Instructions
GH933 250 Foot Hose Kits
For use with Architectural Coating, Paints, Roof Coatings and Below Grade Coatings
7250 psi (50 MPa, 500 bar) Maximum Working Pressure
Model: 16U281 GH933 / 16U285 GH933 ES
with L145C2 pump and filter use 16U761 hose kit
Model: 17B484, GH933 ES
with L145C1 pump has no filter use 17B825 hose kit
Important Safety Instructions
Read all warnings and instructions in this manual, related manuals and on the equipment.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
3A5269E
EN
ti31780a
Advertisement
Table of Contents
Related Manuals for Graco GH933
Summary of Contents for Graco GH933
- Page 1 For use with Architectural Coating, Paints, Roof Coatings and Below Grade Coatings 7250 psi (50 MPa, 500 bar) Maximum Working Pressure Model: 16U281 GH933 / 16U285 GH933 ES with L145C2 pump and filter use 16U761 hose kit Model: 17B484, GH933 ES...
-
Page 2: Table Of Contents
Graco Standard Warranty ........ -
Page 3: Warnings
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these sym- bols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard sym- bols and warnings not covered in this section may appear throughout the body of this manual where applicable. -
Page 4: Pressure Relief Procedure
Pressure Relief Procedure Pressure Relief Procedure 2. Turn ON/OFF switch to OFF. Follow the Pressure Relief Procedure whenever you see this symbol. 3. Disengage trigger lock. Hold metal part of gun against grounded metal pail and trigger gun into pail to relieve pressure. -
Page 5: Preparation
Preparation Preparation Hose Kits Locate the 17J818 (1/2 NPT x 3/4 NPSM) fitting. This fit- ting is identified by the notches cut in the hex. Pump L145C2 with filter 16U761 L145C1 without filter 17B825 Inspect 3/4 NPSM male pipe fittings. Make certain they have internal 30°... -
Page 6: Connect Hose-To-Hose
Preparation Connect Hose-to-Hose 18. Connect fourth hose H77550 (50 ft.) swivel nut directly to 17J816 fitting on the third hose. Refer to the illustration on the following page. 19. Turn swivel nut until finger tight. 1. Locate three 17J816 3/4 NPSM x 3/4 NPSM fitting. 20. -
Page 7: Connect Gun To Hose
Preparation Connect Gun to Hose Install Extension and Spray Tip When spray gun XTR704 from hose kit 16U761 is used, 1. Thread gun extension 246296 onto the spray gun. connect it directly to the swivel 165198 and 155570 2. Install angle spray nozzle 234189 onto the gun installed at the end of the last hose. -
Page 8: Alternative Hose Joint Assembly
Preparation Alternative Hose Joint Assembly 1. Inspect fitting chambers. Must be clean and without 5. Using two wrenches, tighten hose swivel nut an surface defects. additional full turn. 2. Lubricate threads and chambers. 3. Turn swivel nut on fitting until tight. 4. -
Page 9: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective. - Page 10 For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. All written and visual data contained in this document reflects the latest product information available at the time of publication.
