Proline Promag P 500 PROFINET Table of contents Table of contents About this document ....6 Installation ..... . . 23 Document function .
Page 4 Table of contents Proline Promag P 500 PROFINET Ensuring the degree of protection ..71 Commissioning ....110 Post-connection check .
Page 5 13.2 Measuring and test equipment ... 211 13.3 Endress+Hauser services ....211 Repair ......212 14.1 General notes .
Page 6: About This Document
About this document Proline Promag P 500 PROFINET About this document Document function These Operating Instructions contain all the information that is required in various phases of the life cycle of the device: from product identification, incoming acceptance and storage, to mounting, connection, operation and commissioning through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Proline Promag P 500 PROFINET About this document Symbol Meaning Light emitting diode is on. Light emitting diode is flashing. 1.2.4 Tool symbols Symbol Meaning Torx screwdriver Phillips head screwdriver Open-ended wrench 1.2.5 Symbols for certain types of information Symbol...
Page 8: Documentation
• W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from nameplate • Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2D matrix code (QR code) on the nameplate Detailed list of the individual documents along with the documentation code →...
Page 9: Safety Instructions
Proline Promag P 500 PROFINET Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11: Security
Proline Promag P 500 PROFINET Safety instructions IT security Our warranty is valid only if the device is installed and used as described in the Operating Instructions. The device is equipped with security mechanisms to protect it against any inadvertent changes to the settings.
Page 12: Access Via Web Server
Safety instructions Proline Promag P 500 PROFINET • User-specific access code Protect write access to the device parameters via the local display, Web browser or operating tool (e.g. FieldCare, DeviceCare). Access authorization is clearly regulated through the use of a user-specific access code.
Page 13: Access Via Service Interface (Cdi-Rj45)
Proline Promag P 500 PROFINET Safety instructions 2.7.4 Access via service interface (CDI-RJ45) The device can be connected to a network via the service interface (CDI-RJ45). Device- specific functions guarantee the secure operation of the device in a network. The use of relevant industrial standards and guidelines that have been defined by national and international safety committees, such as IEC/ISA62443 or the IEEE, is recommended.
Page 14: Product Description
Product description Proline Promag P 500 PROFINET Product description The measuring system consists of a transmitter and a sensor. The transmitter and sensor are mounted in physically separate locations. They are interconnected by connecting cables. Product design Two versions of the transmitter are available.
Page 15 Proline Promag P 500 PROFINET Product description 3.1.2 Proline 500 Signal transmission: analog Order code for "Integrated ISEM electronics", option B "Transmitter" For use in applications required to meet special requirements due to ambient or operating conditions. As the electronics are located in the transmitter, the device is ideal in the event of: •...
Page 16: Incoming Acceptance And Product
Technical Documentation present? • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • Depending on the device version, the CD-ROM might not be part of the delivery! The Technical Documentation is available via the Internet or via the Endress+Hauser Operations App, see the "Product identification"...
Page 17: Transmitter Nameplate
 8 sections • The W@M Device Viewer: enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. 4.2.1 Transmitter nameplate Proline 500 –...
Page 18 Incoming acceptance and product identification Proline Promag P 500 PROFINET Proline 500 3 4 5 Order code: Ser. no.: Ext. ord. cd.: Date: A0029192  4 Example of a transmitter nameplate Manufacturing location Name of the transmitter Order code Serial number (ser. no.) Extended order code (ext.
Page 19: Sensor Nameplate
Proline Promag P 500 PROFINET Incoming acceptance and product identification 4.2.2 Sensor nameplate Order code: Ser. no.: Ext. ord. cd.: Date: A0029205  5 Example of sensor nameplate Name of the sensor Manufacturing location Order code Serial number (ser. no.) Extended order code (Ext.
Page 20: Symbols On Measuring Device
Incoming acceptance and product identification Proline Promag P 500 PROFINET 4.2.3 Symbols on measuring device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Reference to documentation Refers to the corresponding device documentation.
Page 21: Storage And Transport
Proline Promag P 500 PROFINET Storage and transport Storage and transport Storage conditions Observe the following notes for storage: ‣ Store in the original packaging to ensure protection from shock. ‣ Do not remove protective covers or protective caps installed on process connections.
Page 22: Measuring Devices With Lifting Lugs
Storage and transport Proline Promag P 500 PROFINET 5.2.2 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device. ‣...
Page 23: Installation
Proline Promag P 500 PROFINET Installation Installation Installation conditions 6.1.1 Mounting position Mounting location A0029343 Preferably install the sensor in an ascending pipe, and ensure a sufficient distance to the next pipe elbow: h ≥ 2 × DN. Installation in down pipes Install a siphon with a vent valve downstream of the sensor in down pipes whose length h ≥...
Page 24 Installation Proline Promag P 500 PROFINET For heavy sensors DN ≥ 350 (14") A0016276 Orientation The direction of the arrow on the sensor nameplate helps you to install the sensor according to the flow direction (direction of medium flow through the piping).
Page 25: Environment And Process Requirements
Proline Promag P 500 PROFINET Installation A0029344 EPD electrode for empty pipe detection Measuring electrodes for signal detection Reference electrode for potential equalization Measuring devices with tantalum or platinum electrodes can be ordered without an EPD electrode. In this case, empty pipe detection is performed via the measuring electrodes.
Page 26 Installation Proline Promag P 500 PROFINET System pressure A0028777 Never install the sensor on the pump suction side in order to avoid the risk of low pressure, and thus damage to the liner. Furthermore, install pulse dampers if reciprocating, diaphragm or peristaltic pumps are used.
Page 27 Proline Promag P 500 PROFINET Installation max. A0031216 Adapters Suitable adapters to DIN EN 545 (double-flange reducers) can be used to install the sensor in larger-diameter pipes. The resultant increase in the rate of flow improves measuring accuracy with very slow-moving fluids. The nomogram shown here can be used to calculate the pressure loss caused by reducers and expanders.
Page 28: Special Mounting Instructions
Installation Proline Promag P 500 PROFINET 6.1.3 Special mounting instructions Protective cover 213 (8.4) 203 (8.0) A0029552  8 Weather protection cover for Proline 500 – digital 280 (11.0) 255 (10.0) 146 (5.75) 134 (5.3) 12 (0.47) 30 (1.18) A0029553 ...
Page 29: Preparing The Measuring Device
Proline Promag P 500 PROFINET Installation 6.2.2 Preparing the measuring device 1. Remove all remaining transport packaging. 2. Remove any protective covers or protective caps present from the sensor. 3. Remove stick-on label on the electronics compartment cover. 6.2.3 Mounting the sensor...
Page 30 Installation Proline Promag P 500 PROFINET Screw tightening torques Please note the following: • The screw tightening torques listed below apply only to lubricated threads and to pipes not subjected to tensile stress. • Tighten the screws uniformly and in diagonally opposite sequence.
Page 31 Proline Promag P 500 PROFINET Installation Nominal Pressure rating Screws Flange thickness Max. screw tightening torque diameter [Nm] [mm] [bar] [mm] [mm] PTFE PN 25 20 × M33 – PN 10 20 × M24 – PN 16 20 × M30 –...
Page 32 Installation Proline Promag P 500 PROFINET Nominal diameter Pressure rating Screws Max. screw tightening torque [Nm] [mm] [bar] [mm] PTFE 4 × M16 – 4 × M16 – 4 × M16 4 × M16 4 × M16 8 × M16 4 ×...
Page 33: Mounting The Transmitter Housing: Proline 500 - Digital
Proline Promag P 500 PROFINET Installation Nominal screw tightening torques Nominal screw tightening torques for JIS B2220 Nominal diameter Pressure rating Screws Nom. screw tightening torque [Nm] [mm] [bar] [mm] 16 × M22 16 × M30×3 16 × M24 16 × M30×3 16 ×...
Page 34 Installation Proline Promag P 500 PROFINET ø TX 25 20…70 ø ( 0.79…2.75) SW 10 A0029051  10 Engineering unit mm (in) Wall mounting 17 (0.67) 5.8 (0.23) 5.8 (0.23) 149 (5.85) A0029054  11 Engineering unit mm (in) Depends on order code for "Transmitter housing"...
