights when linear PCM audio is played back by DVD Lights when a DVD disc is inserted. or CD. It blinks just after a disc is inserted. XV-2000BK/1E 9/24/97, 1:09 PM... - Page 7 Starts playback. Also, used a SELECT button for PBC / / / (Cursor buttons) of video CD. Selects an item in on-screen displays or DVD menus. DVD MENU Displays a DVD menu on the television screen or monitor. XV-2000BK/1E 9/24/97, 1:10 PM...
- Page 8 All manuals and user guides at all-guides.com Introduction 7 Remote control unit POWER OPEN/CLOSE CATV/SAT TV/VIDEO MUTE CH RETURN 100+ AUDIO SLOW VOLUME VOLUME RESUME ANGLE SUB TITLIE CATV ON /OFF LEFT RIGHT DOWN RM-SVD2000U REMOTE CONTROL XV-2000BK/1E 9/24/97, 1:10 PM...
- Page 9 RESUME Stores the location to be resumed later. (See "Resuming Playback" on pages 27, 35 and 43.) AUDIO VOLUME Adjusts the volume of a JVC AV amplifier or receiver. ANGLE (for DVD) Changes camera angles during playback of a DVD...
-
Page 10: Supplied Accessories
Both coaxial and optical connectors are provided. ATTENUATOR switch attenuates the output level when it is set to ON. AV COMPU LINK Connects with another JVC equipment supporting the AV AUDIO OUT (5.1CH) Compulink to facilitate operations. FRONT (RIGHT and LEFT), REAR (RIGHT and (See "AV COMPULINK remote control system"... -
Page 11: Before Using For The First Time
To audio input left To audio input right Audio/video cable (Supplied) To VIDEO OUT Yellow Yellow To video input To 2CH RIGHT To audio input (mono) Audio/video cable (mono) Black (optional) To 2CH LEFT White DVD Player XV-2000BK/1E 9/24/97, 1:11 PM... -
Page 12: Connecting With An Audio Amplifier Or Receiver
REAR CENTER SUBWOOFER RIGHT LEFT RIGHT LEFT RIGHT LEFT NORMAL GAIN PLUS AUDIO OUT VIDEO OUT DIGITAL OUT AV COMPU LINK PCM/DOLBY DIGITAL VIDEO S-VIDEO COAXIAL OPTICAL Audio cable (Supplied) To audio inputs Amplifier or receiver XV-2000BK/1E 9/24/97, 1:11 PM... -
Page 13: Connecting With An Amplifier Equipped With Dolby Digital 5.1-Channel Inputs
PCM/DOLBY DIGITAL VIDEO S-VIDEO COAXIAL OPTICAL FRONT REAR CENTER WOOFER Front speaker Front speaker Audio cable Center speaker (Supplied) FRONT REAR CENTER SUB WOOFER To audio inputs Sub woofer Amplifier or receiver Rear speaker Rear speaker XV-2000BK/1E 9/24/97, 1:11 PM... -
Page 14: Connecting With An Audio Equipment With Digital Input
DVD may generate noise and, in the worse case, damage your speakers. See “Preference via "PREFERENCE" on-screen display” on pages 53. • Set “DOWN MIX” setting in the DVD on-screen display to “L0/R0” or “Lt/ Rt”. (See “Down Mix” on page 33.) XV-2000BK/1E 9/24/97, 1:11 PM... -
Page 15: Connecting With A Dolby Digital Decoder/Amplifier With Built-In Dolby Digital Decoder
VIDEO OUT DIGITAL OUT AV COMPU LINK PCM/DOLBY DIGITAL VIDEO S-VIDEO COAXIAL OPTICAL Front speaker Front speaker Coaxial Optical digital digital Center speaker cable cable To digital input Sub woofer Amplifier or receiver Rear speaker Rear speaker XV-2000BK/1E 9/24/97, 1:11 PM... -
Page 16: Connecting The Power Cord
2. Place the two accessory R6P (SUM-3)/AA(15F) batteries in the remote control according to the polarity markings (“+” and “–”) inside the compartment and on the batteries. 3. Place the cover over the com- partment, and press down lightly. XV-2000BK/1E 9/24/97, 1:11 PM... - Page 17 • Never leave dead batteries lying around, take them apart, mix them with other refuse, or throw them into an incinerator. • Never touch liquid that has leaked out of a battery. • Do not mix new and old batteries, or batteries of different types, when replacing them. XV-2000BK/1E 9/24/97, 1:11 PM...
