R-410A
ZJ SERIES W/SIMPLICITY SE
15 - 25 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power And Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . 14
Optional Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Optional Gas Heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Economizer Sequences . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Dry Bulb Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Single Enthalpy Changeover. . . . . . . . . . . . . . . . . . . . . . . 29
Dual Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . 30
Auto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Free Cooling Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Power Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
1 ZJ180-300 Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 ZJ180-300 Unit Accessory Weights . . . . . . . . . . . . . . . . . 9
4 Utilities Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Supply Fan VFD Weights, In Lbs. . . . . . . . . . . . . . . . . . . . 9
6 ZJ180-300 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . 11
7 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
9 ZJ180-300 Physical Data . . . . . . . . . . . . . . . . . . . . . . . . 25
10 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . 26
11 Gas Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
12 Gas Pipe Sizing - Capacity of Pipe . . . . . . . . . . . . . . . . . 27
13 Gas Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . 27
1 ZJ180-300 Component Location . . . . . . . . . . . . . . . . . . . 6
2 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 ZJ180-300 Unit Dimensions Front View . . . . . . . . . . . . . 9
6 ZJ180-300 Unit Dimensions Rear View . . . . . . . . . . . . . 10
7 ZJ180-300 Unit Dimensions Rain Hood . . . . . . . . . . . . . 11
8 ZJ180-300 Roof Curb . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9 Fixed Outdoor Air Damper . . . . . . . . . . . . . . . . . . . . . . . 13
10 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
15 Vent and Combustion Air Hood . . . . . . . . . . . . . . . . . . . 29

TABLE OF CONTENTS

Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Set Point Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Optional Variable Air Volume (VAV) . . . . . . . . . . . . . . . . . 34
Optional Hot Gas Bypass (HGBP) . . . . . . . . . . . . . . . . . . 36
Air Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Sequence of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Compressor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . 47
Electric Heating Sequence Of Operations . . . . . . . . . . . . 49
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . 49
Gas Heating Sequence Of Operations . . . . . . . . . . . . . . . 50
Gas Heating Operation Errors . . . . . . . . . . . . . . . . . . . . 51
Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Start-Up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Checking Gas Heat Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Charging The Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Start-Up Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
LIST OF TABLES
18 RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
19 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . . 45
20 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . 45
21 Limit Control Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
22 Electric Heat Anticipator Setpoint . . . . . . . . . . . . . . . . . . 50
23 Gas Heat Limit Control Setting . . . . . . . . . . . . . . . . . . . . 51
24 Gas Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . 52
25 Gas Rate Cubic Feet Per Hour . . . . . . . . . . . . . . . . . . . . 53
26 Simplicity SE UCB Details . . . . . . . . . . . . . . . . . . . . . . . 58
27 4-Stage Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
LIST OF FIGURES
16 SE-ECO1001-0 Economizer Controller . . . . . . . . . . . . . 31
17 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
18 Altitude/Temperature Correction Factors . . . . . . . . . . . . 37
For All Unit Tonnages . . . . . . . . . . . . . . . . . . . . . . . . . . 46
20 Gas Valve Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
21 Gas Valve and Controls . . . . . . . . . . . . . . . . . . . . . . . . . 51
22 Proper Pilot Flame Adjustment . . . . . . . . . . . . . . . . . . . 54
23 Typical Flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
24 Typical Gas Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
25 ZJ180 (15 Ton) Charging Chart . . . . . . . . . . . . . . . . . . . 55
26 ZJ210 (17.5 Ton) Charging Chart . . . . . . . . . . . . . . . . . 55
27 ZJ240 (20 Ton) Charging Chart . . . . . . . . . . . . . . . . . . . 55
28 ZJ300 (25 Ton) Charging Chart . . . . . . . . . . . . . . . . . . . 55
29 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
30 4-Stage Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