Page 35: Mounting The Transmitter Housing: Proline 500
Proline Promag P 500 PROFINET Installation 6.2.5 Mounting the transmitter housing: Proline 500 CAUTION Ambient temperature too high! Danger of electronics overheating and housing deformation. ‣ Do not exceed the permitted maximum ambient temperature →  25. ‣ If operating outdoors: Avoid direct sunlight and exposure to weathering, particularly in warm climatic regions.
Page 36: Turning The Transmitter Housing: Proline 500
Installation Proline Promag P 500 PROFINET Post mounting WARNING Order code for "Transmitter housing", option L "Cast, stainless": cast transmitters are very heavy. They are unstable if they are not mounted on a secure, fixed post. ‣ Only mount the transmitter on a secure, fixed post on a stable surface.
Page 37: Turning The Display Module: Proline 500
Proline Promag P 500 PROFINET Installation 7. Depending on the device version: Attach the securing clamp of the connection compartment cover. 6.2.7 Turning the display module: Proline 500 The display module can be turned to optimize display readability and operability.
Page 38: Electrical Connection
Electrical connection Proline Promag P 500 PROFINET Electrical connection NOTICE The measuring device does not have an internal circuit breaker. ‣ For this reason, assign the measuring device a switch or power-circuit breaker so that the power supply line can be easily disconnected from the mains.
Page 39 Proline Promag P 500 PROFINET Electrical connection Relay output Standard installation cable is sufficient. Current input 0/4 to 20 mA Standard installation cable is sufficient. Status input Standard installation cable is sufficient. Cable diameter • Cable glands supplied: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) •...
Page 40 Electrical connection Proline Promag P 500 PROFINET Choice of connecting cable between the transmitter and sensor Depends on the type of transmitter and the installation zones A0032477 Proline 500 digital transmitter Proline 500 transmitter Promag sensor Non-hazardous area Hazardous area: Zone 2; Class I, Division 2 Hazardous area: Zone 1;...
Page 41 Proline Promag P 500 PROFINET Electrical connection Cable lengths for use in Non-hazardous area, Hazardous area: Zone 1; Cross-section Hazardous area: Zone 2; Class I, Division 1 Class I, Division 2 1.50 mm (AWG 15) 300 m (1 000 ft) 180 m (600 ft) 2.50 mm...
Page 42: Terminal Assignment
Electrical connection Proline Promag P 500 PROFINET A0029151  14 Cable cross-section Electrode cable Coil current cable Core Core insulation Core shield Core jacket Core reinforcement Cable shield Outer jacket Reinforced connecting cables Reinforced connecting cables with an additional, reinforcing metal braid should be used for: •...
Page 43: Device Plugs Available
Proline Promag P 500 PROFINET Electrical connection 7.1.4 Device plugs available Device plugs may not be used in hazardous areas! Order code for "Input; output 1", option RA "PROFINET" Order code for Cable entry/connection "Electrical connection" L, N, P, U Connector M12 ×...
Page 44: Preparing The Connecting Cable: Proline 500 - Digital
Electrical connection Proline Promag P 500 PROFINET 7.1.7 Preparing the connecting cable: Proline 500 – digital When terminating the connecting cable, pay attention to the following points: ‣ For cables with fine-wire cores (stranded cables): Fit the cores with ferrules.
Page 45 Proline Promag P 500 PROFINET Electrical connection Transmitter Electrode cable Coil current cable (3.54) 100 (3.94)* 70 (2.76) 80 (3.15) 50 (1.97) 50 (1.97) 17 (0.67) 8 (0.3) 10 (0.4) 8 (0.3) A0029329 A0029326 Sensor Electrode cable Coil current cable 20 (0.8)*...
Page 46: Connecting The Measuring Device: Proline 500 - Digital
Electrical connection Proline Promag P 500 PROFINET Connecting the measuring device: Proline 500 - digital NOTICE Limitation of electrical safety due to incorrect connection! ‣ Have electrical connection work carried out by appropriately trained specialists only. ‣ Observe applicable federal/national installation codes and regulations.
Page 47 Proline Promag P 500 PROFINET Electrical connection Connecting the sensor connection housing via terminals For the device version with the order code for "Sensor connection housing": • Option A "Aluminum coated" • Option L "Cast, stainless" 10 (0.4) 3 mm...
Page 48 Electrical connection Proline Promag P 500 PROFINET Connecting the connecting cable to the transmitter TX 20 TX 20 10 (0.4) 22 mm 24 mm A0029597 1. Loosen the 4 fixing screws on the housing cover. 2. Open the housing cover.
Page 49: Connecting The Transmitter
Proline Promag P 500 PROFINET Electrical connection 7.2.2 Connecting the transmitter A0028200 Terminal connection for supply voltage Terminal connection for signal transmission, input/output Terminal connection for signal transmission, input/output Terminal connection for connecting cable between sensor and transmitter Terminal connection for signal transmission, input/output or terminal connection for network connection via service interface (CDI-RJ45);...
Page 50 Electrical connection Proline Promag P 500 PROFINET 6. Connect the protective ground. 7. Plug in the RJ45 connector. 8. Firmly tighten the cable glands.  This concludes the PROFINET connection process. Connecting the supply voltage and additional inputs/outputs TX 20 TX 20 10 (0.4)
Page 51 Proline Promag P 500 PROFINET Electrical connection Removing a cable 3 (0.12) A0029598  15 Engineering unit mm (in) 1. To remove a cable from the terminal, use a flat-blade screwdriver to push the slot between the two terminal holes 2.
Page 52: Integrating The Transmitter Into A Network
Electrical connection Proline Promag P 500 PROFINET 7.2.3 Integrating the transmitter into a network This section only presents the basic options for integrating the device into a network. For information on the procedure to follow to connect the transmitter correctly →  46.
Page 53 Proline Promag P 500 PROFINET Electrical connection Integrating into a ring topology The device is integrated via the terminal connection for signal transmission (output 1) and the connection to the service interface (CDI-RJ45). Note the following when connecting: • Recommended cable: CAT5e, CAT6 or CAT7, with shielded connector (e.g. brand: YAMAICHI ;...
Page 54: Connecting The Measuring Device: Proline 500
Electrical connection Proline Promag P 500 PROFINET Connecting the measuring device: Proline 500 NOTICE Limitation of electrical safety due to incorrect connection! ‣ Have electrical connection work carried out by appropriately trained specialists only. ‣ Observe applicable federal/national installation codes and regulations.
Page 55 Proline Promag P 500 PROFINET Electrical connection Connecting the sensor connection housing via terminals For the device version with the order code for "Housing": • Option A "Aluminum coated" • Option L "Cast, stainless" 10 (0.4) 3 mm 22 mm...
Page 56 Electrical connection Proline Promag P 500 PROFINET Connecting the connecting cable to the transmitter 10 (0.4) 3 mm 22 mm 24 mm A0029592 1. Loosen the securing clamp of the connection compartment cover. 2. Unscrew the connection compartment cover. 3. Push the cable through the cable entry . To ensure tight sealing, do not remove the sealing ring from the cable entry.
Page 57: Connecting The Transmitter
Proline Promag P 500 PROFINET Electrical connection 7.3.2 Connecting the transmitter A0026781 Terminal connection for supply voltage Terminal connection for signal transmission, input/output Terminal connection for signal transmission, input/output or terminal connection for network connection via service interface (CDI-RJ45) Protective earth (PE)
Page 58 Electrical connection Proline Promag P 500 PROFINET 22 mm 24 mm N ic t e r e r g ö f f iz e t e n s io r ir A0033722 7. Push the cable through the cable entry . To ensure tight sealing, do not remove the sealing ring from the cable entry.
Page 59 Proline Promag P 500 PROFINET Electrical connection 22 mm 24 mm – A0033984 4. Connect the cable in accordance with the terminal assignment .  Signal cable terminal assignment: The device-specific terminal assignment is documented on an adhesive label in the terminal cover.
Page 60: Integrating The Transmitter Into A Network
Electrical connection Proline Promag P 500 PROFINET 7.3.3 Integrating the transmitter into a network This section only presents the basic options for integrating the device into a network. For information on the procedure to follow to connect the transmitter correctly →  54.
Page 61: Ensuring Potential Equalization
Proline Promag P 500 PROFINET Electrical connection Integrating into a ring topology The device is integrated via the terminal connection for signal transmission (output 1) and the connection to the service interface (CDI-RJ45). Note the following when connecting: • Recommended cable: CAT5e, CAT6 or CAT7, with shielded connector (e.g. brand: YAMAICHI ;...
