Summary of Contents for Truper ROEL-30A
- Page 1 Manual 6.5 A Rotary Hammer Joules Impact Energy Motor ROEL-30A Applies for: Code Model 103066 ROEL-30A Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Contents CAUTION Technical Data Power Requirements To gain the best performance of the tool, prolong the duty life, General Power Tools Safety Warnings make the Warranty valid if necessary, and to avoid hazards Safety warnings for Drills of fatal injuries please read and and Hammer Drills understand this Manual before using the tool. -
Page 3: Technical Data
Technical Data ROEL-30A Code 103066 Description Rotary Hammer Chuck SDS Plus (Quick insertion system) Voltage 127 V~ Frequency 60 Hz Current 6.5 A Power 800 W Impact Energy 3.2 Joules Drilling Capacity Concrete: 1-1/8” Steel: 1/2” Wood: 1-1/4” Speed 0 RPM - 1 100 RPM... -
Page 4: General Power Tools Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Drills And Hammer Drills
Safety warnings for Drills and Hammer Drills Choose the right bit While operating the hammer drill CAUTION • Choose the right bit for the work piece. • Use the auxiliary handles, if supplied with the tool. It reduces the risk of severe injury and makes the job Loss of control may result in personal injury. -
Page 6: Parts
Parts Depth Stop Rod Ball bearing mounted motor Forward / Reverse control switch SDS-plus Chuck Fast Depth Non-Slip grip Adjustment System Lock-on 360° button Switch Auxiliary Handle Function Selector Dust Guard Cord Protector Chuck Power Cord 1/2" Standard chuck with SDS adapter Preparation Auxiliary Handle and Depth Stop Depth... -
Page 7: Start Up
Preparation Bit and Accessory Installation or Removal • Clean and lubricate lightly the bit and / or accessory before installing. • Insert the shaft of the bit into the SDS socket. • Twist and push the bit in until it engages. •... - Page 8 Start Up Rotation Direction The tool has a reversing switch to change the direction of rotation. Move the reversing switch lever to position (A) for clockwise rotation or to position (B) for counterclockwise rotation. WARNING Never use the tool in reverse with the operation mode selector in the IMPACT positions ( ).
- Page 9 Start Up Operation Percussion drill. • Set the knob that changes the drive mode to the symbol • Position the bit at the desired location in the hole, then actuate the switch. • Do not force the tool. With less pressure, you get better results. Keep the tool in the proper position and prevent it from slipping out of the hole.
-
Page 10: Maintenance
Maintenance Cleaning and Care Lubrication • To guarantee adequate motor cooling, always keep slots • We recommend lubricating the tool transmission every clean and free of obstructions. carbon brush change in a Authorized • Regularly inspect all the assembly screws. Double-check Service Center. -
Page 11: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 12: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. Phone number 800-018-7873. Made in China. Imported by TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100. - Page 20 Advertencias de seguridad...
