INSTALLATION INSTRUCTIONS
Before attempting to connect or operate this product, please read
instructions completely. Installation and Operation Instructions for
the following model:
PPRM35W
Parapet Mount Bracket for use with i-PRO PS485S, PS781, WV-QAT501-S
(6) Stainless Steel Masonry Anchors
•
(1) Masonry Drill Bit
•
(5) M10 Stainless Steel Bolts
•
(2) End Caps (Mounted)
•
(4) 3/8" Hex Head Bolts
•
(4) 3/8" Flat Washer
•
(4) 3/8" Split Washer
•
Distributed by:
Panasonic i-PRO Sensing Solutions Corporation of America
8550 Fallbrook Drive, Suite 200, Houston, Texas 77064
https://www.security.us.panasonic.com/
PPRM35W
(1) Parapet Mount Base
•
(1) Parapet Mount Arm w/ 1.5" NPT Threads
•
(1) Parapet Mount Extension
•
(1) Hardware Pack
•
INCLUDED HARDWARE
7L615
Rev.A
210812
Advertisement
Table of Contents
Related Manuals for Wren PPRM35W
Summary of Contents for Wren PPRM35W
- Page 1 INSTALLATION INSTRUCTIONS Before attempting to connect or operate this product, please read instructions completely. Installation and Operation Instructions for the following model: PPRM35W Parapet Mount Bracket for use with i-PRO PS485S, PS781, WV-QAT501-S PPRM35W (1) Parapet Mount Base • (1) Parapet Mount Arm w/ 1.5” NPT Threads •...
- Page 2 IMPORTANT SAFEGUARDS 1. Read Instructions - All the safety and operating instructions should be read before the unit is operated. 2. Retain Instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the unit and in the operating instructions should be adhered to. 4.
- Page 3 Installation area for this product: Make sure that the installation area is strong enough to hold the total weight of the camera and • mount assembly before installation. Tools needed for installation: Hammer • Drill • 12” Level • Adjustable Wrench or 3/8” Hex Head Socket •...
- Page 4 IMPORTANT Prepare safety tethers and anchor bolts according to the material and strength of the area where the product is to be installed. The pull-out strength of the anchor bolt shall be more than 5 times of the total weight of the in- stalled devices (including the camera body, ceiling mount, anchor bolts, and all other parts.) Panasonic i-PRO Sensing Solutions Corporation of America assumes no responsibility for injuries or property damage resulting from failures arising out of improper installation or operation inconsistent with this documen-...
- Page 5 FINAL DIMENSIONS & WEIGHT Approx. Weight: 22lb / 9.98 kg 7L615 Rev.A 210812...
