CHERY T19
Labour Time
Manual 2020
FOREWORD
This labour time manual has been prepared to
provide standard work time for the T19 models
when performing repairs under conditions
prescribed by Chery.
This manual only applies to models listed
below:
T19 1.5L+CVT
T19 1.5L+MT
Explanations of the Labour Times, conditions
and how to use this manual are provided.
Please read these explanations thoroughly.
The Labour Times are subject to change at
any time by Chery, based on time studies by
Chery relating to improved methods,
techniques or equipment.
All rights reserved. Any unit or individual shall
not reproduce or copy this manual in any form
or by any means, or transmit it on the network
by any form for any purpose without written
permission of Chery Automobile Co., Ltd.