-
Page 18: Preliminary Knowledge
Title 1 Title 2 Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2 For a DVD Track 1 Track 2 Track 3 Track 4 For an audio CD XV-2000BK/1E 9/24/97, 1:12 PM... -
Page 19: How To Use Numeric Keys
1 = 0 = 5 = 2 = ENTER Example 2: To enter chapter number 14 1 = 4 = ENTER • If you enter a wrong number, enter zeros until the wrong number disappears, then reenter the correct numbers. XV-2000BK/1E 9/24/97, 1:12 PM... -
Page 20: On-Screen Guide And Invalid Operation Icons
On-screen displays The player provides several On-Screen Displays shown below for choosing preferences for initial settings and functions which are not frequently used in most cases. Opening display DVD during playback For preferences XV-2000BK/1E 9/24/97, 1:12 PM... - Page 21 • Numbers are entered using numeric keys. • Some functions become effective by pressing the ENTER button after specifying necessary entries. • Pressing ON SCREEN again exits the on screen display. XV-2000BK/1E 9/24/97, 1:13 PM...
-
Page 22: Screen Saver Function
5 minutes. Pressing any button of the player or the remote control unit will release the screen saver function and go back to the previous display. XV-2000BK/1E 9/24/97, 1:13 PM... -
Page 23: Dolby Digital
(See See “Preferences via “PREFERENCE” on-screen display” on page 53) According to your speaker configuration, you can get the optimum sound balance. * Manufactured under license from Dolby Laboratories Licensing Corporation. DOLBY, the double-D symbol and "AC-3" are trademarks of Dolby Laboratories Licensing Corpration. XV-2000BK/1E 9/24/97, 1:13 PM... -
Page 24: Basic Operations
See “Preferences via “PREFERENCE” on-screen display” on page 53. Some functions like fast forward or fast backward are disabled because of the recording method of DVD discs. In this case, the functions do not work even if the operations are done. XV-2000BK/1E 9/24/97, 1:13 PM... -
Page 25: Selecting An Item From A Menu
4/1 or ¢/¡ usually turns the menu pages. * Pressing “RETURN” returns to the previous menu. The operation procedure may be different depending on discs. Read the manual for the discs and follow the procedure indicated in the menu. XV-2000BK/1E 9/24/97, 1:13 PM... -
Page 26: Dvd Video Operations
DVD MENU button: The disc does not contain any DVD menu. Pressing DVD MENU again turns off the menu and resumes playback from the previous scene. XV-2000BK/2E 9/24/97, 1:19 PM... -
Page 27: Locating A Title
4. Press ENTER. The player starts playback from the selected chapter. appears when pressing ENTER: The disc does not contain chapters, or prohibits the chapter search function. To turn off the on-screen display: Press ON SCREEN. XV-2000BK/2E 9/24/97, 1:19 PM... -
Page 28: Starting Playback From A Specific Time
The player pauses. Each time you press STEP, the picture advances one frame. Pressing 3 returns the player to normal playback. * The audio is muted during frame-by-frame playback. * You cannot backward a picture frame-by-frame. XV-2000BK/2E 9/24/97, 1:20 PM... -
Page 29: Playing In Slow-Motion
1. Press RESUME when the disc is stopped or the power is off (STANDBY). RESUME The player will locate the memory position and resume playback. Repeating a title You can repeat playback of the current title. 1. Press ON SCREEN during playback. The on-screen display appears. XV-2000BK/2E 9/24/97, 1:20 PM... -
Page 30: Repeating A Chapter
You can repeat a current chapter. 1. Press ON SCREEN during playback. The on-screen display appears. 2. Move to “REPEAT” using LEFT RIGHT DOWN 3. Press ENTER twice. The current chapter will be repeated. The message box indicates “CHAPTER REPEAT”. XV-2000BK/2E 9/24/97, 1:20 PM... -
Page 31: Repeating A Desired Part