Page 62: Connection Example, Standard Scenario
Electrical connection Proline Promag P 500 PROFINET 7.4.2 Connection example, standard scenario Metal, grounded pipe A0016315  17 Potential equalization via measuring tube 7.4.3 Connection example in special situations Unlined and ungrounded metal pipe This connection method also applies in situations where: •...
Page 63 Proline Promag P 500 PROFINET Electrical connection A0029339  19 Potential equalization via ground terminal and ground disks 1. Connect the ground disks to the ground terminal via the ground cable. 2. Connect the ground disks to ground potential. Pipe with a cathodic protection unit This connection method is only used if the following two conditions are met: •...
Page 64: Special Connection Instructions
Electrical connection Proline Promag P 500 PROFINET Special connection instructions 7.5.1 Connection examples PROFINET A0028767  20 Connection example for PROFINET Control system (e.g. PLC) Ethernet switch Observe cable specifications Device plug Transmitter PROFINET: MRP (Media Redundancy Protocol) A0027544 Control system (e.g. PLC) Ethernet switch Observe cable specifications →...
Page 65 Proline Promag P 500 PROFINET Electrical connection PROFINET: system redundancy S2 A0039553  21 Connection example for system redundancy S2 Control system 1 (e.g. PLC) Synchronization of control systems Control system 2 (e.g. PLC) Industrial Ethernet Managed Switch Transmitter Current output 4-20 mA 4...20 mA...
Page 66 Electrical connection Proline Promag P 500 PROFINET Pulse/frequency output 12345 A0028761  24 Connection example for pulse/frequency output (passive) Automation system with pulse/frequency input (e.g. PLC) Power supply Transmitter: Observe input values →  222 Switch output A0028760  25 Connection example for switch output (passive) Automation system with switch input (e.g.
Page 67: Hardware Settings
Proline Promag P 500 PROFINET Electrical connection Current input A0028915  27 Connection example for 4 to 20 mA current input Power supply Terminal box External measuring device (to read in pressure or temperature, for instance) Transmitter Status input A0028764 ...
Page 68 Electrical connection Proline Promag P 500 PROFINET Setting the device name using the DIP switches The last part of the device name can be set using DIP switches 1-8. The address range is between 1 and 254 (factory setting: serial number of the device )
Page 69 Proline Promag P 500 PROFINET Electrical connection 1 2 3 4 5 6 7 8 Name of Station A0034497 1. Loosen the 4 fixing screws on the housing cover. 2. Open the housing cover. 3. Fold open the terminal cover.
Page 70: Activating The Default Ip Address
Electrical connection Proline Promag P 500 PROFINET 5. Reconnect the device to the power supply.  The configured device address is used once the device is restarted. Setting the device name via the automation system DIP switches 1-8 must all be set to OFF (factory setting) or all be set to ON to be able to set the device name via the automation system.
Page 71: Ensuring The Degree Of Protection
Proline Promag P 500 PROFINET Electrical connection Activating the default IP address by DIP switch: Proline 500 Risk of electric shock when opening the transmitter housing. ‣ Before opening the transmitter housing: ‣ Disconnect the device from the power supply.
Page 72: Post-Connection Check
Electrical connection Proline Promag P 500 PROFINET Post-connection check Are cables or the device undamaged (visual inspection)?  Do the cables used meet the requirements?  Do the cables have adequate strain relief?  Are all the cable glands installed, firmly tightened and leak-tight? Cable run with "water trap"...
Page 73: Operation Options
Proline Promag P 500 PROFINET Operation options Operation options Overview of operation options A0034513 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370...
Page 74: Structure And Function Of The Operating
Operation options Proline Promag P 500 PROFINET Structure and function of the operating menu 8.2.1 Structure of the operating menu For an overview of the operating menu for experts: "Description of Device Parameters" document supplied with the device→  244...
Page 75: Operating Philosophy
Proline Promag P 500 PROFINET Operation options 8.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (operator, maintenance etc.). Each user role contains typical tasks within the device lifecycle. Menu/parameter User role and tasks...
Page 76: Access To The Operating Menu Via The Local Display
Operation options Proline Promag P 500 PROFINET Access to the operating menu via the local display 8.3.1 Operational display X X X X X X X 1120.50 A0029346 Operational display Device tag Status area Display area for measured values (4-line) Operating elements→...
Page 77: Navigation View
Proline Promag P 500 PROFINET Operation options Measurement channel numbers Symbol Meaning Measurement channel 1 to 4 The measurement channel number is displayed only if more than one channel is present for the same measured variable type (e.g. Totalizer 1 to 3).
Page 78 Operation options Proline Promag P 500 PROFINET Status area The following appears in the status area of the navigation view in the top right corner: • In the submenu • The direct access code for the parameter you are navigating to (e.g. 0022-1) •...
Page 79: Editing View
Proline Promag P 500 PROFINET Operation options 8.3.3 Editing view Numeric editor +0.000 Xx – A0034250  30 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 80 Operation options Proline Promag P 500 PROFINET Operating key(s) Meaning Enter key • Press the key briefly: confirm your selection. • Press the key for 2 s: confirm the entry. Escape key combination (press keys simultaneously) Close the editing view without accepting the changes.
Page 81: Operating Elements
Proline Promag P 500 PROFINET Operation options 8.3.4 Operating elements Operating key(s) Meaning Minus key In a menu, submenu Moves the selection bar upwards in a picklist. With a Wizard Confirms the parameter value and goes to the previous parameter.
Page 82 Operation options Proline Promag P 500 PROFINET Calling up and closing the context menu The user is in the operational display. 1. Press the  and  keys for longer than 3 seconds.  The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 83: Navigating And Selecting From List
Proline Promag P 500 PROFINET Operation options 8.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 84: Calling Up Help Text
Operation options Proline Promag P 500 PROFINET The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 85: User Roles And Related Access Authorization
Proline Promag P 500 PROFINET Operation options Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN For a description of the editing view - consisting of the text editor and numeric editor - with symbols →  79, for a description of the operating elements →  81 8.3.10...
Page 86: Enabling And Disabling The Keypad
Operation options Proline Promag P 500 PROFINET 2. Enter the access code.  The -symbol in front of the parameters disappears; all previously write- protected parameters are now re-enabled. 8.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation.
Page 87: Prerequisites
Proline Promag P 500 PROFINET Operation options 8.4.2 Prerequisites Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have an RJ45 The operating unit must have a interface. WLAN interface. Connection Standard Ethernet cable with RJ45 Connection via Wireless LAN.
Page 88: Establishing A Connection
Operation options Proline Promag P 500 PROFINET Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON  For information on enabling the Web server →  92...
Page 89 Proline Promag P 500 PROFINET Operation options The measuring device works with the Dynamic Configuration Protocol (DCP), on leaving the factory, i.e. the IP address of the measuring device is automatically assigned by the automation system (e.g. Siemens S7). To establish a network connection via the service interface (CDI-RJ45): set the "Default IP address"...
Page 90: Logging On
Operation options Proline Promag P 500 PROFINET 3. Enter the password: serial number of the measuring device ex-works (e.g. L100A802000).  LED on display module flashes: it is now possible to operate the measuring device with the Web browser, FieldCare or DeviceCare.
Page 91: User Interface
Proline Promag P 500 PROFINET Operation options 2. Enter the user-specific access code. 3. Press OK to confirm your entry. Access code 0000 (factory setting); can be changed by customer If no action is performed for 10 minutes, the Web browser automatically returns to the login page.
Page 92: Disabling The Web Server
