  • Page 1 MIPI CSI-2 C LVIUM AMERAS Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1 Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2024-Jul-15...

  • Page 2: Read Before Use

    The product can have sharp edges. Intended use Intended use of Allied Vision product is the integration into vision systems by professionals. All Allied Vision product is sold in a B2B setting. Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 3 Fare for skarpe kanter Produktet kan have skarpe kanter. Tilsigtet brug Allied Vision produktets tilsigtede brug er en indbygning i et visionssystem, udført af fagfolk. Alle Allied Vision produkter sælges i B2B. Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 4 Schnitte durch scharfe Kanten Das Produkt kann scharfe Kanten haben. Bestimmungsgemäßer Gebrauch Allied Vision Produkte sind bestimmt für die Integration in Bildverarbeitungs- systeme durch Fachpersonal. Alle Allied Vision Produkte werden in einer B2B-Umgebung verkauft. Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 5 Riesgo de cortes por bordes afilados El producto puede tener bordes afilados. Uso previsto El uso previsto del producto Allied Vision es la integración en el sistema de visión por parte de profesionales. Todos los productos Allied Vision se venden dentro de una relación B2B.
  • Page 6 Käytössä olevan tuotteen saavuttamat lämpötilatasot voivat aiheuttaa palovammoja. HUOMIO Terävien reunojen aiheuttama viiltovaara Tuotteessa voi olla teräviä reunoja. Käyttötarkoitus Allied Vision -tuotteen käyttötarkoitus on integrointi kuvajärjestelmiin ammattilaisten toimesta. Kaikki Allied Vision -tuotteet myydään B2B-ympäristössä. Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 7 Utilisation prévue L’utilisation prévue du produit Allied Vision est son intégration dans des systèmes de vision par le soin de professionnels. Tout produit Allied Vision est vendu dans un cadre B2B. Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 8 Read before use ‫ת‬ ‫י ר‬ ‫ב ע‬ HE - ‫ת‬ ‫ו ח‬ ‫י ט‬ ‫ב‬ ‫. ד‬ ‫י מ‬ ‫ת‬ ‫ו‬ ‫ל א‬ ‫ן ו ח‬ ‫ט‬ ‫י ב‬ ‫ת ו‬ ‫א ר‬ ‫ו ה‬ ‫ש‬ ‫מ‬ ‫מ ל‬ ‫ך‬...
  • Page 9 Pericolo di tagliarsi sui bordi affilati I bordi del prodotto lente possono essere affilati. Uso previsto Il prodotto Allied Vision è concepito per essere integrato in sistemi di monitoraggio in campo professionale. Tutti i prodotti Allied Vision sono venduti in uno scenario B2B.
  • Page 10 Read before use JA - 日本語 安全性 本製品を使用する前に、この安全ガイドをお読みください。警告を必ず 守ってください。必ず21ページのIntended use 23 ページに従って使用し てください。 注意 やけどの危険性 作動中のカメラは、やけどを引き起こす温度まで熱くなる恐れがありま す。 注意 な端部で切り傷の危険性 本製品には鋭利な部分がある場合があります。 用途 Allied Vision製品は、専門家が視覚装置に統合することを意図したもの です。すべてのAllied Vision製品は、企業間取り引き用に販売されてい ます。 Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 11 Risico van snijwonden door scherpe randen Het product kan scherpe randen hebben. Beoogd gebruik Het beoogde gebruik van het Allied Vision-product is de integratie in optische systemen door professionals. Alle Allied Vision-producten worden verkocht in de B2B-markt. Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 12 Risiko for kutt fra skarpe kanter Produktet kan ha skarpe kanter. Tiltenkt bruk Den tiltenkte bruken av Allied Vision-produktet er integrering i visjonssystemer av profesjonelle. Alle Allied Vision-produkter selges i en forretning til forretning-situasjon. Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 13 Risk för skärsår från vassa kanter Produkten kan ha vassa kanter. Avsedd användning Den avsedda användningen av Allied Vision-produkter är integrering i visionssystem av fackmän. Samtliga Allied Vision-produkter säljs i en B2B-miljö. Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 14 Read before use ZH - 简体中文版 安全需知 在使用产品之前，请阅读这些安全说明。请务必遵守相关警告 和 Intended 于第 23 页 . 注意事项 烫伤风险 在产品运行过程中，温度可能会上升，导致烧伤的危险。 注意事项 锋利边缘割伤的风险 产品可能有锋利的边缘。 预期用途 Allied Vision 产品的预期用途是由专业人士整合到视觉系统中。所有 Allied Vision 的产品均通过 B2B 渠道销售。 Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...