“A-B REPEAT” in the on-screen display and press ENTER. appears when pressing ENTER: You cannot execute the A-B Repeat because of the disc contents. To turn off the on-screen display: Press ON SCREEN. Pressing it again turns on the on-screen display again. XV-2000BK/2E 9/24/97, 1:21 PM... -
Page 32: Changing The Angle
* With some discs, subtitles are always displayed and SUBTITLE ON/OFF does not work. Changing the subtitle You can choose the subtitle language from among the languages included on a disc language during playback. 1. Press ON SCREEN during playback. The on-screen display appears. XV-2000BK/2E 9/24/97, 1:21 PM... -
Page 33: Changing The Audio
The current audio channel number and the total number of recorded audio channels are displayed in the box. Example: The example above indicates that 3 audio channels are recorded in the disc and audio channel 2 is being played back. XV-2000BK/2E 9/24/97, 1:21 PM... -
Page 34: Selecting Picture Character
C: noise reduction * You can set the picture characters for DVDs and video CDs independently. * The selection is memorized even if the player turns off and on. To turn off the on-screen display: Press ON SCREEN. XV-2000BK/2E 9/24/97, 1:22 PM... -
Page 35: Down Mix
DOWN MIX correctly according to the playback system when playing back a Dolby Digital 5.1-channel source. To turn off the on-screen display: Press ON SCREEN. XV-2000BK/2E 9/24/97, 1:22 PM... -
Page 36: Compression
1. Press ON SCREEN during playback. The on-screen display appears. 2. Move to “COMPRESSION” using LEFT RIGHT DOWN 3. Turn compression ON or OFF using LEFT RIGHT DOWN To turn off the on-screen display: Press ON SCREEN. XV-2000BK/2E 9/24/97, 1:22 PM... -
Page 37: Audio Cd Operations
* The last memory overrides the previous memory. 7 Resuming playback RESUME 1. Press RESUME when the disc is stopped or the power is off (STANDBY). The player will locate the memory position and start playback. XV-2000BK/2E 9/24/97, 1:22 PM... -
Page 38: Playing Back In A Desired Order
* Pressing 7 during the program playback makes the player stop but the program remains. To quit the program mode: Move to “PROGRAM” in the display using / / / and press ENTER. “PROGRAM” returns to its original color. XV-2000BK/2E 9/24/97, 1:23 PM... -
Page 39: Repeating All Tracks
2. Move to “REPEAT” using LEFT RIGHT DOWN 3. Press ENTER twice. “REPEAT1” is displayed and the current track is played back repeatedly. To stop playback Press 7. The player stops but the Single repeat mode remains. XV-2000BK/2E 9/24/97, 1:23 PM... -
Page 40: Repeating A Desired Part
The on-screen display appears. 2. Move to “A-B REPEAT” using LEFT RIGHT DOWN 3. At the beginning of the desired part (point A), press ENTER. 4. At the end of the desired part (point B), press ENTER. XV-2000BK/2E 9/24/97, 1:23 PM... -
Page 41: Starting Playback From A Specified Time
(You have to know the corresponding elapsed time in advance. To know the elapsed time, see “Selecting the displayed time mode” on page 40.) 1. Press ON SCREEN. The on-screen display appears. LEFT RIGHT DOWN 2. Move to the “TIME SEARCH” using XV-2000BK/2E 9/24/97, 1:23 PM... -
Page 42: Playing Back Only The Beginning Of Each Track
The first 10 seconds of each track on a disc are played back from the first track in numerical order. When all the tracks are played back, the player quits this function. To quit this function during execution Press 7. Playing back tracks in random order LEFT RIGHT DOWN XV-2000BK/2E 9/24/97, 1:24 PM... -
Page 43: Selecting The Displayed Time Mode
When all tracks have been played once, the Random play quits. * The same track will not be played back more than once during the Random play. To quit this function during execution Press 7. Selecting the displayed time mode XV-2000BK/2E 9/24/97, 1:24 PM... -
Page 44: Video Cd Operations