Operation options Proline Promag P 500 PROFINET Functions Meaning Configuration and checking of all the parameters required for establishing the connection to Network the measuring device: configuration • Network settings (e.g. IP address, MAC address) • Device information (e.g. serial number, firmware version)
Page 93: Logging Out
Proline Promag P 500 PROFINET Operation options 8.4.7 Logging out Before logging out, perform a data backup via the Data management function (upload configuration from device) if necessary. 1. Select the Logout entry in the function row.  The home page with the Login box appears.
Page 94 Operation options Proline Promag P 500 PROFINET A0033719  34 Options for remote operation via PROFINET network: ring topology Automation system, e.g. Simatic S7 (Siemens) Computer with Web browser (e.g. Internet Explorer) for accessing the integrated device Web server or computer with operating tool (e.g.
Page 95 Proline Promag P 500 PROFINET Operation options Proline 500 transmitter A0027563  36 Connection via service interface (CDI-RJ45) Computer with Web browser (e.g. Microsoft Internet Explorer, Microsoft Edge) for accessing the integrated device Web server or with "FieldCare", "DeviceCare" operating tool with COM DTM "CDI Communication TCP/IP"...
Page 96 Operation options Proline Promag P 500 PROFINET Function WLAN: IEEE 802.11 b/g (2.4 GHz) Encryption WPA2-PSK AES-128 (in accordance with IEEE 802.11i) Configurable WLAN channels 1 to 11 Degree of protection IP67 Available antennas • Internal antenna • External antenna (optional) In the event of poor transmission/reception conditions at the place of installation.
Page 97: Fieldcare
FieldCare Function scope FDT-based plant asset management tool from Endress+Hauser. It can configure all smart field devices in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Page 98: Devicecare
DeviceCare Function scope Tool to connect and configure Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. For details, see Innovation Brochure IN01047S Source for device description files See information →...
Page 99: System Integration
Proline Promag P 500 PROFINET System integration System integration Overview of device description files 9.1.1 Current version data for the device Firmware version 01.01.zz • On the title page of the Operating instructions • On the transmitter nameplate • Firmware version Diagnostics →...
Page 100: File Name Of The Device Master File (Gsd)
System integration Proline Promag P 500 PROFINET 9.2.1 File name of the device master file (GSD) Example of the name of a device master file: GSDML-V2.3.x-EH-PROMAG 500-yyyymmdd.xml GSDML Description language V2.3.x Version of the PROFINET specification Endress+Hauser PROMAG Instrument family...
Page 101: Cyclic Data Transmission
Proline Promag P 500 PROFINET System integration Cyclic data transmission 9.3.1 Overview of the modules The following tables shows which modules are available to the measuring device for cyclic data exchange. Cyclic data exchange is performed with an automation system.
Page 102 System integration Proline Promag P 500 PROFINET Data structure Input data of Analog Input Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Measured value: floating point number (IEEE 754) Status Status coding →  107 Digital Input module Transmit digital input values from the measuring device to the automation system.
Page 103 Proline Promag P 500 PROFINET System integration Data structure Input data of Diagnose Input Byte 1 Byte 2 Byte 3 Byte 4 Diagnostic information number Status Value 0 Status Coding (hex) Status 0x00 No device error is present. Failure (F): 0x01 A device error is present.
Page 104 System integration Proline Promag P 500 PROFINET Selection: control totalizer Slot Sub-slot Value Control totalizer Totalize Reset + hold Preset + hold 11…13 Reset + totalize Preset + totalize Hold Data structure of output data (Totalizer Control submodule) Byte 1...
Page 105 Proline Promag P 500 PROFINET System integration Available units Density Temperature Unit code Unit Unit code Unit 1100 g/cm 1001 °C 1101 1002 °F 1099 kg/dm 1000 1103 kg/l 1003 °R 1097 kg/m 1628 SD4°C 1629 SD15°C 1630 SD20°C 32833 SG4°C...
Page 106 System integration Proline Promag P 500 PROFINET Digital Output module Transmit digital output values from the automation system to the measuring device. Digital output values are used by the automation system to enable and disable device functions. Digital output values cyclically transmit discrete output values, including the status, from the automation system to the measuring device.
Page 107: Status Coding
Proline Promag P 500 PROFINET System integration Verification has failed Verification performed successfully (input data) Verification has not been performed – Verification control Start verification (output data) A change in the status from 0 to 1 starts the verification Data structure...
Page 108: Factory Setting
System integration Proline Promag P 500 PROFINET 9.3.4 Factory setting The slots are already assigned in the automation system for initial commissioning. Assigned slots Slot Factory setting Volume flow Mass flow Corrected volume flow Flow velocity 5…10 – Totalizer 1...
Page 109: System Redundancy S2
Proline Promag P 500 PROFINET System integration System redundancy S2 A redundant layout with two automation systems is necessary for processes that are in continuous operation. If one system fails the second system guarantees continued, uninterrupted operation. The measuring device supports S2 system redundancy and can communicate with both automation systems simultaneously.
Page 110: Commissioning
Commissioning Proline Promag P 500 PROFINET Commissioning 10.1 Function check Before commissioning the measuring device: ‣ Make sure that the post-installation and post-connection checks have been performed. • "Post-installation check" checklist→  37 • "Post-connection check" checklist →  72 10.2...
Page 111: Configuring The Measuring Device
Proline Promag P 500 PROFINET Commissioning 10.5 Configuring the measuring device • The Setup menu with its guided wizards contains all the parameters needed for standard operation. • Navigation to the Setup menu X X X X X X X 20.50...
Page 112: Defining The Tag Name
Commissioning Proline Promag P 500 PROFINET ‣ Relay output 1 to n →  127 ‣ Display →  129 ‣ Low flow cut off →  132 ‣ Empty pipe detection →  134 ‣ →  135 Advanced setup 10.5.1...
Page 113 Proline Promag P 500 PROFINET Commissioning Mass unit →  113 Density unit →  113 Corrected volume flow unit →  114 Corrected volume unit →  114 Parameter overview with brief description Parameter Prerequisite Description Selection Factory setting Volume flow unit –...
Page 114: Displaying The Communication
Commissioning Proline Promag P 500 PROFINET Parameter Prerequisite Description Selection Factory setting Corrected volume flow unit – Select corrected volume flow Unit choose list Country-specific: unit. • Nl/h • Sft³/h Result The selected unit applies for: Corrected volume flow parameter (→  156) Corrected volume unit –...
Page 115: Selecting And Setting The Medium
Proline Promag P 500 PROFINET Commissioning 10.5.4 Selecting and setting the medium The Select medium wizard submenu contains parameters that must be configured in order to select and set the medium. Navigation "Setup" menu → Select medium ‣ Medium selection →...
Page 116: Configuring The Current Input
Commissioning Proline Promag P 500 PROFINET Apply I/O configuration →  116 I/O alteration code →  116 Parameter overview with brief description Parameter Description User interface / Selection / Factory setting User entry I/O module 1 to n terminal numbers Shows the terminal numbers used by the I/O •...
Page 117: Configuring The Status Input
Proline Promag P 500 PROFINET Commissioning Failure mode →  117 Failure value →  117 Parameter overview with brief description Parameter Prerequisite Description User interface / Factory setting Selection / User entry Terminal number – Shows the terminal numbers • Not used –...
Page 118: Configuring The Current Output
Commissioning Proline Promag P 500 PROFINET Terminal number →  118 Response time status input →  118 Terminal number →  118 Parameter overview with brief description Parameter Description User interface / Selection / Factory setting User entry Terminal number Shows the terminal numbers used by the •...
Page 119 Proline Promag P 500 PROFINET Commissioning Failure mode →  120 Failure current →  120 Parameter overview with brief description Parameter Prerequisite Description User interface / Factory setting Selection / User entry Terminal number – Shows the terminal numbers • Not used –...
Page 120 Commissioning Proline Promag P 500 PROFINET Parameter Prerequisite Description User interface / Factory setting Selection / User entry Fixed current The Fixed current option is Defines the fixed output 0 to 22.5 mA 22.5 mA selected in the Current span current. parameter (→  119).