  • Page 15: This Document At A Glance

    • For all information about Alvium CSI-2 cameras and accessories, see www.alliedvision.com/en/support/ technical-documentation/alvium-csi-2-documentation. • Please contact your Allied Vision Sales representative for ordering and for additional information on hardware options for Alvium cameras. Technical information on Toradex embedded boards For information on Toradex embedded boards, see www.toradex.com.

  • Page 16: Contact Us

    Exton, PA 19341, USA Toll-free// +1-877-USA-1394 T// +1 978 225 2030 Asia-Pacific China Japan Allied Vision Technologies Shanghai Co Ltd. Allied Vision Technologies B-510, Venture International Business Park Yokohama Portside Bldg. 10F 2679 Hechuan Road 8-1 Sakae-cho, Kanagawa-ku Minhang District, Shanghai 201103...

  • Page 17: Table Of Contents

    Contents Contents Read before use ..............2 This document at a glance .
  • Page 18 Contents Installing adapter boards ..............37 Connecting the FFC.

  • Page 19: Document History And Conventions

    Document history and conventions This chapter includes: Document history ..............20 Conventions used in this user guide........20 Component naming .............. 21 Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...

  • Page 20: Document History

    Document history and conventions Document history Version Date Remarks V1.1.1 2024-Jul-15 Updated addresses in Contact us on page 16. V1.1.0 2024-Mar-14 • Added Read before use on page 2. • Added UKCA symbol in Compliance notifications on page 23. • Added Sharp edges on page 24.

  • Page 21: Symbols And Notes

    Document history and conventions Symbols and notes CAUTION Risk of burns Precautions are described NOTICE Material damage Precautions are described. Practical tip Additional information helps to understand or ease handling the camera and components. Additional information Web link or reference to an external source with more information is shown. Component naming Components described in this user guide are not defined by common standards.

  • Page 22: Compliance, Safety, And Intended Use

    Compliance, safety, and intended use This chapter includes: Compliance notifications ............23 Intended use ................. 23 Copyright and trademarks ............ 23 Your safety................24 Product safety ............... 24 Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...

  • Page 23: Compliance Notifications

    We are offering standard products as well as customized solutions. Intended use of Allied Vision product is the integration into Vision systems by professionals. All Allied Vision product is sold in a B2B setting.

  • Page 24: Your Safety

    Compliance, safety, and intended use Your safety This section informs about issues related to your personal safety. Descriptions explain how to avoid hazards and use adapter boards safely. Handling hot adapter boards Electrical components of adapter boards get hot during operation. Before operation, include adapter boards in housings that disable any contact to hot components.

  • Page 25: Camera Power

    Compliance, safety, and intended use • Wrist strap: Wear a static-dissipative wrist strap to ground your body. • Clothing: Wear ESD-protective clothing. Keep components away from your body and clothing. Even if you are wearing a wrist strap, your body is grounded but your clothes are not.
  • Page 26 MIPI CSI-2 FPC cables Manufacturing FPC cables or embedded boards If you want to design your own components to connect Alvium CSI-2 cameras to embedded boards, contact your Allied Vision Sales representative or visit www.alliedvision.com/en/about-us/contact-us/technical-support-repair-/-rma. FPC cable position Short circuits of the FPC cable can damage the camera or connected hardware.

  • Page 27: I/O Connections

    Compliance, safety, and intended use I/O connections Through the adapter board, the camera connects to the embedded board. To reduce signal latencies, I/O cables can be connected directly to the adapter board. This includes soldering. • Do soldering only if you have sufficient working knowledge. •...

  • Page 28: Specifications

    Specifications This chapter includes: Specifications ................ 29 Dimensions and PCB layout ..........30 Electronic schematics ............31 Camera power............... 33 I/O connections..............33 Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...

  • Page 29: Specifications

    Supported cameras Alvium CSI-2 cameras Supported FPC cables for camera connections Allied Vision 12316, 12317, 12318 Table 4: Adapter for Toradex Ixora specifications PCB and PCBA number The PCB number is printed on the backside, the PCBA number is placed anywhere...

  • Page 30: Dimensions And Pcb Layout

    Specifications Dimensions and PCB layout 36.6 mm 24 mm M2.5 M2.5 Figure 3: Adapter for Toradex Ixora dimensions and PCB layout Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...

