- Page 1 Wearable BT UHF Reader AZ-MR20 User Manual www.rfidlabel.com E-mail : sales@rfidlabel.com Tel : +86-131-3958-0585 https://...
-
Page 2: Table Of Contents
Content Chapter 1 Product intro ................. 3 1.1 Intro ......................3 1.2 Precaution before using battery ............4 1.3 Charger ....................5 1.4 Notes ......................6 Chapter 2 Installation instructions.............. 7 2.1 Appearance ................... 7 2.2 Battery charge ..................8 2.3 Buttons and function area display .......... -
Page 3: Chapter 1 Product Intro
Besides, this tiny device has the protection features like dustproof, waterproof, shockproof, and drop resistance. All these functions make the AZ-MR20 a most adaptable device in a wide spectrum of circumstances such as logistics & express delivery, retail store management, warehouse management,... -
Page 4: Precaution Before Using Battery
1.2 Precaution before using battery ➢ Do not leave battery unused for long time, no matter it is in device or inventory. If battery has been used for 6 months already, it should be check for charging function or it should be disposed correctly. -
Page 5: Charger
1.3 Charger The charger type is PWR-R2/R5/R6/MR20-5V2A-CN, output voltage/current is 5V DC/1.5A. The plug considered as disconnect device of adapter. -
Page 6: Notes
1.4 Notes Note: Using the incorrect type battery has danger of explosion. Please dispose the used battery according to instructions. Note: Due to the used enclosure material, the product shall only be connected to a USB Interface of version 2.0 or higher. The connection to so called power USB is prohibited. -
Page 7: Chapter 2 Installation Instructions
Chapter 2 Installation instructions 2.1 Appearance AZ-MR20 appearances are showing as follows: Indicating Lamps instruction Lamps Description Red lamp lights up constantly (charging status) Green lamp lights up constantly (battery fully charged) Power Blue lamp lights up constantly (battery level higher than... -
Page 8: Battery Charge
2.2 Battery charge By using USB contact, the original adaptor should be used for charging the device. Make sure not to use other adaptors to charge the device. -
Page 9: Buttons And Function Area Display
2.3 Buttons and function area display AZ-MR20 reader has 1 power button and 1 Type-C port, 1 SCAN button. -
Page 10: Chapter 3 Demo Test
Chapter 3 Demo Test 3.1 Install demo-uhf-bt (1.0.8) 1. Copy demo-uhf-bt (1.0.8) into internal storage of smart phone or C7x device. 2. Click to install. 3. Click icon to open demo. -
Page 11: Pairing Device
3.2 Pairing Device 1. Switch on Bluetooth function of smartphone or C7x device. 2. Power on AZ-MR20. 3. Click BLUETOOTH in the demo. 4. Click SEARCH to search for MAC of AZ-MR20. 5. Click the correct MAC to connect. - Page 12 6. After connecting successfully, user could click 3 dots on top right to check UHF version, battery percentage and UHF module temperature.
-
Page 13: Uhf Scan Function
3.3 UHF Scan Function 1. Click START in demo or pull the trigger on R6, the UHF tags could be read. 2. Click STOP in demo to stop reading of UHF tags. 3. Click CLEAR to clean all EPC information. -
Page 14: Uhf Configuration
3.4 UHF Configuration 1. Click CONFIG in demo to adjust working mode and output power. -
Page 15: Uhf Tag Reading And Writing
3.5 UHF Tag Reading and Writing 1. The storage of one tag has 4 zones: RESERVED, EPC, TID and USER. Normally, the default password is 00000000. And TID zone can only be read, other zones can be read and written. -
Page 16: Uhf Tag Lock And Kill
3.6 UHF Tag Lock and Kill 1. Lock Function: For example. User could try to lock down EPC zone. - Page 17 2. Kill Function: Kill function can be used to kill the tag permanently. Input the correct access password and click kill.
-
Page 18: Chapter 4 Device Characteristic
Chapter 4 Device characteristic Physical characteristics Size 50 × 62 × 19 mm / 1.97 × 2.44 × 0.75 in. Weight 64 g / 2.26 oz. ( with glove: 90 g / 3.17 oz. ) Color Yellow, Blue, Gray Appearance Plastic material Product... -
Page 19: Declaration
Declaration The simplified EU declaration of conformity referred to in Article 10(9) shall be provided as follows: Hereby, we declare that the radio equipment type UHF Sled Reader is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following.