Page 121: Configuring The Pulse/Frequency
Proline Promag P 500 PROFINET Commissioning 10.5.9 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 122 Commissioning Proline Promag P 500 PROFINET Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode – Define the output as a pulse, • Pulse Pulse frequency or switch output. • Frequency • Switch Terminal number –...
Page 123 Proline Promag P 500 PROFINET Commissioning Minimum frequency value →  123 Maximum frequency value →  124 Measuring value at minimum →  124 frequency Measuring value at maximum →  124 frequency →  124 Failure mode Failure frequency →...
Page 124 Commissioning Proline Promag P 500 PROFINET Parameter Prerequisite Description Selection / User Factory setting interface / User entry Maximum frequency value The Frequency option is Enter maximum frequency. 0.0 to 10 000.0 Hz 10 000.0 Hz selected in the Operating mode parameter (→  121)
Page 125 Proline Promag P 500 PROFINET Commissioning Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  125 Terminal number →  125 Signal mode →  125 →  126...
Page 126 Commissioning Proline Promag P 500 PROFINET Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off in the Operating mode output. • On parameter. • Diagnostic behavior • Limit •...
Page 127: 10.5.10 Configuring The Relay Output
Proline Promag P 500 PROFINET Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch-off delay • The Switch option is Define delay for the switch-off 0.0 to 100.0 s 0.0 s selected in the Operating of status output. mode parameter.
Page 128 Commissioning Proline Promag P 500 PROFINET Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Relay output function – Select the function for the • Closed Closed relay output. • Open • Diagnostic behavior • Limit •...
Page 129: 10.5.11 Configuring The Local Display
Proline Promag P 500 PROFINET Commissioning 10.5.11 Configuring the local display The Display wizard guides you systematically through all the parameters that can configured for configuring the local display. Navigation "Setup" menu → Display ‣ Display Format display →  130 Value 1 display →...
Page 130 Commissioning Proline Promag P 500 PROFINET Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 131 Proline Promag P 500 PROFINET Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Value 2 display A local display is provided. Select the measured value that • None None is shown on the local display. • Volume flow • Mass flow •...
Page 132: 10.5.12 Configuring The Low Flow Cut Off
Commissioning Proline Promag P 500 PROFINET Parameter Prerequisite Description Selection / User Factory setting entry 100% bargraph value 3 A selection was made in the Enter 100% value for bar Signed floating-point Value 3 display parameter. graph display. number Value 4 display A local display is provided.
Page 133 Proline Promag P 500 PROFINET Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Assign process variable – Select process variable for low • Off Volume flow flow cut off. • Volume flow • Mass flow •...
Page 134: 10.5.13 Configuring Empty Pipe Detection
Commissioning Proline Promag P 500 PROFINET 10.5.13 Configuring empty pipe detection The Empty pipe detection submenu contains parameters that must be configured for the configuration of empty pipe detection. Navigation "Setup" menu → Empty pipe detection ‣ Empty pipe detection →...
Page 135: Advanced Settings
Proline Promag P 500 PROFINET Commissioning 10.6 Advanced settings The Advanced setup submenu together with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu X X X X X X X 20.50 0104-1 Main menu Display language English Display/operat.
Page 136: Using The Parameter To Enter The Access Code
Commissioning Proline Promag P 500 PROFINET ‣ WLAN settings →  143 ‣ Heartbeat setup ‣ Configuration backup →  145 ‣ Administration →  146 10.6.1 Using the parameter to enter the access code Navigation "Setup" menu → Advanced setup...
Page 137 Proline Promag P 500 PROFINET Commissioning Unit totalizer →  137 Totalizer operation mode →  137 Failure mode →  137 Parameter overview with brief description Parameter Description Selection Factory setting Assign process variable Select process variable for totalizer.
Page 138: Carrying Out Additional Display Configurations
Commissioning Proline Promag P 500 PROFINET 10.6.4 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣ Display →...
Page 139 Proline Promag P 500 PROFINET Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size 1 value, max. size are shown on the display.
Page 140 Commissioning Proline Promag P 500 PROFINET Parameter Prerequisite Description Selection / User Factory setting entry Value 2 display A local display is provided. Select the measured value that • None None is shown on the local display. • Volume flow • Mass flow •...
Page 141 Proline Promag P 500 PROFINET Commissioning Parameter Prerequisite Description Selection / User Factory setting entry 0% bargraph value 3 A selection was made in the Enter 0% value for bar graph Signed floating-point Country-specific: Value 3 display parameter. display. number • 0 l/h •...
Page 142: Performing Electrode Cleaning
Commissioning Proline Promag P 500 PROFINET Parameter Prerequisite Description Selection / User Factory setting entry Display language A local display is provided. Set display language. • English English • Deutsch (alternatively, the • Français ordered language is • Español preset in the device) •...
Page 143: Wlan Configuration
Proline Promag P 500 PROFINET Commissioning Navigation "Setup" menu → Advanced setup → Electrode cleaning circuit ‣ Electrode cleaning circuit →  143 Electrode cleaning circuit →  143 ECC duration ECC recovery time →  143 ECC cleaning cycle →...
Page 144 Commissioning Proline Promag P 500 PROFINET WLAN mode →  144 SSID name →  144 Network security →  144 Security identification →  144 →  144 User name WLAN password →  145 WLAN IP address →  145...
Page 145: Configuration Management
Proline Promag P 500 PROFINET Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface WLAN password – Enter WLAN password. – – WLAN IP address – Enter IP address of the WLAN 4 octet: 0 to 255 (in 192.168.1.212 interface of the device.
Page 146: Using Parameters For Device Administration
Commissioning Proline Promag P 500 PROFINET Parameter overview with brief description Parameter Description User interface / Selection Factory setting Operating time Indicates how long the device has been in Days (d), hours (h), minutes – operation. (m) and seconds (s) Last backup...
Page 147 Proline Promag P 500 PROFINET Commissioning Navigation "Setup" menu → Advanced setup → Administration ‣ Administration ‣ →  147 Define access code ‣ →  147 Reset access code Device reset →  148 Using the parameter to define the access code Navigation "Setup"...
Page 148: Simulation
Commissioning Proline Promag P 500 PROFINET Parameter overview with brief description Parameter Description User interface / User entry Factory setting Operating time Indicates how long the device has been in Days (d), hours (h), minutes – operation. (m) and seconds (s) Reset access code Reset access code to factory settings.
Page 149 Proline Promag P 500 PROFINET Commissioning Current output 1 to n simulation →  150 Value current output 1 to n →  150 Frequency output simulation 1 to n →  150 Frequency value 1 to n →  150 →...
Page 150 Commissioning Proline Promag P 500 PROFINET Parameter Prerequisite Description Selection / User Factory setting entry / User interface Current output 1 to n simulation – Switch the simulation of the • Off current output on and off. • On Value current output 1 to n...
Page 151: Protecting Settings From Unauthorized
Proline Promag P 500 PROFINET Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Diagnostic event simulation – Select a diagnostic event to • Off simulate this event. • Diagnostic event picklist (depends on the category selected) Logging interval –...
Page 152: Write Protection Via Write Protection
Via Web browser, FieldCare, DeviceCare (via CDI-RJ45 service interface), fieldbus For a reset code, contact your Endress+Hauser service organization. 1. Navigate to the Reset access code parameter (→  148). 2. Enter the reset code.
Page 153 Proline Promag P 500 PROFINET Commissioning Proline 500 – digital WARNING Excessive tightening torque applied to the fixing screws! Risk of damaging the plastic transmitter. ‣ Tighten the fixing screws as per the tightening torque: 2 Nm (1.5 lbf ft) A0029673 1.
Page 154 Commissioning Proline Promag P 500 PROFINET Proline 500 A0029630 Setting the write protection (WP) switch on the main electronics module to the ON position enables hardware write protection.  In the Locking status parameter the Hardware locked option is displayed →...
Page 155: Operation