  • Page 31: Electronic Schematics

    Specifications Electronic schematics To Alvium cameras GREEN GND VCC-CAM VCC-EXT-IN FAUL T ESD9B5.0ST5G EXT -GPIO0-I2C-SCL (EP)GND ILIM 270k EXT -GPIO1-I2C-SDA TPS25200DR VT V in: 2.5V -6.5V EXT -GPIO2 100n I max: 2.5A EXT -GPIO3 B7-CSI2-TXD3_N 100 Ohm B7-CSI2-TXD3_P 100 Ohm B7-CSI2-TXD2_N 100 Ohm Imin = 1752 mA...
  • Page 32 Specifications Damage to the camera power supply We recommend you to power Alvium cameras using the USB connector J5. camera. VCC-EXT-IN: DCIN 4V5 .. 5V5, max. 1.5 A External USB power External power Note: J4 is not equipped. VCC-EXT -IN VCC-EXT -IN CON1x2 USB 2.0 TYPE B 90°...

  • Page 33: Camera Power

    Specifications Camera power NOTICE Damage to power supplies If power supplies do not provide sufficient current, they may be damaged. Ensure USB power supplies provide 1.5 A. Power Alvium cameras using the USB 2.0 Micro B receptacle (J5). See the description in Figure 5, Adapter for Toradex Ixora electronic schematics, part 2 page 32.

  • Page 34: Using The Adapter Board

    Using the adapter board This chapter includes: Embedded system accessories ..........35 Connecting FPC cables to Hirose FPC connectors ....35 Installing adapter boards ............37 Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...

  • Page 35: Embedded System Accessories

    Designing your own embedded components If you want to design your own components to connect Alvium CSI-2 cameras to embedded boards, contact your Allied Vision Sales representative or visit www.alliedvision.com/en/about-us/contact-us/technical-support-repair-/-rma. Proper usage of the Hirose FH55-22S-0.5SH FPC connector is vital for connecting Alvium CSI-2 cameras to embedded boards.
  • Page 36 Using the adapter board NOTICE Damage to the camera by reverse polarity If Alvium CSI-2 cameras are powered with reverse polarity, camera electronics is damaged. • Before connecting camera power and I/O power, carefully read the Alvium Cameras User Guide for the FPC connector pin assignment. •...

  • Page 37: Installing Adapter Boards

    Using the adapter board Installing adapter boards CAUTION Burns to the skin Electrical components get hot during operation. Before operation, include adapter boards in housings that disable any contact to hot components. NOTICE Damage to electronics • Disconnect all power supplies before installing the adapter board to your embedded board.

  • Page 38: Connecting The Ffc

    Using the adapter board Connecting the FFC 1. With the conductors (a) facing the PCB of the adapter board,... Adapter board Embedded board Figure 11: Inserting the FFC ...connect the FFC to the embedded board connector (b) of the adapter board. Figure 12: Embedded board connector of the adapter board Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...

  • Page 39: Connecting The Embedded Board

    Using the adapter board Connecting the embedded board 1. With the conductors (c) facing the PCB of the embedded board... Adapter board Embedded board Figure 13: Inserting the FFC ...connect the FFC to the camera connector of the embedded board. Connecting the camera 1.

  • Page 40: Connecting Usb Power

    Using the adapter board Connecting USB power We recommend you to power the camera using USB power. NOTICE Damage to power supplies If power supplies do not provide sufficient current, they may be damaged. Ensure USB power supplies provide 1.5 A. 1.

  • Page 41: Connecting The I/Os

    Using the adapter board Connecting the I/Os If you want to use the I/O lines of the embedded board, see I/O connections page 33. This way, you can use the I/Os immediately. If you want to use the I/O lines of the adapter board, see the following instruction. This way, you reduce signal latencies, such as for triggering the camera by a light barrier About this instruction...
  • Page 42 Using the adapter board 3. Connect GND to pin 2 (i) on connector J4. Figure 17: Connecting GND 4. On the pin header (h), use the I/O pins defined in I/O signal levels and description on page 43. Figure 18: Connecting the I/Os Adapter Board for Toradex Ixora Carrier Board User Guide V1.1.1...
  • Page 43 Using the adapter board I/O signal levels and description Table displays the signals for the GPIOs on connector J2, for GND on connector J4, and for VCC-EXT-IN on the USB connector J5. Connector Signal < - > Level Description EXT-GPIO2 IN/OUT (low) = -0.3 to 0.8 VDC GPIO...
