Symbol Type of heating
Hot air gentle
Pizza setting
Bottom heating
Full-surface grill
Grill settings:
1 = low
2 = medium
3 = high
Hot air grilling
Top/bottom heating
Other functions
This is where you can find an overview of other functions on the function selector or in the menu of your appliance.
Symbol Function
Rapid heating
Lighting
4.4 Temperature and setting levels
There are different settings for the types of heating and functions.
Note: For temperature settings above 250 °C, the appliance reduces the temperature to approx. 240 °C after ap-
prox. 10 minutes. If your appliance has the top/bottom heating or bottom heating types, this temperature reduction
does not take place there.
Symbol Function
Zero setting
50 - 275 Temperature range
1, 2, 3 Grill settings
or
I, II, III
Heat-up indicator
The appliance indicates when it is heating up.
When the appliance is heating, the ⁠ symbol lights up
on the display. This symbol goes out when heating is
paused.
What it's used for and how it works
Cook selected dishes gently on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back
wall evenly around the cooking compartment.
The food is cooked in phases using residual heat. Always keep the appliance
door closed when cooking. If you open the appliance door even briefly, the ap-
pliance will continue to heat without utilising any residual heat.
Select a temperature between 120 °C and 230 °C.
This type of heating is used to determine the energy consumption in air recircu-
lation mode and the energy efficiency class.
Cook pizza or food that requires a lot of heat from below.
The bottom heating element and the ring heating element in the back wall heat
the cooking compartment.
Final baking or cook food in a bain marie.
The heat is emitted from below.
Grill flat items such as vegetables and sausages, or make toast. Gratinate food.
The entire area below the grill element becomes hot.
Roast poultry, whole fish or larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the
hot air around the food.
Traditionally bake or roast on one level. This type of heating is especially good
for cakes with moist toppings.
The heat is emitted evenly from above and below.
This type of heating is used to measure the energy consumption in the conven-
tional mode.
Use
Rapidly preheat the cooking compartment without accessories.
→ "Rapid heating", Page 10
Light up the cooking compartment without heating.
→ "Lighting", Page 8
Use
The appliance is not heating up.
Set the temperature in the cooking compartment in °C.
Set the grill settings for Full-surface grill
1 = low
2 = medium
3 = high
Familiarising yourself with your appliance en
When you preheat the appliance, the optimal time to
place your food in the cooking compartment is when
the symbol first goes out.
Note: Due to thermal inertia, the temperature displayed
may differ slightly from the actual temperature inside
the cooking compartment.