Proline Promag P 500 PROFINET Operation Operation 11.1 Reading the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access status displayed in the Access status parameter applies →  85. Only appears on local display.
Page 156: Process Variables" Submenu
Operation Proline Promag P 500 PROFINET 11.4.1 "Process variables" submenu The Process variables submenu contains all the parameters needed to display the current measured values for each process variable. Navigation "Diagnostics" menu → Measured values → Process variables ‣ Process variables...
Page 157: Input Values" Submenu
Proline Promag P 500 PROFINET Operation Navigation "Diagnostics" menu → Measured values → Totalizer 1 to n ‣ Totalizer 1 to n →  157 Assign process variable →  157 Totalizer value 1 to n Totalizer status 1 to n →...
Page 158 Operation Proline Promag P 500 PROFINET Navigation "Diagnostics" menu → Measured values → Input values ‣ Input values ‣ →  158 Current input 1 to n ‣ →  158 Status input 1 to n Input values of current input The Current input 1 to n submenu contains all the parameters needed to display the current measured values for every current input.
Page 159: Output Values
Proline Promag P 500 PROFINET Operation 11.4.4 Output values The Output values submenu contains all the parameters needed to display the current measured values for every output. Navigation "Diagnostics" menu → Measured values → Output values ‣ Output values ‣...
Page 160 Operation Proline Promag P 500 PROFINET Navigation "Diagnostics" menu → Measured values → Output values → Pulse/frequency/switch output 1 to n ‣ Pulse/frequency/switch output 1 to n Output frequency 1 to n →  160 Pulse output 1 to n →...
Page 161: Adapting The Measuring Device To The Process
Proline Promag P 500 PROFINET Operation 11.5 Adapting the measuring device to the process conditions The following are available for this purpose: • Basic settings using theSetup menu (→  111) • Advanced settings using theAdvanced setup submenu (→  135) 11.6...
Page 162: Function Scope Of The "Reset All Totalizers" Parameter
Operation Proline Promag P 500 PROFINET Options Description Preset + totalize The totalizer is set to the defined start value from the Preset value parameter and the totaling process is restarted. Hold Totalizing is stopped. 11.6.2 Function scope of the "Reset all totalizers" parameter...
Page 163 Proline Promag P 500 PROFINET Operation Assign channel 4 →  164 Logging interval →  164 Clear logging data →  164 Data logging →  164 Logging delay →  165 Data logging control →  165 Data logging status →...
Page 164 Operation Proline Promag P 500 PROFINET Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Assign channel 1 The Extended HistoROM Assign process variable to • Off application package is logging channel. • Volume flow available.
Page 165 Proline Promag P 500 PROFINET Operation Parameter Prerequisite Description Selection / User Factory setting entry / User interface Logging delay In the Data logging Enter the time delay for 0 to 999 h parameter, the Not measured value logging. overwriting option is selected. Data logging control...
Page 166: Diagnostics And Troubleshooting
Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostics and troubleshooting 12.1 General troubleshooting For local display Error Possible causes Solution Local display dark and no output Supply voltage does not match the Apply the correct supply voltage . signals value indicated on the nameplate.
Page 167 Proline Promag P 500 PROFINET Diagnostics and troubleshooting For output signals Error Possible causes Solution Signal output outside the valid Main electronics module is Order spare part →  212. range defective. Device shows correct value on local Configuration error...
Page 168 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Error Possible causes Solution Apart from the active network • Make sure that no other network connection to the measuring device, connections are established by other network connections are also the computer (also no WLAN) being used.
Page 169: Diagnostic Information Via Light Emitting
Proline Promag P 500 PROFINET Diagnostics and troubleshooting For system integration Error Possible causes Solution The device name is not displayed A device name containing one or Specify a correct device name correctly and contains coding. more underscores has been...
Page 170 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Color Meaning Flashing red A diagnostic event with "Warning" diagnostic behavior has occurred. A diagnostic event with "Alarm" diagnostic behavior has occurred. Flashing red/green The device restarts. Device status (during Flashes red slowly If >...
Page 171: Sensor Connection Housing
Proline Promag P 500 PROFINET Diagnostics and troubleshooting Color Meaning Flashing green Device is not configured. Flashing red A diagnostic event with "Warning" diagnostic behavior has occurred. A diagnostic event with "Alarm" diagnostic behavior has occurred. Flashing red/green The device restarts.
Page 172 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Color Meaning Communication White Communication active. Device status (normal Problem operation) Flashing red Warning Device status (during Flashes red slowly If > 30 seconds: problem with the boot loader. start-up) Flashes red quickly If >...
Page 173: Diagnostic Information On Local Display
Proline Promag P 500 PROFINET Diagnostics and troubleshooting 12.3 Diagnostic information on local display 12.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. Operational display in alarm condition...
Page 174 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning Measurement is resumed. The signal outputs and totalizers are not affected. A diagnostic message is generated.
Page 175: Calling Up Remedial Measures
Proline Promag P 500 PROFINET Diagnostics and troubleshooting 12.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2...
Page 176: Calling Up Remedy Information
Diagnostics and troubleshooting Proline Promag P 500 PROFINET A0031056 Status area with status signal Diagnostic information Remedy information with Service ID In addition, diagnostic events which have occurred can be shown in the Diagnostics menu: • Via parameter →  205 •...
Page 177: Calling Up Remedy Information
Proline Promag P 500 PROFINET Diagnostics and troubleshooting Xxxxxx/…/…/ Device name: Xxxxxxx Mass flow: kg/h 12.34 Device tag: Xxxxxxx Volume flow: 12.34 m /h ³ Status signal: Function check (C) Xxxxxx Diagnostics 1: C485 Simu... Remedy information: Deactivate... Failure (F)
Page 178: Adapting The Diagnostic Information
Diagnostics and troubleshooting Proline Promag P 500 PROFINET 12.6 Adapting the diagnostic information 12.6.1 Adapting the diagnostic behavior Each item of diagnostic information is assigned a specific diagnostic behavior at the factory. The user can change this assignment for specific diagnostic information in the Diagnostic behavior submenu.
Page 179 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Supported status information Status Coding (hex) BAD - Maintenance alarm 0x24 BAD - Process related 0x28 BAD - Function check 0x3C UNCERTAIN - Initial value 0x4F UNCERTAIN - Maintenance demanded 0x68 UNCERTAIN - Process related...
Page 180 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Measured value status (fixed assignment) Diagnostic behavior Device diagnosis Quality Coding Category (configurable) (fixed assignment) Quality Substatus (hex) (NE107) Logbook entry only GOOD 0x80 to 0x8E – – Diagnostic information 302 Measured value status (fixed assignment)
Page 181: Overview Of Diagnostic Information
Proline Promag P 500 PROFINET Diagnostics and troubleshooting 12.7 Overview of diagnostic information The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. In the case of some items of diagnostic information, the diagnostic behavior can be changed.
Page 182 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 083 Memory content 1. Restart device • Conductivity 2. Restore HistoROM S-DAT backup • Corrected conductivity Measured variable status (' D evice reset' parameter) •...
Page 183 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 170 Coil resistance Check ambient and process temperature • Conductivity • Corrected conductivity Measured variable status • Density • Electronic temperature Quality • Flow velocity...
Page 184: Diagnostic Of Electronic
Diagnostics and troubleshooting Proline Promag P 500 PROFINET 12.7.2 Diagnostic of electronic Diagnostic information Remedy instructions Influenced measured variables Short text 201 Device failure 1. Restart device • Conductivity 2. Contact service • Corrected conductivity Measured variable status • Measured values 1 •...
Page 185 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 252 Modules incompatible 1. Check if correct electronic modul is • Conductivity plugged • Corrected conductivity Measured variable status 2. Replace electronic module •...
