Easy-Laser E420 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E420
MANUAL
English
05-0629 Revision 2.0
System version 6.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E420 and is the answer not in the manual?

Questions and answers

Related Manuals for Easy-Laser E420

Summary of Contents for Easy-Laser E420

  • Page 1 E420 MANUAL English 05-0629 Revision 2.0 System version 6.0...

  • Page 3: Table Of Contents

    CONTENT INTRODUCTION Service and calibration Travelling with your measurement system DISPLAY UNIT Navigation buttons Function buttons Status bar Screen dump LED lights Battery Charge the Display unit Charge measuring units Calculator Measurement file handling Save file File manager Open file as template Copy file to USB memory Barcode Print file (Optional)
  • Page 4 PROGRAM VALUES Tolerance Zoom Half or Zero set value Live values – colours Automatic recording Calibration check HORIZONTAL Mount the units Bluetooth® Enter distances Measure using Easy Turn™ Measure using 9-12-3 Result and adjust Live values Thermal compensation Tolerance SOFTFOOT VERTICAL Preparations Measure...

  • Page 5: Introduction

    INTRODUCTION Damalini AB Damalini AB develops, manufactures and markets Easy-Laser measurement and ® alignment equipment based on laser technology. We have more than 25 years of experience from measurement tasks in the field and product development. We also provide measurement service, which means that we ourselves use the equipment we develop, and continuously improve it.
  • Page 6 Extended warranty Easy-Laser® Measurement and Alignment Systems meet the highest quality standards! For this reason, we have extended the warranty to you to a total of 3 years — free of...

  • Page 7: Service And Calibration

    Service and Calibration. Before sending your measuring system to our main Service centre, please fill in the online Service and Repair report. www.easy-laser-service.com Manuals as PDF You can download our manuals in pdf format from our website. The pdf’s are also available on the USB memory stick that is delivered with most systems.

  • Page 8: Travelling With Your Measurement System

    For information about Easy-Laser® batteries, please see system unit details in the end of this manual. It is also good practice to remove the batteries from the equipment, when possible, e.g.

  • Page 9: Display Unit

    DISPLAY UNIT Press and hold the On/Off button to reset the Display unit. Battery info See “LED lights” on page 8 On/Off Escape OK button Navigation buttons Numeric buttons Function buttons External power USB A (master) Escape Escape will either return to start view, or close active window (for example file man- ager) and return to previous view.

  • Page 10: Navigation Buttons

    Display unit Navigation buttons To navigate on the screen, use the navigation buttons. The selected icon is marked with a yellow frame. The navigation buttons are also used to move between the icons in a submenu and to change the values in the fields. Escape Navigation buttons OK button...

  • Page 11: Status Bar

    Measurement progress. Time is depending on which filter you have selected. Selected filter. Peripheral. Indicates that a peripheral device is plugged in, such as a projector. Not available for E420. Bluetooth . Indicates that the Bluetooth functionality is activated. ®...

  • Page 12: Screen Dump

    Display unit Screen dump It is possible to take screen dumps of what is currently displayed on screen. You can e-mail the screen dump or use it for reports. Take a screen dump 1. Press and hold the numeric button period (.) for 5 seconds. 2.

  • Page 13: Battery

    Display unit Battery Select to display the Battery view. This view gives you a good overview of the battery status of all connected equipment. Display unit Detector or Measuring unit Serial number Charging Battery symbols correspond to the LED signals on the Display unit. The E-series is not compatible with units from the D-series.

  • Page 14: Calculator

    Display unit Calculator The calculator is found on the Start view and Control panel ( 1. Select to open the calculator. 2. Use the numerical buttons and function buttons to enter values. 3. Use the button to compute. Select to display sub-menu Use OK button as equal sign (=) Unit converter The unit converter is found on the Start view and Control panel (...

  • Page 15: Measurement File Handling

    A measurement file. “Screen dump” on page 8 A report. The PDF report can not be opened in the Display unit. PDF is not available for E420. Function buttons Back to previous view. “Open file as template” on page 12.

  • Page 16: Open File As Template

    Display unit Open file as template You can open a saved measurement and use it to make a new measurement. This is very useful when you have many flanges or machines with the same dimensions for example. This way you do not have to enter the same distances every time. 1.

  • Page 17: Print File (Optional)

    Display unit Print file (Optional) Part no. 03-1004 The thermal printer is optional equipment. 1. Save the measurement. To print from a Shaft program, you need to open a saved measurement before you can print a report. 2. Connect the thermal printer and select 3.

  • Page 18: Control Panel

    Display unit Control panel Select to open the Control panel. Some of the settings are personal and will be default next time you start the system. Note! All settings are not available for all systems. Filter Select to open the Filter view. If the laser beam passes through air with varying temperature, this may influence the direction of the laser beam.

