- Page 1 INSTALLATION GUIDE 3D MOTION PLATE For Swing Catalyst Studio Installations...
-
Page 2: Table Of Contents
TV & feedback screen setup................12 Part 3: Flooring & Specifications Building floor structure.................13 Mounting rail specs..................16 3D Motion Plate specs...................17 Building podium structure................19 Part 4: Studio Lights LED lighting setup...................22 Support........................23 Installation guide 3D Motion Plate 2016 2006-2017 © Initial Force AS Swing Catalyst®... -
Page 3: Introduction
INTRODUCTION The Swing Catalyst team has over the years gained extensive experience from studio installations all around the world. This knowledge is now passed on to you as a valued Swing Catalyst customer. This guide offers recommendations regarding space requirements,... -
Page 4: Part 1 Studio Overview
Face on camera right direction Down the line camera Overhead camera 3D Motion Plate / Balance Plate PC table Optional wall mounted flat screen * These are the recommended distances. Please note that more space is required if you consider using a radar based launch Optional student screen monitor. -
Page 5: Dimensions - Garage Bay
DIMENSIONS - GARAGE BAY CAMERAS Hitting direction 3.0m / 9’ 10” * Hitting direction Camera height measured from floor to lens: Face on camera left Face on camera right Down the line camera * These are the recommended distances. Please note that more Recommended minimum height from floor to lens: space is required if you consider using a radar based launch monitor. -
Page 6: Part 2 Cabling
Ethernet for GigE Vision USB for Balance Plate USB for USB cameras All electronics connected to the 3D Motion Plate must have ground. The power grid should have adequate Power outlet, 110-220V AC grounding. We recommend using surge protectors to prevent damage to your electronics. -
Page 7: Tv & Feedback Screen Setup
TV & FEEDBACK SCREEN SETUP BUILDING FLOOR STRUCTURE Place the 3D Motion Plate on a flat and level floor to ensure accurate data readings. Hitting direction Screen cables: HDMI for flatscreen TV and feedback screen Power outlet, 110-220V AC Note: The setup for flatscreen TV and feedback screen is optional. - Page 8 Side view Same height as 1 cm / Logo mat sensor plates + Turf 0.4’’ logo mat. Balance Plate Board 7,9 cm / 3.11’’ Force Plate Wood stud Mounting rail Minimum 3 cm/1.2 in gap between the sensor plates and the wood Top view construction.
-
Page 9: Part 3 Flooring & Specifications
MOUNTING RAIL SPECS 3D MOTION PLATE SPECS Bottom view 956,8 mm / 37.67’’ 874,5 mm / 34.43’’ 998 mm / 39.3’’ 811 mm / 31.93’’ 998 mm / 39.3’’ 153 mm / 6.0’’ ø a: 41,4 mm / 1.63’’ 49 mm / 1.93’’... -
Page 10: Building Podium Structure
BUILDING PODIUM STRUCTURE Feet on the floor Follow construction details from the previous pages. Choose Important! To ensure accurate data readings the 3D Motion desired moldings for a good finish. Plate must be level and have all 4 feet in contact with the floor. Make sure the plate is level before mounting the Balance Plate. -
Page 11: Part 4 Studio Lights
1.2m / 3’ 93’’ Side view Hitting direction Hitting direction 3D Motion Plate hole Recommended lighting setup: Lumen: 30,000 lumen Beam angle: 45 degrees Number of spot lights: 15-30 Recommended lux measurements: Hip-height horizontally: 1300 lux Floor below golfer: 2300 lux Walls: 500 lux Part 3 Flooring &... -
Page 12: Support
SUPPORT Follow Swing Catalyst to receive the latest updates: If you have any questions, please contact support: support@swingcatalyst.com...