* When the picture is being played back of 1/32 of the normal speed (which is the slowest) the SLOW “+” button is not effective. * Similarly, “–” button is not effective during 1/2 speed playback. * Pressing STEP or 8 in slow-motion mode freezes the motion. XV-2000BK/3E 9/24/97, 1:28 PM... -
Page 45: Resuming Playback
You can enjoy the tracks on a video CD in the order you want. 1. Press ON SCREEN while the disc is stopped. The on-screen display appears. 2. Move to “PROGRAM” using and press ENTER. LEFT RIGHT DOWN XV-2000BK/3E 9/24/97, 1:28 PM... -
Page 46: Repeating All Tracks
Press 7. The player stops but the All-track repeat mode remains. To quit All-track Repeat: Move to “REPEAT” in the on-screen display and press ENTER twice. “REPEAT” returns to its original color. To turn off the on-screen display: Press ON SCREEN. XV-2000BK/3E 9/24/97, 1:28 PM... -
Page 47: Repeating A Single Track
To turn off the on-screen display: Press ON SCREEN. Repeating a part You can repeat a desired part in the current track. 1. Press ON SCREEN during playback. The on-screen display appears. 2. Move to “A-B REPEAT” using LEFT RIGHT DOWN XV-2000BK/3E 9/24/97, 1:29 PM... -
Page 48: Starting Playback From A Specified Time
“TIME SEARCH” using and press ENTER. LEFT RIGHT The player starts playback from the specified time. DOWN If the specified time does not exist, the entered number disappears so that you can reenter the time. XV-2000BK/3E 9/24/97, 1:29 PM... -
Page 49: Playing Back Only The Beginning Of Each Track
Press 7. Playing back tracks in The player can playback tracks in random order. random order 1. Press ON SCREEN while the disc is stopped. The on-screen display appears. 2. Move to “RANDOM” using LEFT RIGHT DOWN XV-2000BK/3E 9/24/97, 1:30 PM... -
Page 50: Selecting Audio Channels
Selecting picture character You can select from three picture characters; sharp or soft and noise reduction. 1. Press “ON SCREEN” during playback. The on-screen display appears. 2. Move to “PICTURE” using LEFT RIGHT DOWN XV-2000BK/3E 9/24/97, 1:30 PM... -
Page 51: Checking Total Disc Time
(such cases include playback of the track specified with the numeric keys), you can go into the PBC mode by two methods. Method 1: 1. Press 7. 2. Press 3. The player starts the PBC function. XV-2000BK/3E 9/24/97, 1:30 PM... - Page 52 The on-screen display appears. 2. Move to “PBC CALL” using LEFT RIGHT DOWN 3. Press ENTER. The player starts the PBC function. appears: The disc does not support PBC or it is being played back in PBC mode. XV-2000BK/3E 9/24/97, 1:31 PM...
-
Page 53: Controlling Other Equipment
Controlling Other Equipment The remote control unit supplied with the player can control other manufacturers’ TVs, CATV converters and satellite tuners, as well as JVC’s amplifiers/receivers. When operating the other manufacturers’ components, refer to the manuals supplied with them. To operate these components with the remote control, first you need to set the manufacturers’... -
Page 54: Controlling Catv Converter Or Satellite Tuner
Note: If there is more than one code listed for your brand of CATV converter or satellite tuner, try each one until the correct one is entered. Controlling a JVC AUDIO VOLUME controls the volume of a JVC amplifier or receiver. amplifier or receiver XV-2000BK/3E... -
Page 55: Selecting Preferences
"NEXT PAGE" or "PREV PAGE" using and press ENTER. 3. Move to the item to be set using LEFT RIGHT DOWN 4. Select the setting you prefer using LEFT RIGHT DOWN To turn off the on-screen display: Press ON SCREEN. XV-2000BK/3E 9/24/97, 1:31 PM... - Page 56 ON SCREEN GUIDE The player can display “on screen guide” icons or characters on the picture, which show what is happening to the disc or the player. You can turn the guide display on or off. XV-2000BK/3E 9/24/97, 1:32 PM...
