Pentax WG-1000 Quick Start Manual

Model: R08040
Quick Start Guide
快速入門指引
퀵 스타트 가이드
คู ่ ม ื อ เริ ่ ม ต้ น ใช้ ง านฉบั บ ย่ อ
Panduan mulai cepat
For the detailed user guide, please refer to the HP address below to
download the "Operating Manual" (PDF Version).
關於本產品的詳細使用方法，請参閱以下 HP 位址下載本產品 [用戶手冊]
（PDF版本）。
자세한 사용 설명서는 아래의 HP 주소에서 "사용 설명서"(PDF 버전)를
다운로드하십시오.
https://www.ricoh-imaging.co.jp/english/support/download_manual.html
製造商： RICOH IMAGING COMAPNY, LTD.
日本東京都大田區中馬込1-3-6
台灣進口商： 富堃有限公司
台北市中正區開封街一段37 號8 樓
電話號碼:(02)2381-6132
Email：service@pentax.com.tw
RICOH IMAGING COMPANY, LTD.
1-3-6, Nakamagome, Ohta-ku, Tokyo 143-8555, JAPAN
(https://www.ricoh-imaging.co.jp)
RICOH IMAGING EUROPE S.A.S.
7-9, avenue Robert Schuman, 94150 RUNGIS, FRANCE
(https://www.ricoh-imaging.eu)
RICOH IMAGING AMERICAS CORPORATION
2 Gatehall Drive Suite 204, Parsippany, New Jersey 07054, U.S.A.
(https://www.us.ricoh-imaging.com)
RICOH IMAGING CANADA INC.
5560 Explorer Drive Suite 100, Mississauga, Ontario, L4W 5M3, CANADA
(https://www.ricoh-imaging.ca)
RICOH IMAGING CHINA CO., LTD.
Room A 23F Lansheng Building, 2-8 Huaihaizhong Road, Huangpu District,
Shanghai, 200021, CHINA
(http://www.ricoh-imaging.com.cn)
https://www.ricoh-imaging.co.jp/english
This contact information may change without notice. Please check the latest
information on our websites.
WG-1000
設備名稱：數位相機 型號（型式）：R08040
Equipment name Type designation (Type)
限用物質及其化學符號
Restricted substances and its chemical symbols
單元
六價鉻 多溴聯苯
鉛
汞 鎘
Ｕnit
Hexavalent Polybrominated Polybrominated
Lead Mercury Cadmium
chromium biphenyls diphenyl ethers
(Pb ) (Hg) (Cd)
(Cr+6) (PBB)
外殼
－ －
電路板
液晶顯示器
零件
結構零件
－ －
電池零件
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含
量基準值。
Note 1: "Exceeding 0.1 wt %" and "exceeding 0.01 wt %" indicate that the percentage
content of the restricted substance exceeds the reference percentage value of
presence condition.
備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: "O" indicates that the percentage content of the restricted substance does not
exceed the percentage of reference value of presence.
備考3.〝－〞係指該項限用物質為排除項目。
－
Note 3：The " " indicates that the restricted substance corresponds to the exemption.
D-PA180
型號（型式）：DSA-5PFU1-05 FCA 050100C
設備名稱：交換式電源供應器
Equipment name Type designation (Type)
限用物質及其化學符號
Restricted substances and its chemical symbols
單元
六價鉻 多溴聯苯
鉛 汞 鎘
Ｕnit
Hexavalent Polybrominated Polybrominated
Mercury
Lead Cadmium
chromium biphenyls diphenyl ethers
(Hg)
(Pb ) (Cd)
(Cr+6) (PBB)
外殼
線材
電路板
散熱片
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含
量基準值。
Note 1: "Exceeding 0.1 wt %" and "exceeding 0.01 wt %" indicate that the percentage
content of the restricted substance exceeds the reference percentage value of
presence condition.
備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: "O" indicates that the percentage content of the restricted substance does not
exceed the percentage of reference value of presence.
備考3.〝－〞係指該項限用物質為排除項目。
－
Note 3：The " " indicates that the restricted substance corresponds to the exemption.
茲切結保證所提供之商品限用物質含有情況標示內容係經執行測試作業或採適當之品質
管理措施，並備置前述相關文件，確認正確無誤後提供貴局。並同意配合貴局執行後市
場管理作業所需，依商品檢驗法第49條之規定，於限期28個工作天內提供相關證明文
件以供審查。
I hereby ensure that "the presence conditions of the restricted substance" provided
above have been proved by testing or appropriate quality control measures, and make
sure the relevant documents provided are correct and ready. Also, I agree to cooperate
with BSMI, as the Article 49 of the Commodity Inspection Act stipulates, to provide
the relevant documents, if needed, for verification within 28 working days when BSMI
carries out the market surveillance activities.
202401 Copyright © RICOH IMAGING COMPANY, LTD. 2024
CR503081699-0 Printed in China
GETTING STARTED
Accessories Included
1
1 2
6 7
Camera Views
2
6
5
4
3
2
1
Inserting the Battery & SD Card
3
2
3
1
Charging the Battery
4
Installation
1
Only use the dedicated
battery charger for
charging the battery.
