TC Electronic HONEY POT FUZZ Quick Start Manual
TC Electronic HONEY POT FUZZ Quick Start Manual

TC Electronic HONEY POT FUZZ Quick Start Manual

Vintage-flavored fuzz pedal with massive wall of tones and miles of sustain

Advertisement

Quick Links

TC Electronic
HONEY POT FUZZ
Vintage-Flavored Fuzz Pedal with Massive Wall of
Tones and Miles of Sustain
Quick Start Guide
(4)
(3)
(1)
(2)
Controls
(EN)
Input/Output jacks – Connect a 1/4" cable from your
(1)
guitar to the INPUT jack, and connect a cable from the
OUTPUT jack to your amplifier.
(2)
9 V DC – Connect a 9 V power supply (not included).
(3)
Footswitch – Turns the effect on and off. The LED will
light when the pedal is engaged. The pedal operates in
true bypass when disengaged.
SUSTAIN – Adjusts the amount of overdrive
(4)
and saturation.
(5)
VOLUME – Adjusts the output level.
(6)
TONE – Adjusts the brightness.
V 4.0
Controles y conectores
(ES)
Input/Output jacks – Conecte un cable con clavijas de
(1)
6,3 mm desde su guitarra a la toma INPUT y otro cable
desde la toma OUTPUT
al amplificador.
9 V DC – Conecte un adaptador de corriente de
(2)
9 V (opcional).
Footswitch – Esto activa y desactiva el efecto. El piloto
(3)
se iluminará cuando el pedal esté activo. Cuando no esté
activo, este pedal ofrece un bypass real.
(4)
SUSTAIN – Esto ajusta la cantidad de saturación
y overdrive.
VOLUME – Este mando ajusta el nivel de salida.
(5)
(5)
TONE – Esto ajusta el brillo.
(6)
Réglages et connecteurs
(FR)
(6)
(1)
Input/Output jacks – Connectez un câble Jack
6,35 mm entre votre guitare et l'entrée de la pédale.
Connectez également un câble entre la sortie de la
pédale et l'entrée de votre ampli.
(2)
9 V DC – Permet de connecter un adaptateur secteur
9 V (non fourni).
(3)
Footswitch – Permet d'activer/de désactiver l'effet.
La LED s'allume lorsque la pédale est activée. Lorsque
l'effet est désactivé, la pédale fonctionne en true
bypass.
(4)
SUSTAIN – Permet de régler la quantité d'overdrive et
de saturation.
(5)
VOLUME – Permet de régler le niveau de sortie.
(6)
TONE – Permet de régler la brillance du son.
Regler und Anschlüsse
(DE)
(1)
Input/Output jacks – Schließen Sie das 6,3 mm-Kabel
Ihrer Gitarre an die INPUT-Buchse an und verbinden Sie
die OUTPUT-Buchse über ein weiteres Kabel mit Ihrem
Verstärker.
(2)
9 V DC – Schließen Sie hier einen optionalen
9 V Netzadapter an.
(3)
Footswitch – Schaltet den Effekt ein und aus. Bei
aktiviertem Pedal leuchtet die LED. Bei deaktiviertem
Pedal wird das Signal vollständig am Pedal
vorbeigeführt (echter Bypass).
(4)
SUSTAIN – Regelt die Stärke der Übersteuerung
und Sättigung.
VOLUME – Regelt den Ausgangspegel.
(5)
TONE – Regelt die Helligkeit.
(6)
Controles e Conectores
(PT)
(1)
Jacks Input/Output – Conecte um cabo de 1/4" da
sua guitarra ao jack INPUT, e conecte um cabo do jack
OUTPUT ao seu amplificador.
9 V DC – Conecte uma fonte de alimentação de
(2)
9 V (não inclusa).
(3)
Footswitch – Liga e desliga o efeito. O LED acenderá
quando o pedal estiver ativado. O pedal opera em true
bypass quando desativado.
SUSTAIN – Ajusta a quantidade de overdrive e saturação.
(4)
(5)
VOLUME – Ajusta o nível de saída.
(6)
TONE – Ajusta o brilho.
Controlli
(IT)
(1)
Input/Output jacks – Collega un cavo da 1/4" dalla tua
chitarra alla presa INPUT e collega un cavo dalla presa
OUTPUT al tuo amplificatore.
9 V DC – Collegare un alimentatore da 9 V (non incluso).
(2)
Footswitch – Attiva e disattiva l'effetto. Il LED si
(3)
accenderà quando il pedale è inserito. Il pedale funziona
in true bypass quando è disinserito.
(4)
SUSTAIN – Regola la quantità di overdrive
e saturazione.
VOLUME – Regola il livello di uscita.
(5)
(6)
TONE – Regola la luminosità.
Besturing
(NL)
(1)
Input/Output jacks – Sluit een 1/4" kabel van je gitaar
aan op de INPUT-aansluiting, en sluit een kabel van de
OUTPUT-aansluiting aan op je versterker.
9 V DC – Sluit een 9 V voeding aan (niet inbegrepen).
(2)
Footswitch – Zet het effect aan en uit. De LED gaat
(3)
branden als het pedaal is ingeschakeld. Het pedaal
werkt in ware bypass wanneer het is uitgeschakeld.
(4)
SUSTAIN – Past de hoeveelheid overdrive en
verzadiging aan.
VOLUME – Past het uitgangsniveau aan.
(5)
(6)
TONE – Past de helderheid aan.
Kontroller
(SE)
(1)
Input/Output jacks – Anslut en 1/4" kabel från din
gitarr till INPUT-uttaget och anslut en kabel från
OUTPUT-uttaget till din förstärkare.
9 V DC – Anslut en 9 V strömförsörjning (ingår ej).
(2)
Footswitch – Slår på och av effekten. LED-lampan
(3)
tänds när pedalen är inkopplad. Pedalen fungerar i
verklig förbikoppling när den är urkopplad.
(4)
SUSTAIN – Justerar mängden överdrift
och mättnad.
VOLUME – Justerar utgångsnivån.
(5)
(6)
TONE – Justerar ljusstyrkan.