  • Page 19: Unit And Resolution

    Default is set to 0.01 mm (0.4 mil). The selected unit is shown on the Status bar. Note! It is possible to select 0.0001mm only in the E940 system. For E420, only 0.01mm is possible. Date and time Select to open the Date and Time view. Set the date and time. Default is set to Central European Time.

  • Page 20: Language

    Display unit Language Personal setting Select to open the Language view. Default is set to English. Use the navigation buttons to select a language. Press to save changes. Language view User Select to open the Users view. A user account is used for storing your personal settings.
  • Page 21 Display unit Automatic sleep mode Personal setting Select to open the Automatic sleep mode view. Select how much time before automatic sleep mode. Use the navigation buttons to select. Press OK to save changes. See also “On/Off” on page 5. Information Select to display the information regarding serial number and version of the...

  • Page 22: System Update

    Display unit System update Download update file 1. Go to www.damalini.com > Download > Software > E series Display unit Firmware Update. 2. Download the update file to your PC. 3. Unzip the file. 4. Copy the .elu file to the root of a USB memory. Save .elu file on a USB memory.

  • Page 23: License

    Display unit License It is easy to upgrade your Display unit. 1. Contact your Easy-Laser distributor if you wish to upgrade your Display unit. ® 2. An e-mail will be sent to you with information on how to download the update file.

  • Page 24: Bluetooth® Set Up

    1. Select to open the Bluetooth view. ® 2. Select to search for Bluetooth units. ® 3. The view is updated with the Easy-Laser Bluetooth units you can connect to. ® ® Searching for Bluetooth units ® 4. Select the unit you want to connect to and select .
  • Page 25 Display unit Use only one Bluetooth unit ® Many of our systems are delivered with two Measuring units. In some cases you might want to use only one unit together with a laser transmitter. By default both units are set to “Connect ”.

