- Page 1 Zhangjiagang Medi Medical Equipment Co.ltd. www.medik-medical.com YA-D5-11 User Manual Electric ICU Bed since 1995...
- Page 2 COMPANY PROFILE Profession with years experience! Always alleviating medical staff's workload. Always improving patient's safety and comfort. Always minimizing the medical incident. Zhangjiagang medi medical equipment co.,ltd, founded in 1995, with more than 20 years experience in developing hospital furniture, is one of the largest manufacturer of hospital bed, patient stretcher, medical cart and other related hospital furniture in china or even asia.
-
Page 3: Table Of Contents
OVERVIEW Table of contents General Attentions .....................3 Safety........................4 Proper Use and Application..................5 Introduction .......................6 Description of Parts ....................7 Technical Data ......................8 Transport and Unpacking...................9 Installation and First Use ..................10 Evaluation Criteria ....................11 Application of Product’s Function ................12 Central Brake System ....................13 Electric control ......................14 Bed Positioning......................15 Battery........................16... -
Page 4: General Attentions
1 GENERAL ATTENTIONS Dear Clients Great appreciation to you for choosing this bed from our company, we wish you would find much satisfaction while using it. Please read this manual carefully, in which includes all the significant information and Attentions to guide proper installation and operation of the product as well as its servicing. -
Page 5: Safety 2
SAFETY 2 The structure of the product assures its safe operation on condition that the rules comprised in this manual are followed. Prior to use, the user should read all following safety introduction and check all bed’ s functions item by item according to this manual. -
Page 6: Proper Use And Application
3 PROPER USE & APPLICATION Application YA-D5-11 hospital electrical bed is designed for mid to high acuity patients population. General requirements The bed should only be used in an internal environment where: The ambient temperature ranges from +10°C to +40°C(Ambient temperature change range is less than 20℃... -
Page 7: Introduction 4
INTRODUCTION 4 YA-D5-11 hospital electrical bed is designed and manufactured by Zhangjiagang Medi Medical Equipment Co., Ltd., which can be used in several kinds of ICU ward. It also can be applied to top grade ward, VIP ward as well as healing ward due to its multifarious functions and adaptability. -
Page 8: Description Of Parts
5 DESCRIPTION OF PARTS Segments 9 10 Description Description Back side rail Handle for mechanic CPR quick release (Side rail close to head board) Exterior control on the back side rail 125mm casters Head board Angle indicator on the back side rail Interior control on the back side rail Bed surface Mattress stopper... -
Page 9: Technical Data
TECHNICAL DATA Mechanical and operating parameters Parameters Description YA-D5-11 Length×Width 2000×900 mm Overall Length×Width 2200mm x 990mm Maximum height 770 mm Minimum height 420 mm Angle of backrest adjust 75°±5° Angle of Thighrest adjust 35°±5° Back CPR Manual and Electric... -
Page 10: Transport And Unpacking
7 TRANSPORT AND UNPACKING Transport There is a possibility to transport the product by any covered transport means, it can be transported by highway, railway, waterway, and air transportation. While transporting, it is necessary to immobilize the truck and protect it against water and moisture. The transport conditions are as follows: Parameters Description Temperature... -
Page 11: Installation And First Use
INSTALLATION & FIRST USE 8 Caution All electric devices connected directly with the patient should be connected with potential Place the bed in the needed equalization installation. working room. In case of potential equalization installation lack in Block castor lock lever. the bed installation place these devices should be connected by means of potential equalization wire with potential equalization socket in the bed... -
Page 12: Evaluation Criteria
9 EVALUATION CRITERIA Caution Correctness of bed functioning shall be checked before the first start up. The method of checking whether the functioning of the bed is correct: Check stability of the bed when its wheels are locked by trying to move the bed manually: pushing the bed should not cause tilting or moving in any direction. -
Page 13: Application Of Product's Function 10
APPLICATION OF PRODUCT’S FUNCTION 10 Bed height adjustment The pallets can be vertically adjusted between 420mm and 770mm. Bed’s angle inclination (Trendelenburg and Anti-Trendelenburg position) The bed can be tilted to Trendelenburg or Anti-Trendelenburg position in 12°. The Reverse-trendelenburg one can provide better drainage for the patient after operation, while the Trendelenburg can heighten the quantum of the blood supplies to the heart and brain. -
Page 14: Central Brake System