Installing Silicone Case
5
多溴二苯醚
Attaching the Carabiner Strap
6
(PBDE)
Set your Language, Date/Time
7
Language
Español
Português
Italiano
Deutsch
English
Français Svenska
多溴二苯醚
(PBDE)
BASIC OPERATION
3 4
8 9
7 8 9 10 11 12 13 14 15 16
2
1
USB Power Adapter
4
Power Outlet
2
PENTAX WG-1000
USB Cable
Date & Time
H - M
. . :
2024 01 01 00 00
GETTING STARTED
1
5
10
2
17
18 21
22
19
20
25 23
26
24
27
1
2
Inserting the Battery and the Memory Card
3
Removal
4
3
5
6
1
7
2
BASIC OPERATION
1
2
3
1
2
4
3
4
Quick Start Guide
Accessories Included
Your camera box should contain the camera model you
purchased along with the following accessories. If anything is
missing or appears to be damaged, please contact your retailer
first or our customer service center. (The Power plug of the
USB power adapter may be a little different in shape due to the
difference of countries or regions this type of cameras are sold
to, and are subject to matching the physical product).
1 Rechargeable lithium-ion 6 Strap
battery D-LI96
7 Carabiner strap
2 Power plug 8 Battery operating
manual
3 USB power adapter
4 USB cable 9 Quick start guide
5 Silicone case 10 Warranty card
Camera Views
1 Flash 14 Speaker
2 Lens 15 Power button
3 Strap attachment 16 Shutter button
4 Tripod socket 17 MODE button
5 Battery cover 18 Zoom button
6 Battery cover lock 19 Indicator lamp
lever
20 Movie button
7 HDMI micro output 21 DISP. button/Arrow button (Up)
terminal (Type D)
22 OK button
8 USB terminal 23 Flash button/Arrow button (Right)
9 Battery lock lever 24 Delete button/Self-timer button/
Arrow button (Down)
10 Card slot
11 AF assist light 25 Macro button/Arrow button (Left)
12 Microphone 26 Playback button
13 Monitor 27 MENU button
1. Push the Battery cover lock lever as shown in step ①, push
the battery cover as shown in step ② to open the battery
cover.
2. While checking the positive and negative of the battery, use
the side of the battery to release the battery lock lever in the
direction of the arrow to install the battery correctly.
3. Insert the memory card into the memory card slot as shown
in the figure, push exposed edge of the memory card fully
into the slot with your fingertip.
4. Close the battery cover as shown in step ① and slide the
battery cover as shown in step ②. Make sure that a red
mark appears on the battery cover lock lever and that the
battery cover is securely closed.
Charging the Battery
Before you charge your battery, make sure the camera is off
and the battery is inserted correctly.
1. Insert the Power plug to the USB power adapter as show in
❶.
2. Connect the camera to the USB power adapter using the
supplied USB cable as show in ❷, ❸.
3. Insert the Power plug into the wall outlet to charge the
battery as show in ❹.
※ During charging, the Indicator lamp lights orange and
displays [ Charging...] on the Monitor, and turns off after
5 seconds. You can press any button of your camera to
display [ Charging....]. When the charging is complete, the
Indicator lamp lights up green, [100%] is displayed on the
Monitor, and the camera turns off after 5 seconds.
Please charge the battery at least 4 hours for the first time
after purchase.
※ Only use the dedicated battery charger for charging the
battery.
Installing Silicone Case
To protect the main body, please confirm that the Silicone case
is clean, free of sand, dust, eg. or other foreign objects inside.
1. Thread the side with buttons protection of the Silicone case
through the strap attachment of the main body.
2. Match the shape of the main body's lens and pass the other
strap attachment part.
Attaching the Carabiner Strap
1. Pass the tip of the carabiner strap through the strap
attachment part of the main body as shown in the figure
and fix it to the fastener.
2. In order to prevent scratches when the carabiner strap and
the main body against each other, please adjust the position
of the rubber rings so that they do not influence each other.
Setting the Language/Date/Time
1. Press the Power button to turn the camera on and the
language menu will appear. Use the [ ]/[ ]/[
[ ] buttons to select desired language and press the
button to to confirm your language.
2. Use the [ ]/[ ]/[ ]/[ ] buttons again to set the
date and time and press the button to confirm.
Taking the Best Photos
1. Be sure to hold the camera securely.
2. Use the Zoom button to select Tele or Wide position to zoom
in or out on your subject(s).
3. Gently press the Shutter button half-way down to focus on
your subject (s). When the focus frame turns green, press
the Shutter button completely down to take your photo.
Using the MODE Button
This camera provides a convenient MODE button that allows
you to manually switch between different camera settings with
ease. Available modes are listed below:
Auto Mode Underwater Mode
Program AE
CALS Mode (※1)
※1 Records in a size suitable
Manual Mode
for electronic delivery
Movie Mode
in accordance with
construction CALS.
Scene Mode
Using the Movie Button
While in shooting mode, press the button to begin recording
a video. To stop recording, press the button again. The
camera's memory card will store the video and return to the
shooting screen.
Using the MENU Button
In each mode, press the menu button to access the "Easy
Menu". Press the [ ]/[ ] buttons to move between
options, then press the button to make a selection.
Choosing the within this list will provide access to the Full
Menu below:
Menu of Shooting Mode Menu of Playback Mode
Shoot Settings Playback Settings
General Settings General Settings
Connection Settings Connection Settings
File Settings File Settings
EN
]/