- Page 57 DVD with 96-kHz, linear PCM no output DVD with Dolby Digital Dolby Digital bitstream 48-kHz, 16-bit linear ← DVD with MPEG audio 48-kHz, 16-bit linear PCM ← 44.1-kHz, 16-bit linear PCM ← Video CD 44.1-kHz, 16-bit linear PCM XV-2000BK/3E 9/24/97, 1:32 PM...
-
Page 58: Setting Parental Lock
2. Select the parental level using DOWN You can select the level from among NONE, NC17, R, PG13, PG, and G. You cannot playback DVD discs rated higher than the selected level. NONE means no restriction. NC17 is the strictest. XV-2000BK/3E 9/24/97, 1:32 PM... - Page 59 100+ "WRONG! RETRY.." If you forget your password: Enter "8888". After entering the correct password, proceed to the following steps. 3. Select the parental level using LEFT RIGHT DOWN 4. Press ENTER. The level is changed. XV-2000BK/3E 9/24/97, 1:32 PM...
- Page 60 If you select “YES”, then enter your password, the disc will start playback. If you enter a wrong password, the following message appears. "WRONG! RETRY.." If you select “NO”, the parental lock on-screen display disappears. XV-2000BK/3E 9/24/97, 1:32 PM...
-
Page 61: Other Information
Sometimes during play noise or images may be garbled. This is sometimes due to the disc. (It may not be up to industry standards.) These symptoms are caused by the discs, not by the malfunction of the player. XV-2000BK/3E 9/24/97, 1:32 PM... -
Page 62: Table Of Languages And Their Abbreviations
Tsonga Scots Gaelic Dutch Tatar Galician Norwegian Guarani Occitan Ukrainian Gujarati (Afan) Oromo Urdu Hausa Oriya Uzbek Hindi Panjabi Vietnamese Croatian Polish Volapuk Hungarian Pashto, Pushto Wolof Armenian Portuguese Xhosa Interlingua Quechua Yoruba Interlingue Rhaeto-Romance Zulu XV-2000BK/3E 9/24/97, 1:33 PM... -
Page 63: Manufacture's Code List
GI JERROLD SONY GI JERROLD TOSHIBA GI JERROLD ZENITH SCIENTIFIC ATRANTA HITACHI SCIENTIFIC ATRANTA PANASONIC ZENITH SAMSUNG ZENITH SANYO PIONEER SANYO PIONEER SAMSUNG HAMLIN/REGAL HAMLIN/REGAL HAMLIN/REGAL HAMLIN/REGAL OAK/SIGMA OAK/SIGMA OAK/SIGMA TOCOM TOCOM RCA/PANASONIC RCA/PANASONIC RCA/PANASONIC RCA(SAT) SONY(SAT) XV-2000BK/3E 9/24/97, 1:33 PM... -
Page 64: Av Compulink Remote Control System
When you buy a separate TV, VCR DVD player, receiver or other components and connect them to each other, you have to operate each component individually. JVC’s AV COMPULINK remote control system meets the demand for a system made up of single components and has the ease of operation of a single unit. - Page 65 There is no description about connections to a DVD player in the instruction manual of a television or VCR. But a television or VCR with AV COMPULINK terminals indicating II can be connected to a DVD player. XV-2000BK/3E 9/24/97, 1:33 PM...
-
Page 66: Troubleshooting
DOWN MIX is set to OFF. Set DOWN MIX to L0/R0 speakers do (see page 33). not reproduce dialogs for a DVD movie disc. There may be causes other than the player. Check the other devices connected to the player. XV-2000BK/3E 9/24/97, 1:33 PM... -
Page 67: Specifications
20 bit: More than 108 dB 24 bit: More than 108 dB Wow and flutter: Unmeasurable (less than ± 0.002%) Total harmonic distortion: Less than 0.002% * Specifications and appearance subject to change without prior notice. XV-2000BK/3E 9/24/97, 1:33 PM... - Page 68 All manuals and user guides at all-guides.com VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan 0997FTYUBNPRI XV-2000BK/CoverE 9/24/97, 1:17 PM...