  • Page 27: Choose Program

    CHOOSE PROGRAM Preparations Before starting a measurement, there are several things that are good to check to ensure a good and accurate measurement. • Ensure a good measurement environment. Strong sunlight, warning lights, vibra- tions and temperature gradients can affect the readings. •...
  • Page 29 PROGRAM VALUES With the program Values, you can see live readings from the detectors. As default, a target and a table is displayed. Press OK to register values. Live vertical values Detector or Measuring unit Registered values Serial number Use the navigation Unit one (out of two connected) buttons to scroll Target...
  • Page 30 Program values Tolerance 1. Select to set tolerance. It is possible to set different tolerance in vertical and horizontal direction. 2. Use navigation buttons to move between the fields and to change the tolerance. 3. Press OK. Live values and marking displayed in Live values displayed in red when green when within tolerance.
  • Page 31 Program values Edge warning When the laser beam is close to the edge, the edge is “lit up” as a warning. It is not possible to register values when you see the edge warning. Half or Zero set value Half value Zero set value Absolute value Select...
  • Page 32 Program values Automatic recording In Values, it is possible to make automatic recording of values. This is very useful when you want to register values during a longer time period for example. 1. Select to start automatic recording. 2. Set Interval. 3.
  • Page 33 Program values Calibration check Use the program Values to check if the detector readings are within specified tolerances. Quick check 1. Set the tolerance to 0.01 mm (0.5mil). 2. Select and show targets for both M- and S-unit. 3. Select to zero set value.
  • Page 35 HORIZONTAL For horizontally mounted machines. Select between two different measuring methods: EasyTurn Start anywhere on the turn. The three measuring positions can be reg- istered with as little as 20º between positions. By default, the EasyTurn program is shown. See “Measure using Easy Turn™” on page 35. 9-12-3 The measuring positions are registered at positions 9, 12, 3 o’clock.
  • Page 36 Horizontal Mount the units 1. Mount the S-unit on the stationary machine and the M-unit on the movable machine. 2. Mount the units facing each other. Make sure they are at the approximately same rotational angle. Laser adjustment knob On/Off button Connection for charging cable Locking knob Hook for the chain...
  • Page 37 Horizontal Adjust measuring units Place the Measuring units on the rods, make sure they are at the approximately same rotational angle. You need to place the measuring units with an offset, see image. Also make sure that the adjustment knob is adjustable in both directions. Image showing measuring units for E530 system.
  • Page 38 Horizontal Enter distances Confirm each distance with Distance between S-unit and M-unit. Measure between the rods. Distance between S-unit and centre of coupling. Distance between M-unit and feetpair one. Distance between feetpair one and feetpair two. Coupling diameter. Optional, select to activate field.
  • Page 39 Horizontal Measure using Easy Turn™ Preparations Follow the preparations as described in the previous pages. 1. Mount the measuring units. 2. Enter distances, confirm each distance with OK. 3. If needed, perform a rough alignment. 4. If needed, perform a Softfoot check. Measure It is possible to measure with as little as 40º...
  • Page 40 Horizontal Measure using 9-12-3 Preparations Follow the preparations as described in the previous pages. 1. Mount the measuring units. 2. Enter distances, confirm each distance with OK. 3. If needed, perform a rough alignment. 4. If needed, perform a Softfoot check. Measure 1.
  • Page 41 See “Tolerance” on page 41. See “Thermal compensation” on page 40. RefLock, lock feet. Note! Not available for E420. Show target. This is a quick way to see where the laser beam hits the target and how the measuring units are positioned.
  • Page 42 Horizontal Live values When reading the values, face the stationary machine from the movable machine. Positions for measuring units as seen from the movable machine. Live values are marked with yellow frame. Face the stationary machine (S) from the movable machine (M). Then 9 o’clock is to the left, as in the measuring programs. Offset and angle values The offset and angle value indicate how well the machine is aligned at the coupling.
  • Page 43 Horizontal Adjust Adjust the machine if needed. 1. Shim the machine according to the vertical feet values. 2. Adjust the machine sideways according to the live horizontal values. 3. Tighten the feet. 4. Select to remeasure. Position indicator To adjust, you need to place the measuring units in live position (9, 12, 3 or 6 o’clock). Select to show the Position indicator.
  • Page 44 Horizontal Thermal compensation During normal operation, machinery is influenced of different factors and forces. The most common of these changes is the change in the temperature of the machine. This will cause the height of the shaft to increase. This is called thermal growth. To com- pensate for thermal growth, you enter values for cold condition compensation.
  • Page 45 Horizontal Tolerance 1. Select . The tolerance window is displayed. 2. Select a tolerance and press GAP values Add user defined tolerance Function buttons Close Tolerance view. See “Control panel” on page 14. Edit user defined tolerance. Delete user defined tolerance. Add new tolerance You can add your own user defined tolerance.
  • Page 46 Horizontal Tolerance table The rotation speed of the shafts will decide the demands on the alignment. The table on this side can be used as a guidance if no other tolerances is recommended by the manufacturer of the machines. The tolerances is set to the maximum allowed deviation from accurate values, with no consideration to if that value should be zero or compensated for thermal growth.
  • Page 47 SOFTFOOT Perform a softfoot check to ensure that the machine is resting evenly on all its feet. A softfoot can be angular and/or parallel, see image. Softfoot can be caused by: • Twisted machinery foundations. • Twisted or damaged machinery feet. •...
  • Page 48 Toggle button to switch machine. To check Softfoot, distances between feet pairs are necessary. If needed, the Enter distance view is displayed. Not available for E420. Remeasure Softfoot. Continue to Measure view, only available when you have started Softfoot from the...
  • Page 49 VERTICAL The program Vertical is used for vertical and/or flange mounted machines. Preparations 1. Mount the M-unit on the movable machine and the S-unit on the stationary machine. 2. Select to open Vertical program. 3. Enter distances. Confirm each distance with If you have a barcode reader, simply scan the barcode and all machine data is read.
  • Page 50 Vertical Measure The program Vertical uses the 9-12-3 method. 1. Position the units at 9 o’clock, at bolt number one. Make sure that it is possible to also position the units at 12 and 3 o’clock. 2. Press to register first position. The first position is automatically set to zero. 3.
  • Page 51 Vertical Result The result is displayed as sideways offset in the coupling and angular error between shafts. Live values in Live values in the 9-3 direction the 6-12 direction Live values The values can be displayed live in two directions: •...
  • Page 52 Vertical Shim result view To view this, you need to enter number of bolts and diameter of bolt circle. 1. Select to open Shim value view. The values are not live. 2. Read values. The highest bolt is calculated as 0.00. Values below zero indicates that the bolt is low and need shimming.
  • Page 53 TECHNICAL DATA System Easy-Laser® E420 Shaft, Part No. 12-0745 A complete system contains Measuring unit M Measuring unit S Display unit Shaft brackets with chains Set of rods 4x60 mm, 4x120 mm [4.72”, 2.36”] Measuring tape 3 m Power adapter (100–240 V AC)
  • Page 54 Technical Data Display unit E53 Part no. 12-0748 In the Display unit you are guided through the measurement procedure and can save and analyze the results. Battery info See “LED lights” on page 8 On/Off Escape OK button Navigation buttons Numeric buttons Function buttons Display unit...
  • Page 55 Technical Data Measuring units Part no. 12-0746 Part no. 12-0747 On/Off Laser aperture Connector for charger cable See “LED lights” on page 8 The rods have a height of PSD (20 mm/0.78”) 120–180 mm. They can be extended with accessory rods. Made of stainless steel.
  • Page 56 Technical Data...
  • Page 57 INDEX Angular misalignment 38 PDF 12 Personal settings 15 Position indicator 37, 39 Bar-code 13 Print 14 Barcode 8 Projector 7 Battery view 9 Bluetooth® 7, 21 Buttons 5, 5 Resolution 16 Rotate coordinates 7 Rough alignment 33 Calibration 3 Calibration check 29 Convert units 11 Screen dump 8...
