Montage
Montage
Montaggio
Montaje
Installation
CH:
1/2"
1/2"
Montage des Anschlages
Montage de la butée
Montaggio del fermo
Montaje det tope
Installation of movement limiter
Inbetriebsetzung
Mise en service
Messa in funzione
Puesta en servicio
Initial operation
1
ø35mm /
1 3/8"
S36
USA/CAN
EU:
1/2"
1/2"
c
c =
750 mm, 29 1/2"
d =
500 mm, 19 1/2"
d
D spülen
2
F rincer
I sciacquate
Sp enjuagar
E flush
EU/AUS
3
ø35mm /
1 3/8"
S36
Radius min.
= 50mm / 2"
Verlängerungsmutter L= 40mm
Ecrou allongé L= 40mm
Dado prolungato L= 40mm
Tuerca de prolongación L= 40mm
Z.503.315
Extension nut L= 40mm / 1 1/2"
1/2"
1/2"
3
ø36mm /
1 7/16"
