repeater retransmits Fast Ethernet transmissions from ports operating at
100Mbps to all other ports operating at the same speed.
100Mbps
Ethernet
Station
If there is a DFE-908x hub present in the stack, its built-in switch serves as
a bridge between the two independent segments.
4
100Mbps
10Mbps
10Mbps
Ethernet
Ethernet
Ethernet
Station
Station
Station
10Mbps Repeater
100Mbps Repeater
NWay Detection
RJ-45 Ports
100Mbps
Ethernet
Station
Introduction
