- Page 1 Wireless Analogue Control System USER MANUAL 08/2024 - Version 1.0 E&OE...
-
Page 2: System Specifications
INDEX Index Conven#onal Accessory Opera#on System Specifica#ons Digital Accessory Opera#on About INFINITY Changing an Accessory Name or Icon Pack Contents Accessory Sequences The Solo Base Unit P17-18 Programming Accessories Directly Duo Base Unit P19-22 Acolyte Expansion Units Handset Addi#onal Handsets Handset LCD Screen Troubleshoo#ng Power Supply... - Page 3 THANK YOU FOR CHOOSING GAUGEMASTER INFINITY Gaugemaster Infinity offers today’s railway modeller complete control of their layout in a contemporary way. Infinity delivers all the benefits of conven#onal control with a new, modern feel and some added features we think you will love.
- Page 4 YOUR GAUGEMASTER INFINITY SOLO BASE UNIT FRONT REAR A - Track 1 Status LED E - DCC Feed for DCC controlled accessories* RED = Stop has been pressed F - Track Power Output* GREEN = Connected to a handset and...
- Page 5 YOUR GAUGEMASTER INFINITY DUO BASE UNIT FRONT REAR D - USB Port for firmware updates A - Track 1 Status LED RED = Stop has been pressed E - DCC Feed for DCC controlled accessories* GREEN = Connected to a handset and...
- Page 6 YOUR GAUGEMASTER INFINITY HANDSET A - LCD DISPLAY See Right B/C/D - SELECTION BUTTONS The use of these bu@ons varies, depending on what you want to change or operate. The func#on of each bu@on is displayed on the screen directly above them. On the DRIVE...
- Page 7 YOUR GAUGEMASTER INFINITY HANDSET LCD SCREEN Track Output Current being Scaled Time (If Handset Bluetooth Status being con- drawn on Clock Func#on Ba@ery SOLID = Connected to trolled selected track is turned on) Level Base Unit, FLASHING = Not Connected Track Name (User Definable)
-
Page 8: Before You Get Started
SUPPORT The Gaugemaster website is a great resource to learn about the INFINITY system and our physical shop is open 7 days a week should you ever need face to face support in a beau#ful part of the world. Alter-... -
Page 9: Quick Start
We’re going to walk you through the system in such a way that you get to run a train quickly and get to experience conven#onal GAUGEMASTER analogue control, in the same way you would from a COMBI, a Model D or a Model Q. The main difference will be that you will achieve this wirelessly and through a mobile, ergonomically designed purpose tooled HANDSET using contemporary technology. - Page 10 Dial clockwise to accelerate and an#clockwise to decelerate. You will experience the slow speed ana- logue control synonymous with a Gaugemaster controller, but with this INFINITY controller, it’s being delivered wirelessly. Switch direc#on by using the ‘< >‘ bu@on, preferably by slowing to a stop first and then star#ng up again.
- Page 11 SIMULATION If you have historically owned a controller with SIMULATION such as a Gaugemaster Model P or Model DS, you’ll have enjoyed the ability to automa#cally accelerate a train, allow it to coast or to be braked to a stands#ll. This was historically achieved with two control dials - a regulator and a brake.
- Page 12 DRIVE/YARD MODE INFINITY allows you to drive your train by pressing the direc#on bu@on and then turning the Dial clock- wise to increase the speed of your train, and turning it an#-clockwise to slow it down. It will not change direc#on un#l you press the ‘< >‘ key. When you press this key you will see the direc#on change and the display toggle between a leO or right direc#onal arrow depending on the direc#on of travel as displayed below This is called DRIVE MODE and is the INFINITY default seBng.
- Page 13 In order to access the clock, follow the sequence below: Press MENU Press 5 (CLOCK Press 4 (MORE) then SETTINGS) scroll down using the Dial This will take you to the following screen In order to set the #me, Press “1” and using the numeric keypad, type in the #me and press ENTER.
- Page 14 DISPLAY LIGHT The Handset brightness can be changed from 0% to 100% If you’d prefer to change this, please follow these steps Press MENU Press 6 (DISPLAY Press 4 (MORE) Rotate the Dial to LIGHT) then scroll down change the using the Dial Brightness Level % Press SAVE...
-
Page 15: Accessory Operation
ACCESSORY OPERATION Accessories are a significant part of realis#c Model Railway Control, so for ease of use we’ve given them their own sec#on of this user manual. CONVENTIONAL ACCESSORY OPERATION You may already have a bank of point or signal switches on your layout and you can happily use these independently using their own power source or via the 18v DC feed on the back of the BASE UNIT. - Page 16 DIGITAL ACCESSORY OPERATION - CHANGING AN ACCESSORY NAME/ICON Press MENU Press 4 (4-MORE) Select ACC01 Press 2 (EDIT ACC) Press ‘1’ to change the name of the accessory using the same Dial/Cursor combina#on (as used for re- naming your track) and described on Page 13. You can name this accessory whatever you choose.
- Page 17 Some DCC accessory decoders will oOen need to be programmed to a different address and for many modules (such as those by Train-Tech, Gaugemaster and the Infinity range), this is done while in posi- #on u#lising a learn bu@on so as discussed earlier, please refer to their specific instruc#ons on how to program them.
- Page 18 If you want to change the CV align the arrow and then key in the CV number you require using the keypad, then move to the VALUE op#on and key in the new value required. Press PROG to send this informa#on to the a@ached decoder. In the VALUE sec#on and valida#on message will appear if the decoder support read back of either SUCCESSESFUL or UNVALIDATED.
- Page 19 GAUGEMASTER INFINITY ACOLYTE SINGLE EXPANSION BASE UNIT FRONT REAR A - Track 1 Status LED D - Expansion Port IN for use with INFINITY expan- RED = Stop has been pressed sion units (available separately) E - Expansion Port OUT for use with INFINITY expan-...
- Page 20 GAUGEMASTER INFINITY ACOLYTE DUAL EXPANSION BASE UNIT FRONT REAR A - Track 1 Status LED D - USB Port for firmware updates RED = Stop has been pressed E - DCC Feed for DCC controlled accessories* F - Track 1 Power Output*...
- Page 21 CONNECTING YOUR ACOLYTE EXPANSION UNITS Your INFINITY system is easy to add to, with it’s ini#al single or double track configura#on. This sures your control system can grow with your layout and you don’t need to worry as your model rail- way becomes larger.
- Page 22 Please note: although the Acolyte Single and Dual Base Units have the Tracks labelled Track 1 / Track 2 on each of the units, the track numbers assigned on the handset on connec#on will be sequen#al. Pro-Tip: It is possible to common return mul#ple units.
-
Page 23: Additional Handsets
And to be fair, none of us need much of an excuse to visit our local model railway shop? Of course, full technical support also exists here at Gaugemaster and we will always do our very best to help you. -
Page 24: Standard Warranty
3. Gaugemaster will look to repair any unit as soon as reasonably possible subject to parts availability. Gaugemaster will cover the hours to facilitate the repair if the product is within the warranty period and the unit has not been tampered with or dropped 4. -
Page 25: Extended Warranty
Gaugemaster and maybe invoiced following the repair. f. Gaugemaster recommend items are returned to us using methods that include appropriate insur ance and any item lost in transit to us is not the responsibility of Gaugemaster and will not be re placed. - Page 26 NOTES...
- Page 27 NOTES...
- Page 28 Designed, Engineered and Manufactured in the UK This product is not a toy and contains small parts which may harm or choke a child. Not recommended for children under 14 years old unless supervised by an adult. CONTACT Gaugemaster Controls Ltd Gaugemaster House Ford Road Arundel...