11 CENTRAL BRAKE SYSTEM The bed is equipped with a caster lock lever, by which the caster can be locked and unlocked with one motion. The bed is also equipped with fifth castor allowing easier movement of the bed in narrow spaces, such as passing in and out the lift, entering and leaving the ward etc. The central braking lever can be set to two positions: Lock... -
Page 15: Electric Control 12
ELECTRIC CONTROL 12 The electric control on the bed includes Exterior electric control on Back side rail (see 12.1) Interior electric control on Back side rail (see 12.2) Handset control (see 12.3) 11.1 Exterior electric control on Back side rail The main control for caregiver is incorporated on the exterior side of the Back side rail(Close to the head board),Main functions of the electric control: Back section adjustment... -
Page 16: Bed Positioning
13 BED POSITIONING Adjustment angle of backrest: 0 - 75°±5° Adjustment angle of knee: 0 - 35°±5° HI-LO: 42 - 77cm Trendelenburg and Reverse Trendelenburg 0 to 12°±2° Mechanic CPR: by Mechanical Levers located on each side of the bed, in a single step to perform CPR procedures Electric CPR via a single button on the handset control Caution... -
Page 17: Battery 14
BATTERY 14 The battery is integrated in the control box as support in case of power failure. -
Page 18: X-Ray Examination(Optional)
15 X-RAY EXAMINATION (OPTIONAL) The X-ray cassette holder tray can be inserted below the back section Safe locker X-ray fluoroscopy plate... -
Page 19: Cpr & Emergency Stop 16
CPR & EMERGENCY STOP 16 Pull CPR handle outward, the backrest will quickly return to horizontal position. Emergency Stop Caution CPR is essential for patient’ s reanimation. Caregivers must regularly check whether CPR is out of work. It’ s very important to report to the manufacturer if it is found out of work. Caregivers will be responsible for all the results caused by not finding or not reporting to the manufacturer that CPR mechanism is out of work. -
Page 20: Side Rail
17 SIDE RAIL SEGMENT SIDE-RAIL: Fold down the side rail The guardrail needs to be lifted slightly, and then the button can be pulled down to lower the guardrail. If the guardrail is not raised slightly, the guardrail will not be lowered (this design prevents the patient from lowering the guardrail from the inside of the bed). -
Page 21: Head/Foot Board 18
HEAD/FOOT BOARD 18 As shown in figure, head board /foot board is easily installed and removed by the screw . When installing and knocking down the head board /feet board, please energize symmetrically. -
Page 22: Accessory Assembly And Use
19 ACCESSORY ASSEMBL Y & USE IV Stand There are four IV stand sockets in the corners. IV Stand There are 2 hooks on each side of bed, total is 4. Winder When the power cord is not in use, it can be coiled. Oxygen cylinder holder Removable oxygen cylinder holder. -
Page 23: Damages And Defects
DAMAGES & DEFECTS 20 Damages and defects found in the product or accessories should be reported immediately to one who is in charge of such issues. The bed which can not be safely operated (damaged electric or manual elements) must not be used till it is repaired. -
Page 24: Repairs And Maintenance
21 REPAIRS & MAINTENANCE Repairs must be done by the producer or an authorized service. The user can not carry out any repairs on his own unless he has undergone special training or has been authorized to do that. To provide safe and reliable operation of the product, one should use only spare parts provided by the producer. -
Page 25: Cleaning And Disinfecting
CLEANING & DISINFECTING 22 The Cleaning and disinfecting of Mattress Use alcohol to disinfect the bed. After disinfecting, wash the product with distilled water to remove stains. After disinfecting, dry it thoroughly. Dry it with hot air (max. temp. 60° C) or wipe it with a soft sterile cloth. Caution Cleaning and disinfecting should be carried out only when necessary using the minimal amount of fluid. -
Page 26: Trouble Shooting
23 TROUBLE SHOOTING Possible causes Remedy The bed does not move Locked wheels Unlock the central lock The 5th steering not Step down the pedal for The bed cannot be steered touching the ground caster steering caster again Power cord disconnected from Connect the power pug of the The controlling system mains and Battery is low... -
Page 27: Storage 24
STORAGE 24 If not to be used for a long time, it should be stored in the following conditions: temperature: －10℃～＋60℃ (best temperature suggested:25°±10℃) relative humidity: 20％ ～ 80% Attention: Periodically wash and preserve stainless steel elements with paraffin oil Washing and preservation operations shall be repeated every three months. -
Page 28: Products Scrapped
25 PRODUCTS SCRAPPED According to The Environmental Protection Ordinance, all of these products are environmental pollutants (whether disinfected or not), the users have obligation to deal with the products scrapped in the right way. Process Give the product to company with environmental approach to the use of scrap materials. Give the product to Manufacturers with environmental approach to the use of scrap materials. - Page 30 CONTACT US +(86) 139 6223 1292 info@medik-medical.com info@mediksurgical.com www.medik-medical.com Youtobe www.mediksurgical.com Pls scan the QR code for more info since 1995...
