Call & Panic Buttons for this System...continued
1115 Pendant & Wrist Strap panic button
The 1115 panic button is a battery powered unit that, as standard, will
send a panic signal to the radio receiver. This unit can be programed
to send a less urgent 'Call' alert if required. Please contact Call Aid UK
for more details.
Cancelling at source
To cancel a panic call, please press and hold until the green lamp
starts blinking (For three seconds). The alert will now have been cleared from the receiver.
Low battery warning
When a panic button is pressed and the battery is low, a low battery signal will be sent to the
master receiver. The message can only be removed by changing the battery in the 1115 panic
button and then triggering & cancelling the alert. This function will not work while the system is
in 'Silent Test' mode.
The battery type is: CR2032
Changing the battery
The CR2032 button cell will power this call button for many months (depending on usage). To
change the battery, remove the screw on the rear of the housing. Pull the rubber holder away
from the housing to allow purchase on the edge of the housing to separate the two halves.
The battery can be lifted out of its holder. Replace with a new battery.
To reassemble, ensure that the rubber strap holder is correctly fitted to the back half of the
housing before placing the other half in position. A gentle squeeze should bring the two halves
together. Refit the screw (Do not over tighten as damage may result), refit the strap or lanyard.
Wall mounted assist/panic button
These wall units have two buttons. Pressing the GREEN button will send an
assist call signal to the 1142 master which will display the identity of the call
ASSIST PANIC
and a low level audio alert. Pressing the RED button on the wall unit will
send a high level alert to the 1142 master.
The labels in the buttons will vary depending on the application or usage.
Cancelling at source
both buttons. The reassurance lights will stop
To cancel an alert at the call unit press and hold
flashing and the alert will have cleared from the 1142 master panel.
