- Page 1 INSTALLATION AND OPERATING MANUAL SIMPLEX COMBO READER/READ HEAD MODEL 1880 Part No. 710-0005-00 MODEL 1880E Part No. 800-0006-00 Version 3/00...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION 1 - GENERAL INFORMATION 1.1 INTRODUCTION Page 3 1.2 DESCRIPTION Page 3 1.3 SPECIFICATIONS Page 4 SECTION 2 - INSTALLATION 2.1 INTRODUCTION Page 5 2.2 UNPACKING AND INSPECTION Page 5 2.3 INSTALLATION SUMMARY Page 5 2.4 POWER REQUIREMENTS Page 6 2.5 AC/DC POWER SELECTION Page 7... -
Page 3: Section 1 - General Information
GENERAL INFORMATION 1.1 INTRODUCTION This manual provides information pertaining to the installation and operation of the Model 1880 Combo Reader/Antenna, PCB only, (RFID, Inc. Part No. 710-0005-00) or Model 1880E (the E signifying enclosure) (RFID, Inc. Part No. 800-0006-00). 1.2 DESCRIPTION... -
Page 4: Specifications
1.3 SPECIFICATIONS Operating Frequency: 148 kHz +/-0.5% (transmit) 37 kHz (receive) Tag Reading Distance: Up to 18" (depending on Antenna, transponder and orientation) Remote Enable: 5 mA, Opto-isolated Signal Output: 75 ohms, balanced Cabling to Interface: Up to 5000 feet (with shielded twisted pair cable) Connectors: Angle entry terminal strips Antenna:... -
Page 5: Section 2 - Installation
If the shipping carton is damaged or shows evidence of abusive handling, inspect the Reader for visible damage including dents, scratches, etc. If the unit appears damaged, contact the carrier and RFID, Inc. Sales or Customer Service Departments immediately. Keep the shipping and packaging material for the carrier's inspection. -
Page 6: Power Requirements
Disabled: 30 mA (max.) RFID, Inc. can provide transformers and power supplies suitable for use with the Model 1880. If you provide your own power supply, it is recommended that you avoid switching power supplies. These supplies produce electromagnetic interference (EMI) that WILL interfere with the operation of the Combo Reader. -
Page 7: Ac/Dc Power Selection
AC/DC POWER SELECTION The Combo Reader contains an on-board bridge rectifier for conversion of floating AC power input to DC. For operation with DC input, this full-wave bridge can be bypassed with jumper J2. AC Operation - Select the full-wave bridge by removing shorting jumper J2 from the printed circuit board. -
Page 8: Signal Cabling
2 Conductor paired cable Belden 8761 #22 AWG w/foil shield Columbia C2514 Polyethylene & PVC Manhattan M13226 60 degrees C RFID, Inc. PN 214-2202-00 Signal and 4 Conductor paired cable Belden 8724 Remote Enable 1 pr. 22 AWG w/ foil shield Alpha 2464 1 pr. -
Page 9: Remote Enable Cabling
REMOTE ENABLE CABLING Combo Reader operation may be controlled from an Interface or remote unit via the enable inputs (EN, EN BAR) at TB2 locations 1 and 2. Disabling the Combo Reader shuts off the Antenna’s 148 kHz transmissions and reduces current draw to 30 mA (max). If the remote enable feature is not used, a shorting jumper must be placed across J1 and the EN/EN BAR inputs may be left unconnected. -
Page 10: External Interference
RFID, Inc. products are warranted against defects in materials and workmanship for one (1) year from date of shipment. RFID, Inc. shall, at its option, either repair or replace products that prove to be defective and are returned with freight prepaid to RFID, Inc.’s plant within the warranty period. The foregoing warranty shall not apply to defects resulting from abuse, misuse, accident, alteration, neglect or unauthorized repair or installation.
