900 Series Belt Cutter/Skiver
Safety and Operating Manual
WARNING
IMPROPER OR UNSAFE use of this tool can result in death or serious bodily injury! This
manual contains important information about product function and safety. Please read and
understand this manual BEFORE operating the tool. Please keep this manual available for
other users and owners before they use the tool. This manual should be stored in a safe place.
www.flexco.com
www.flexco.com
Advertisement
Table of Contents
Related Manuals for Flexco 900 Series
Summary of Contents for Flexco 900 Series
- Page 1 900 Series Belt Cutter/Skiver Safety and Operating Manual WARNING IMPROPER OR UNSAFE use of this tool can result in death or serious bodily injury! This manual contains important information about product function and safety. Please read and understand this manual BEFORE operating the tool. Please keep this manual available for other users and owners before they use the tool.
-
Page 2: Table Of Contents
900 Series Belt Cutter/Skiver Table of Contents System Components ........................3 General Safety Rules ........................4-5 Belt Preparation ..........................6 Cutter Operation ........................7-8 Skiver Operation ........................9-12 Changing the Cutter Blade ......................13 Changing the Skiver Blade ......................14 Declaration of Incorporation ......................15 www.flexco.com... -
Page 3: System Components
900 Series Belt Cutter/Skiver System Components Locking Side Upright Cutter Clamp Knob Drive Shaft Carrying Handle Top Clamp Before Skive Drive Skiver Right Knob Handle Blade Belt Stop Bottom After Skive Cutter/Skiver Left Knob Assembly Fixed Side Cutter Upright Blade... -
Page 4: General Safety Rules
900 Series Belt Cutter/Skiver General Safety Rules – Save These Instructions– 1. WORK AREA Signal words: CAUTION “DANGER” indicates an imminently hazardous Keep your work area clean and well lit. Cluttered situation which, if not avoided, will result in death benches and dark areas invite accidents. - Page 5 900 Series Belt Cutter/Skiver General Safety Rules CAUTION 6. BELT SKIVER SAFETY CAUTION Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained tools, with sharp Do not use a dull or damaged blade. cutting edges are less likely to bind and are easier to control.
-
Page 6: Belt Preparation
900 Series Belt Cutter/Skiver WARNING Use caution when handling belt cutter blades. Prior to any work on conveyors and the belt, be sure the power has been turned off and both are “locked out. ” Follow other safety precautions outlined in the operator’s manual. -
Page 7: Cutter Operation
900 Series Belt Cutter/Skiver Cutter Operation Install the drive handle on cutter drive shaft. Move blade to the end of the cutter if needed. Ensure blade is fully enclosed in the upright. Remove Top Clamp Bar. Push down the clamp release lever on locking Pull top clamp bar up and then slide out of the fixed side upright. - Page 8 900 Series Belt Cutter/Skiver Cutter Operation Slide clamp bar into the fixed side upright. Push clamp bar into the locking side upright. NOTE: If clamp release lever won’t lock in place, release pressure by turning both belt clamp knobs counterclockwise until the clamp release lever is locked.
-
Page 9: Skiver Operation
900 Series Belt Cutter/Skiver Skiver Operation Skive Fastener Belt Thickness Skive Fastener Belt Thickness Skive Fastener Belt Thickness Skive Fastener Belt Thickness Skive Fastener Belt Thickness Skive Fastener Belt Thickness Skive Fastener Belt Thickness Setting Size (mm) Setting Size (mm) - Page 10 900 Series Belt Cutter/Skiver Skiver Operation While keeping hands away from the exposed skiver blade, insert the skiver square gibb into the skiver frame rails. Push to engage the skiver gears in the gear track. Make sure the skiver moves freely.
- Page 11 Best Practice: Skive approximately 1/8" (3mm) for most fasteners to countersink them flush with the belt top cover, making sure not to skive into the carcass. If needed, reference the Skive Depth Guage Chart. For sticky/gummy belt covers, use Flexco Silicone Lubricant on the top cover to minimize resistance between the top cover and the skiver pressure plate.
- Page 12 900 Series Belt Cutter/Skiver Skiver Operation Tool Options for Operating Skiver Drive Handle Drive Ratchet Use the drive handle to operate the skiver assembly by attaching Use a 3/8" drive ratchet to operate the skiver assembly by it to the skiver drive shaft. Turn the drive handle clockwise to attaching the 1/2"...
-
Page 13: Changing The Cutter Blade
900 Series Belt Cutter/Skiver Changing the Cutter Blade WARNING Use caution when changing belt cutter blades. Avoid contact with blade edges and sharp corners. Proper PPE is required. 12-1 Remove clamp bar. Locking Side Fixed Side Upright Upright 12-2 12-3... -
Page 14: Changing The Skiver Blade
900 Series Belt Cutter/Skiver Changing the Skiver Blade 13-1 Remove skiver assembly from the bottom cutter/skiver assembly. 13-2 13-3 13-4 Spacer Loosen and remove “After Skive” left knob Remove screws on underside of the blade Insert new blade. and blade holder from skiver assembly. -
Page 15: Declaration Of Incorporation
900 Series Belt Cutter/Skiver Declaration of Incorporation —15—... - Page 16 900 Series Belt Cutter/Skiver Visit www.flexco.com for other Flexco locations and products, or to find an authorized distributor. ©2024 Flexible Steel Lacing Company. 05-08-24. 111760 —16—...
