R-410A
ZE SERIES
3 - 5 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Compressors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power And Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Typical Field Power and Control Wiring . . . . . . . . . . . . . . . . . . . . 15
Typical Power Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Typical Cool/Heat Control Wiring (Smart Equipment™ ZE036-
060) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Optional Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
RRS Economizer Interface Overview . . . . . . . . . . . . . . . . . . . 34
Smart Equipment™ Economizer Sequences. . . . . . . . . . . . . . 35
Dry Bulb Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Single Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Dual Enthalpy Changeover . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Auto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
1 ZE036-060 Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 ZE036-060 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 ZE036-060 Unit Accessory Weights . . . . . . . . . . . . . . . . . . . . 8
4 ZE036-060 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . . . . 10
5 ZE036-060 Utilities Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
8 ZE036-060 Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
9 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . . 31
10 Gas Heat Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . 31
11 Gas Pipe Sizing - Capacity of Pipe . . . . . . . . . . . . . . . . . . . . 32
12 Smart Equipment™ Economizer Board Details . . . . . . . . . . 37
13 Single Enthalpy and Dual Enthalpy High Limit Curves. . . . . . 42
14 Altitude/Temperature Correction Factors . . . . . . . . . . . . . . . 43
15 ZE Blower Performance Side Duct . . . . . . . . . . . . . . . . . . . . 46
16 ZE Blower Performance Bottom Duct . . . . . . . . . . . . . . . . . . 48
17 Belt Drive RPM Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
1 ZE036-060 Component Location . . . . . . . . . . . . . . . . . . . . . . 6
2 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8 ZE036-060 Disconnect Location . . . . . . . . . . . . . . . . . . . . . 10
9 ZE036-060 Unit Side Duct Openings . . . . . . . . . . . . . . . . . . 11
10 ZE036-060 Roof Curb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
11 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
12 Compressor Restraining Bracket . . . . . . . . . . . . . . . . . . . . . 13
14 Typical Smart Equipment™ Control Wiring . . . . . . . . . . . . . 16
TABLE OF CONTENTS
Free Cooling Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Power Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Jade Economizer Interface Overview . . . . . . . . . . . . . . . . . . . 40
Checking Supply Air CFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Cooling Sequence Of Operation . . . . . . . . . . . . . . . . . . . . . . . 51
No Outdoor Air Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Electric Heating Sequence Of Operations. . . . . . . . . . . . . . . . 53
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . . . . 53
Gas Heating Sequence Of Operations . . . . . . . . . . . . . . . . . . 54
Gas Heat Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Flash Codes or Error Messages . . . . . . . . . . . . . . . . . . . . . . . 56
Resets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Start-up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Start-up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Checking Gas Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Board Navigation Examples: . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Start-Up Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
LIST OF TABLES
18 Indoor Blower Specifications (Belt Drive) . . . . . . . . . . . . . . . 49
19 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . . . . . 49
20 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . . . . 50
21 Electric Heat Limit Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
22 Electric Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . 54
23 Single Stage Gas Heat Limit Control Setting . . . . . . . . . . . . 55
24 2 Stage Gas Heat Limit Control Setting . . . . . . . . . . . . . . . . 55
25 Gas Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . . . . 56
26 Gas Rate-Cubit Feet per Hour . . . . . . . . . . . . . . . . . . . . . . . 58
27 ZE036 (3.0 Ton) Operating Pressures . . . . . . . . . . . . . . . . . 61
28 ZE048 (4.0 Ton) Operating Pressures . . . . . . . . . . . . . . . . . 61
29 ZE060 (5.0 Ton) Operating Pressures . . . . . . . . . . . . . . . . . 62
30 Simplicity Lite Unit Control Board Flash Codes . . . . . . . . . . 66
31 Ignition Control Board Flash Codes . . . . . . . . . . . . . . . . . . . 66
32 Smart Equipment™ UCB Details . . . . . . . . . . . . . . . . . . . . . 70
LIST OF FIGURES
15 Side Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
16 Bottom Entry Gas Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
17 Vent And Combustion Air Hood . . . . . . . . . . . . . . . . . . . . . . 34
18 RRS Economizer LCD and Keypad Layout. . . . . . . . . . . . . 34
19 SE-ECO1001-0 Economizer Controller . . . . . . . . . . . . . . . . 37
20 Jade Economizer LCD and Keypad Layout. . . . . . . . . . . . . 40
21 Single Enthalpy Curve And Boundaries . . . . . . . . . . . . . . . . 41
22 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
23 Altitude/Temperature Correction Factors . . . . . . . . . . . . . . . 44
24 Pressure Drop Across Coil . . . . . . . . . . . . . . . . . . . . . . . . . . 50
25 Gas Valve Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
26 Typical Single Stage Gas Valves . . . . . . . . . . . . . . . . . . . . . 57
27 Typical 2 Stage Gas Valves . . . . . . . . . . . . . . . . . . . . . . . . . 57
28 Proper Flame Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 57
29 Typical Flame Appearance . . . . . . . . . . . . . . . . . . . . . . . . . 58
30 Simplicity Lite Control Board . . . . . . . . . . . . . . . . . . . . . . . . 66
31 Smart Equipment™ Unit Control Board . . . . . . . . . . . . . . . . 70
