1.
Installation
1.1
Preparation for installation
Take the device out of the packaging and inspect for damage.
A number of accessories can be found in the upper part of the packaging of the device:
• Connecting hose
• Renegite
• Safety booklet
Read the safety booklet.
At least you need the following:
• Electronic scales
• Two jugs (minimum 1 litre)
The installation procedure contains two calibration programs, flow and temperature.
Do not interrupt these programs.
The device heats the water twice to a set temperature, this will take some time.
Below is a time indication (the temperature variables of the tap water and the device are not included).
Heating during
calibration
230V
1
heating time
e
18 min.
(fig. 17 - 18)
2
heating time
nd
31 min.
(fig. 52 - 55)
1.2
Begin installation
The first program is a single state where you can set the user settings and execute temperature and flow calibration.
An operator / service engineer can configure all settings at once.
The standard boiler fill and heating control are disabled.
The next values are configured during the first start program (see page 2):
• Volume unit type*
• Temp unit type*
• Water filter flow threshold*
• Water filter age threshold*
• Descale threshold* (see also page 6)
• Cleaning threshold*
• Desired language*
• Actual date
• Actual time
You can use an RFID card to copy the settings*
(see page 2 fig. 3, this way you skip fig. 4 to 10).
After the setup, the calibration temperature and calibration
flow will start (see page 3 to 5).
SGH
SGL
400V
230V
400V
13 min.
13 min.
9 min.
29 min.
30 min.
28 min.
700.403.858 B
Original document by manufacturer
© 05-2019 VHH
TWH
230V
400V
230V
38 min.
28 min.
27 min.
53 min.
50 min.
51 min.
Buttons
With the buttons, you can navigate through the menus of
the machine.
1. Hold the M button 1 second to confirm a choice in a
menu level.
Press the M button briefly to proceed to the next menu
level.
2. LEFT/RIGHT button.
TWL
400V
20 min.
49 min.
M
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SGH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BRAVILOR BONAMAT SGH

  • Page 1 Installation Preparation for installation Take the device out of the packaging and inspect for damage. A number of accessories can be found in the upper part of the packaging of the device: • Connecting hose • Renegite • Safety booklet Read the safety booklet.
  • Page 2 first start enter place card language vol units temp units menu settings or press M [English} [ml/L] [°C] wfilter th wfilter th descale th cleaning th year month [0]0000 l [0]00 days [1]000 l [0] days [0]000 [0]0 See page 6 set day format time...
  • Page 3 calib flow filling temp place filter unit place empty jug start 85°C dispense place empty jug start brewer vol place empty jug start brewer vol calib flow [3]00 calib flow [4]50 Enter the Enter the weighted weighted quantity (g) quantity (g) place empty jug start brewer vol...
  • Page 4 calib cycle 2 place empty jug place container continue press HW tap release HW tap brewer vol @ HW tap calib flow [3]00 Enter the weighted quantity (g) ± 600 ml from hw-tap place empty jug place container continue press HW tap release HW tap brewer vol @ HW tap...
  • Page 5 place empty jug place container continue press HW tap release HW tap brewer vol @ HW tap calib flow [4]50 Enter the weighted quantity (g) calib temp place filter unit place container start filling temp calib temp 39°C filling filling 5.0 l Caution hot liquids Mild roast...
  • Page 6 Descale threshold 30 °dH 55 °TH 250 L. 66 Gal. 18 °dH 32 °TH 500 L. 132 Gal. 12 °dH 22 °TH 1000 L. 264 Gal. 8 °dH 15 °TH 1500 L. 396 Gal. 4 °dH 7 °TH 2000 L. 528 Gal.
