Summary of Contents for Swing Catalyst BALANCE PLATE 3
- Page 1 START GUIDE BALANCE PLATE swingcatalyst...
-
Page 2: Table Of Contents
Indoor installation....................6 Next to artificial turf..................7 Recessed in artificial turf................10 Balance Plate specifications.................13 Connect the Balance Plate................14 Part 3: In software Hardware settings....................15 Start new session....................17 Troubleshooting....................17 Checklist.......................18 Support........................19 Start Guide Balance Plate 2017 2006-2017 © Initial Force AS Swing Catalyst®... -
Page 3: Part 1 Install On Computer
Balance Plate drivers on your hard drive and follow the Balance Plate drivers on Windows 7: install instructions. Balance Plate Version 2 (64x32) drivers Click on Windows Start Menu -> Swing Catalyst -> may also be downloaded from Drivers folder: www.swingcatalyst.com/drivers... -
Page 4: Indoor Installation
INDOOR INSTALLATION NEXT TO ARTIFICIAL TURF For a portable setup, we suggest you place the Balance Plate on a solid, level surface next to the artificial turf. When installing a Balance Plate in an indoor studio or in a Make sure the Balance Plate does not move by placing it on garage bay, there are two choices: a rubber mat or similar. - Page 5 Place the Balance Plate next to a mat of artificial turf. The USB cable output should be on the heel side for both right and left handed golfers. Connect the USB to the computer. Note: It is important that the USB cable is free of any obstruction or movement to avoid damage to the unit.
-
Page 6: Recessed In Artificial Turf
RECESSED IN ARTIFICIAL TURF Cut a hole in the turf matching the Balance Plate dimensions (see page 13) so it becomes a tight fit. For a more permanent installation, we recommend building the Balance Plate into a mat of artificial turf. See the illustrations on the next two pages for step-by-step instructions. -
Page 7: Balance Plate Specifications
BALANCE PLATE SPECIFICATIONS 986 mm / 38.8’’ Cut an incision under the mat to make room for the USB 493 mm / 19.4’’ 493 mm / 19.4’’ cable. The USB cable should come out on the heel side for right handed golfers, and be placed under the mat. 10 mm / 0.4’’... -
Page 8: Connect The Balance Plate
CONNECT THE BALANCE PLATE HARDWARE SETTINGS Connect the provided USB cable to the Balance Plate. Open the Swing Catalyst software. In the main menu go to Settings and Hardware. All electronics connected to the Balance Plate must have ground. The power grid should have adequate Under the Sensor Plate tab, set the slider to ON. -
Page 9: Start New Session
START NEW SESSION Now it is time to verify that you receive data from the Balance Plate. Select Swing Analysis in the Main Menu, set up a new golfer and click Start session. Select Capture in the Quick Start menu and step on the Balance Plate. Important: You need to have a supported camera to be able to go in capture mode. -
Page 10: Checklist
CHECKLIST SUPPORT Install the driver Position the Balance Plate Check electrical ground Connect the Balance Plate with USB cabel to your PC Enable the Balance Plate in the software Verify the data. If you have any questions, please contact support: support@swingcatalyst.com Information may also be found in our Help Center: www.swingcatalyst.com/help... - Page 11 Follow Swing Catalyst to receive the latest updates: swingcatalyst...