Page 186 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 271 Main electronic failure 1. Restart device • Conductivity 2. Change main electronic module • Corrected conductivity Measured variable status • Measured values 1 •...
Page 187 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 275 I/O module 1 to n defective Change I/O module • Conductivity • Corrected conductivity Measured variable status • Measured values 1 • Measured values 2 Quality •...
Page 188 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 302 Device verification active Device verification active, please wait. • Conductivity • Corrected conductivity Measured variable status [from the factory] • Measured values 1 •...
Page 189 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 332 Writing in HistoROM backup failed Replace user interface board • Conductivity Ex d/XP: replace transmitter • Corrected conductivity Measured variable status • Measured values 1 •...
Page 190 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 373 Sensor electronic (ISEM) faulty 1. Transfer data or reset device • Conductivity 2. Contact service • Corrected conductivity Measured variable status • Measured values 1 •...
Page 191 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 376 Sensor electronic (ISEM) faulty 1. Replace sensor electronic module • Conductivity (ISEM) • Corrected conductivity Measured variable status [from the factory] 2. Turn off diagnostic message •...
Page 192 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 382 Data storage 1. Insert T-DAT • Conductivity 2. Replace T-DAT • Corrected conductivity Measured variable status • Measured values 1 • Measured values 2 Quality •...
Page 193: Diagnostic Of Configuration
Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 512 Sensor electronic (ISEM) faulty 1. Check ECC recovery time • Conductivity 2. Turn off ECC • Corrected conductivity Measured variable status • Density •...
Page 194 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 410 Data transfer 1. Check connection • Conductivity 2. Retry data transfer • Corrected conductivity Measured variable status • Measured values 1 • Measured values 2 Quality •...
Page 195 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 437 Configuration incompatible 1. Restart device • Conductivity 2. Contact service • Corrected conductivity Measured variable status • Measured values 1 • Measured values 2 Quality •...
Page 196 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 442 Frequency output 1 to n 1. Check process – 2. Check frequency output settings Measured variable status [from the factory] Quality Good...
Page 197 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 453 Flow override Deactivate flow override • Conductivity • Corrected conductivity Measured variable status • Density • Electronic temperature Quality Good • Flow velocity...
Page 198 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 486 Current input 1 to n simulation Deactivate simulation • Measured values 1 • Measured values 2 Measured variable status • Measured values 3...
Page 199 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 494 Switch output simulation 1 to n Deactivate simulation switch output – Measured variable status Quality Good Quality substatus Coding (hex) 0x80 to 0x83...
Page 200 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 520 I/O 1 to n hardware configuration invalid 1. Check I/O hardware configuration – 2. Replace wrong I/O module Measured variable status 3. Plug the module of double pulse output...
Page 201: Diagnostic Of Process
Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 594 Relay output simulation Deactivate simulation switch output – Measured variable status Quality Good Quality substatus Coding (hex) 0x80 to 0x83 Status signal...
Page 202 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 833 Electronic temperature too low Increase ambient temperature • Conductivity • Corrected conductivity Measured variable status [from the factory] • Measured values 1 •...
Page 203 Proline Promag P 500 PROFINET Diagnostics and troubleshooting Diagnostic information Remedy instructions Influenced measured variables Short text 842 Process limit Low flow cut off active! • Flow velocity 1. Check low flow cut off configuration • Mass flow Measured variable status [from the factory] •...
Page 204 Diagnostics and troubleshooting Proline Promag P 500 PROFINET Diagnostic information Remedy instructions Influenced measured variables Short text 938 EMC interference 1. Check ambient conditions regarding • Conductivity EMC influence • Corrected conductivity Measured variable status [from the factory] 2. Turn off diagnostic message •...
Page 205: Pending Diagnostic Events
Proline Promag P 500 PROFINET Diagnostics and troubleshooting 12.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 206: 12.10 Event Logbook
Diagnostics and troubleshooting Proline Promag P 500 PROFINET / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  43 Taking the example of the local display To call up the measures to rectify a diagnostic event: • Via local display →  175 •...
Page 207: 12.10.2 Filtering The Event Logbook
Proline Promag P 500 PROFINET Diagnostics and troubleshooting 12.10.2 Filtering the event logbook Using the Filter options parameter you can define which category of event message is displayed in the Events list submenu. Navigation path Diagnostics → Event logbook → Filter options Filter categories •...
Page 208: 12.11 Resetting The Measuring Device
Diagnostics and troubleshooting Proline Promag P 500 PROFINET Info number Info name I1514 Upload started I1515 Upload finished I1618 I/O module 2 replaced I1619 I/O module 3 replaced I1621 I/O module 4 replaced I1622 Calibration changed I1624 Reset all totalizers...
Page 209: 12.12 Device Information
Proline Promag P 500 PROFINET Diagnostics and troubleshooting 12.12 Device information The Device information submenu contains all parameters that display different information for device identification. Navigation "Diagnostics" menu → Device information ‣ Device information Device tag →  209 →  209...
Page 210: 12.13 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: • Product root: e.g. 5P5B The product root is the first part of the order code: see the nameplate on the device.
Page 211: Maintenance
Replacement seals (accessory part) →  244 13.2 Measuring and test equipment Endress+Hauser offers a wide variety of measuring and test equipment, such as W@M or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services. List of some of the measuring and testing equipment: →  214 13.3...
Page 212: Repair
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 213: Disposing Of The Measuring Device
Proline Promag P 500 PROFINET Repair WARNING Danger to persons from process conditions. ‣ Beware of hazardous process conditions such as pressure in the measuring device, high temperatures or aggressive fluids. 2. Carry out the mounting and connection steps from the "Mounting the measuring device"...
Page 214: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 215: For The Sensor
Proline Promag P 500 PROFINET Accessories Display guard Is used to protect the display against impact or scoring from sand in desert areas. Proline 500 – digital  Order number: 71228792  Installation Instructions EA01093D Ground cable Set, consisting of two ground cables for potential equalization.
Page 216: Service-Specific Accessories
Accessories Description Applicator Software for selecting and sizing Endress+Hauser measuring devices: • Choice of measuring devices for industrial requirements • Calculation of all the necessary data for identifying the optimum flowmeter: e.g. nominal diameter, pressure loss, flow velocity and accuracy.
Page 217: System Components
Proline Promag P 500 PROFINET Accessories 15.4 System components Accessories Description Memograph M graphic The Memograph M graphic data manager provides information on all the relevant data manager measured variables. Measured values are recorded correctly, limit values are monitored and measuring points analyzed. The data are stored in the 256 MB internal memory and also on a SD card or USB stick.
Page 218: Technical Data
Technical data Proline Promag P 500 PROFINET Technical data 16.1 Application The measuring device is only suitable for flow measurement of liquids with a minimum conductivity of 5 µS/cm. Depending on the version ordered, the measuring device can also measure potentially explosive, flammable, poisonous and oxidizing media.
Page 219 Proline Promag P 500 PROFINET Technical data Recommended Nominal diameter Factory settings flow min./max. full Full scale value scale value Pulse value Low flow cut off current output (v ~ (~ 2 pulse/s) (v ~ 0.04 m/s) (v ~ 2.5 m/s) 0.3/10 m/s)
