1142 Radio Portable Manual - O&M Manual V6
1142RX Portable
Radio Duress Alarm System
Operation & Maintenance Manual
Call Aid UK Ltd,
Unit 5 Factory Lane,
Beeston,
Nottingham, UK
NG9 4AA
Tel: 0115 940 0905
sales@callaiduk.com
www.callaiduk.com
MANU/A6993
Z:\AA MANUALS & INSTRUCTIONS 2017\1142 Radio System\1142 Radio Portable Manual - O&M Manual V6.docx
Page
1 of 20

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1142RX and is the answer not in the manual?

Questions and answers

Related Manuals for Call Aid UK 1142RX

Summary of Contents for Call Aid UK 1142RX

  • Page 1 1142 Radio Portable Manual - O&M Manual V6 1142RX Portable Radio Duress Alarm System Operation & Maintenance Manual Call Aid UK Ltd, Unit 5 Factory Lane, Beeston, Nottingham, UK NG9 4AA Tel: 0115 940 0905 sales@callaiduk.com www.callaiduk.com MANU/A6993 Z:\AA MANUALS & INSTRUCTIONS 2017\1142 Radio System\1142 Radio Portable Manual - O&M Manual V6.docx...

  • Page 2: System Overview

    OLED display. An audible alert will be activated, which will vary depending on the alert type i.e. Call & Panic or Call & Assist. If there is more than one Call alert on the system, the 1142RX display will scroll through the incoming calls.
  • Page 3 1142 Radio Portable Manual - O&M Manual V6 Call Aid UK - 1142 radio Basic 1122 Alarm System Battery 240 volt socket charger 1142RX Portable Master Display Panel PAN IC PAN IC PAN IC PAN IC Z:\AA MANUALS & INSTRUCTIONS 2017\1142 Radio System\1142 Radio Portable Manual - O&M Manual V6.docx...
  • Page 4 1142 Radio Portable Manual - O&M Manual V6 Call & Panic Buttons for this System 1122 Portable Call alert button The portable Call alert buttons are supplied with two buttons, pressing the ‘Panic’ button will trigger a ‘PANIC’ alert on the system. Pressing the ‘Call’ button will trigger a less urgent ‘Call’ alert on the system.
  • Page 5 1142 Radio Portable Manual - O&M Manual V6 Changing the batteries The batteries will last a long time as the portable unit only uses battery power for a short time when the button is pressed. To access the batteries remove the small screw on the rear of the portable Call alert button and replace the old battery with the new one.
  • Page 6 The 1115 panic button is a battery powered unit that, as standard, will send a panic signal to the radio receiver. This unit can be programed to send a less urgent ‘Call’ alert if required. Please contact Call Aid UK for more details.
  • Page 7 PANIC PANIC to press. When either buttons is pressed a Call alert is sent to the 1142RX master. There is a red lamp mounted on the side facing out as a reassurance lamp to be seen by the operator. When installing this unit ensure that the dimples are nearest to the operator.
  • Page 8 Press one of the buttons on the Call alert button. Check the value that is on the 1142RX display. A value ranging from 200 – 45 will be displayed Z:\AA MANUALS & INSTRUCTIONS 2017\1142 Radio System\1142 Radio Portable Manual - O&M Manual V6.docx...
  • Page 9 1142 Radio Portable Manual - O&M Manual V6 on the 1142RX master. The higher the better but a minimum of 55 is recommended to give a reliable signal. To cancel each call press both buttons at the same time on the transmitter unit.
  • Page 10 Cancel : Panel Night M: (_Global/_Local) PPB Mode (Fixed/Locate) Mute Time (0-600 Seconds) Relay : (Toggle/Latch) End Menu 1142RX Engineer’s Menu - Overview Z:\AA MANUALS & INSTRUCTIONS 2017\1142 Radio System\1142 Radio Portable Manual - O&M Manual V6.docx Page 10 of 20...
  • Page 11 1142RX units or when they share a common RS485 loop. At manufacturing, the default setting is ‘01’ unless previously requested before dispatch. Display No (Display ID) This ID is used to give the display panel a unique ID. This is set by Call Aid UK at • manufacture and should not be changed Cancel via Source/Panel (Cancel Method) •...
  • Page 12 Relay (Output Type) • The 1142RX has an output that can be used with the CAUK 1132 Relay PCB. This output can be used to control external sounders or interface with third party systems. • The latch option should be used with Beacon Sounders and third party systems equipment.

  • Page 13: Installation

    1142 Radio Portable Manual - O&M Manual V6 1150 Radio Panic button Opening the 1150 Case To open the case please use a small screw driver inserted at the bottom of the buttons. Now apply a little pressure and ease the buttons out from the bottom.
  • Page 14 1142 Radio Portable Manual - O&M Manual V6 1124 Radio ceiling pull switch The Radio ceiling pull switch is a battery powered call unit that will transmit a signal to a receiver. The signal can be set either as a call (low level call) or a panic (high level call). Installing the 1124 The 1124 are supplied with a standard single gang surface back box unless specified.
  • Page 15 1142 Radio Portable Manual - O&M Manual V6 Setting the call level The 1124 can send two levels of call either Call (Low level assistance) or Panic (High level panic) these functions will be available depending on the type of the receiver fitted.
  • Page 16 1142 Radio Portable Manual - O&M Manual V6 1123 Radio Signal Repeater Z:\AA MANUALS & INSTRUCTIONS 2017\1142 Radio System\1142 Radio Portable Manual - O&M Manual V6.docx Page 16 of 20...
  • Page 17 1142 Radio Portable Manual - O&M Manual V6 1123-IP65 Radio Stand Alone Repeater On the reverse of the 1123-IP65 Repeater there are few place for making holes that will allow the repeater unit to be screwed onto the wall. Before the repeater is screwed to the wall, test that all the Call alert button signals are reaching the 1123 Repeater in the position on the wall where it is to be used.
  • Page 18 1142 Radio Portable Manual - O&M Manual V6 The 1123 Pairing over door lamp panic alarm system The 1123 Radio Over Door Lamp is used to alert staff to any panic buttons that have been activated in the vicinity. All Call Aid panic buttons that are to be used with this Over Door Lamp will need to be paired. Please refer to the pairing instructions.
  • Page 19 1142 Radio Portable Manual - O&M Manual V6 Pairing remote radio products to the 1123 over door lamp When the panic buttons are dispatched with the 1123 Over Door Lamp system they are already “paired” to that Over Door Lamp. The 1123 can store in its memory up to five remote units such as radio pendants, portable panic button, ceiling mounted pull switches and radio wall units.
  • Page 20 1142 Radio Portable Manual - O&M Manual V6 Exiting the setup mode is done by pressing and holding the two buttons until all four lamps circle to end this function. Right Mini Left Mini button button Please note: The pairing mode times out after five minutes.
  • Page 21 1142 Radio Portable Manual - O&M Manual V6 When the Global over door lamp detects a low battery when any call/panic unit is triggered, a low battery warning is stored. When the system is idle, the Global over door lamp will flash and beep every 5 minutes to warn the users.
