1.1 SecureSync Front Panel
1.1.1.1

Using the Keypad

The functions of the five keys are:
1.1.1.2

Using the Front Panel Display

There are seven main menu screens on the SecureSync front information display.
Figure 1-2:
1. Your front panel screen will timeout and darken after two minutes of inactiv-
2. Press a menu button to enter that menu on the front panel display.
3. After entering a menu, the cursor will automatically begin on the submenu
4. Use the left and right buttons to switch between submenus if necessary.
5. To enter into a submenu body, press the down button. You will only be able
2
◀▶▲ ▼ arrow keys: Navigate to a menu option (will be highlighted); move
the focus on the screen; switch between submenus
▲ ▼ arrow keys: Scroll through parameter values in edit displays; move
the focus on the screen
ENTER key: Select a menu option, or confirm a selection when editing
✓
each of the seven main menus.
Status LED menu buttons
ity. If your screen is dark, press any menu or keypad button to wake.
selection that you last visited.
to highlight fields that can be changed.
menu buttons: Press these buttons to navigate to