Page 220 • Reference density for calculating the mass flow Various pressure transmitters and temperature measuring devices can be ordered from Endress+Hauser: see "Accessories" section →  217 It is recommended to read in external measured values to calculate the corrected volume flow.
Page 221 Proline Promag P 500 PROFINET Technical data Status input Maximum input values • DC –3 to 30 V • If status input is active (ON): R >3 kΩ Response time Configurable: 5 to 200 ms Input signal level • Low signal: DC –3 to +5 V •...
Page 222: Output
Technical data Proline Promag P 500 PROFINET 16.4 Output Output signal PROFINET Standards In accordance with IEEE 802.3 Current output 4 to 20 mA Signal mode Can be set to: • Active • Passive Current range Can be set to: •...
Page 223 Proline Promag P 500 PROFINET Technical data Assignable measured • Volume flow variables • Mass flow • Corrected volume flow Frequency output Maximum input values DC 30 V, 250 mA (passive) Maximum output current 22.5 mA (active) Open-circuit voltage DC 28.8 V (active)
Page 224 Technical data Proline Promag P 500 PROFINET Maximum switching • DC 30 V, 0.1 A capacity (passive) • AC 30 V, 0.5 A Assignable functions • Off • On • Diagnostic behavior • Limit value: • Off • Volume flow •...
Page 225 Proline Promag P 500 PROFINET Technical data Pulse/frequency/switch output Pulse output Failure mode Choose from: • Actual value • No pulses Frequency output Failure mode Choose from: • Actual value • 0 Hz • Defined value (f 2 to 12 500 Hz)
Page 226 Technical data Proline Promag P 500 PROFINET Light emitting diodes (LED) Status information Status indicated by various light emitting diodes The following information is displayed depending on the device version: • Supply voltage active • Data transmission active • Device alarm/error has occurred •...
Page 227: Power Supply
Proline Promag P 500 PROFINET Technical data Supported functions • Identification & Maintenance Simple device identification via: • Control system • Nameplate • Measured value status The process variables are communicated with a measured value status • Blinking feature via the onsite display for simple device identification and assignment •...
Page 228: Performance Characteristics
Technical data Proline Promag P 500 PROFINET Terminals Spring-loaded terminals: Suitable for strands and strands with ferrules. Conductor cross-section 0.2 to 2.5 mm (24 to 12 AWG). Cable entries • Cable gland: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) •...
Page 229: Installation
Proline Promag P 500 PROFINET Technical data Influence of ambient Current output temperature Temperature coefficient Max. 1 μA/°C Pulse/frequency output Temperature coefficient No additional effect. Included in accuracy. 16.7 Installation Chapter "Mounting requirements" →  23 16.8 Environment Ambient temperature →...
Page 230: Process
Technical data Proline Promag P 500 PROFINET Vibration broad-band random, according to IEC 60068-2-64 Order code for "Sensor junction housing", option L "Cast, stainless" and order code for "Sensor option", option CG "Extended neck for insulation" • 10 to 200 Hz, 0.003 g •...
Page 231 Proline Promag P 500 PROFINET Technical data [°F] [°C] 40 60 80 100 120 140 160 [°C] [°F] A0029347  46 Ambient temperature Medium temperature Colored area: the ambient temperature range –10 to –20 °C (+14 to –4 °F) applies to stainless flanges only Hatched area: harsh environment only for medium temperature range –20 to +130 °C (–4 to +266 °F)
Page 232 Technical data Proline Promag P 500 PROFINET Pressure-temperature An overview of the pressure-temperature ratings for the process connections is ratings provided in the "Technical Information" document Pressure tightness Liner: PFA Nominal diameter Limit values for absolute pressure in [mbar] ([psi]) for medium temperatures:...
Page 233: 16.10 Mechanical Construction
Proline Promag P 500 PROFINET Technical data Flow limit The diameter of the pipe and the flow rate determine the nominal diameter of the sensor. The optimum velocity of flow is between 2 to 3 m/s (6.56 to 9.84 ft/s). Also match the velocity of flow (v) to the physical properties of the fluid: •...
Page 234 Technical data Proline Promag P 500 PROFINET Nominal diameter EN (DIN), AS ASME [mm] [in] Pressure rating [kg] Pressure rating [kg] Pressure rating [kg] PN 16 Class 150 12.7 – PN 16 19.5 Class 150 – PN 16 23.5 Class 150 23.5...
Page 235 Proline Promag P 500 PROFINET Technical data Nominal Pressure rating Process connection internal diameter diameter ASME AS 2129 AS 4087 PTFE (DIN) [mm] [in] [bar] [psi] [bar] [bar] [bar] [mm] [in] [mm] [in] PN 40 Class 150 Table E PN 16 1.89...
Page 236 Technical data Proline Promag P 500 PROFINET Cable entries and adapters Material Cable gland M20 × 1.5 Plastic • Adapter for cable entry with internal thread G ½" Nickel-plated brass • Adapter for cable entry with internal thread NPT ½"...
Page 237 Proline Promag P 500 PROFINET Technical data JIS B2220 Stainless steel, F316L ; carbon steel, A105/A350 LF2 AS 2129 Table E • DN 25 (1"): carbon steel, A105/S235JRG2 • DN 40 (1 ½"): carbon steel, A105/S275JR AS 4087 PN 16...
Page 238: 16.11 Human Interface
Technical data Proline Promag P 500 PROFINET 16.11 Human interface Languages Can be operated in the following languages: • Via local operation English, German, French, Spanish, Italian, Dutch, Portuguese, Polish, Russian, Turkish, Chinese, Japanese, Korean, Bahasa (Indonesian), Vietnamese, Czech, Swedish •...
Page 239 Proline Promag P 500 PROFINET Technical data Service interface →  94 Supported operating tools Different operating tools can be used for local or remote access to the measuring device. Depending on the operating tool used, access is possible with different operating units and via a variety of interfaces.
Page 240 Technical data Proline Promag P 500 PROFINET • Flash firmware version for device firmware upgrade, for instance • Download driver for system integration • Visualize up to 1000 saved measured values (only available with the Extended HistoROM application package →  243) Web server special documentation →...
Page 241: 16.12 Certificates And Approvals
The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. Ex approval The devices are certified for use in hazardous areas and the relevant safety instructions are provided in the separate "Safety Instructions"...
Page 242 • With the identification PED/G1/x (x = category) on the sensor nameplate, Directive Endress+Hauser confirms conformity with the "Essential Safety Requirements" specified in Appendix I of the Pressure Equipment Directive 2014/68/EU. • Devices not bearing this marking (PED) are designed and manufactured according to good engineering practice.
Page 243: 16.13 Application Packages
The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 244: 16.14 Accessories
For an overview of the scope of the associated Technical Documentation, refer to the following: • W@M Device Viewer (www.endress.com/deviceviewer): Enter the serial number from nameplate • Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2D matrix code (QR code) on the nameplate Standard documentation Brief Operating Instructions...
Page 245 Proline Promag P 500 PROFINET Technical data Contents Documentation code cCSAus IS XA01524D cCSAus Ex e ia/Ex d ia XA01525D cCSAus Ex nA XA01526D INMETRO Ex i XA01527D INMETRO Ex ec XA01528D NEPSI Ex i XA01529D NEPSI Ex nA XA01530D...
Page 246: Index
Index Proline Promag P 500 PROFINET Index Context menu Calling up ......81 About this document .
Page 247 Proline Promag P 500 PROFINET Index Document Flow limit ....... . 233 Function .
Page 248 Index Proline Promag P 500 PROFINET Manufacturer ID ......99 Operable flow range ......220 Manufacturing date .
Page 249 Proline Promag P 500 PROFINET Index Status input (Submenu) ....117 Screw tightening torques ..... . 30 Status input 1 to n (Submenu) .
Page 250 Index Proline Promag P 500 PROFINET Configuration backup ..... 145 Terminal assignment of connecting cable for Proline Current input 1 to n ..... . 158 500- digital Data logging .
Page 251 Proline Promag P 500 PROFINET Index WLAN settings ......143 Workplace safety ......10 Write access .
Page 252 www.addresses.endress.com...

Endress+Hauser Proline Promag P 500 PROFINET Operating Instructions Manual

1 About this Document

2 Safety Instructions

3 Product Description

4 Incoming Acceptance and Product

Identification

5 Storage and Transport

6 Installation

7 Electrical Connection

8 Operation Options

9 System Integration

10 Commissioning

11 Operation

12 Diagnostics and Troubleshooting

13 Maintenance

14 Repair

15 Accessories

16 Technical Data

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Endress+Hauser Proline Promag P 500 PROFINET

Summary of Contents for Endress+Hauser Proline Promag P 500 PROFINET
