INSTALLATION INSTRUCTIONS
Before attempting to connect or operate this product, please read instructions completely.
Installation and Operation Instructions for the following model:
PWM485AW
Wall Mount Kit for use with WV-S25xxx, WV-SFV6xxx, WV-SFV5xxx, WVSFV3xxx, WV-CW6xx
Descriptions and additional units:
PWM485AW: Pendant Shroud with Wall Mount Bracket Kit
Kit Includes:
PS485AW: Pendant Shroud
PWM40AW: Wall Mount Bracket
PWM40AW
4 x 8-32 screws
Hardware
BY:
W: White Color Model
PS485AW
1 Wrench
7L493 Rev E 221114
Advertisement
Related Manuals for Wren i-PRO PWM485AW
Summary of Contents for Wren i-PRO PWM485AW
- Page 1 Manufactured for: INSTALLATION INSTRUCTIONS Before attempting to connect or operate this product, please read instructions completely. Installation and Operation Instructions for the following model: PWM485AW Wall Mount Kit for use with WV-S25xxx, WV-SFV6xxx, WV-SFV5xxx, WVSFV3xxx, WV-CW6xx Descriptions and additional units: PWM485AW: Pendant Shroud with Wall Mount Bracket Kit Kit Includes: PS485AW: Pendant Shroud...
- Page 2 IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read Instructions - All the safety and operating instructions should be read before the unit is operated. CAUTION Retain Instructions - The safety and operating instructions should be retained for future reference. RISK OF ELECTRICAL SHOCK Heed Warnings - All warnings on the unit and in the DO NOT OPEN operating instructions should be adhered to.
- Page 3 Remove the mount cover using the provided wrench. NOTE: Captive fasteners have been provided. Do not Securely mount the bracket to the wall using the appropriate fasteners and anchors (not provided). completely remove the fasteners from the mount. Conduit Attachment plate Port (included in Camera) Pull the appropriate camera cabling into the wall...
- Page 4 Tether Mounting Point Apply thread Attach the camera to the pendant shroud and complete sealant here all wiring connections inside the mount. Wrap Teflon tape around the pipe threads and thread Note: If required, attach the safety tether to the tether the pendant shroud onto the mount until it is tight.
- Page 5 Manufactured for: Weight: 2.95 lbs. [1.34 kg] 7L493 Rev E 221114...
