ADVANTAGE AIR MyAir 4 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Smart Home Systems
User Manual
V2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MyAir 4 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADVANTAGE AIR MyAir 4 Series

Summary of Contents for ADVANTAGE AIR MyAir 4 Series

  • Page 1 Smart Home Systems User Manual V2.0...

  • Page 3: Table Of Contents

    MyAir User Manual Contents 1 - INTRODUCTION 2 - MODE SCREEN 3 - ZONES SCREEN 4 - MYZONE (OPTIONAL) 5 - MOTION ZONE (OPTIONAL) 6 - CONSTANT ZONES 7 - FRESH AIR (OPTIONAL) 8 - PLANS SCREEN 9 - PLANS EDIT SCREEN 10 - SETUP SCREEN 11 - TROUBLESHOOTING 12 - SMART DEVICE CONTROL...

  • Page 4: Introduction

    1 - INTRODUCTION Welcome to your new MyAir 4 smart air-conditioning system. The information provided in this user manual will help you get the most from your new air- conditioning system. The MyAir 4 app runs on its own dedicated wall-mounted touch screen which is permanently powered and attached to your wall.

  • Page 5: Mode Screen

    2 - MODE SCREEN The mode screen on the MyAir tab allows you to control your air-conditioner’s operation mode. From the mode screen you can perform the following actions: • Turn the air-con unit ON or OFF; • Set an ON or OFF timer; •...
  • Page 6 MODE SCREEN Simple Timer The simple timer can be used to turn the air- con unit ON or OFF after a set time. Each press of the Timer button increases the time by 30 or 60 mins (up to 12 hours). Pressing the trash icon clears the timer.

  • Page 7: Zones Screen

    3 - ZONES SCREEN Press the Zones button on the menu bar to bring up the zones screen. MyZone Temperature Zone Motion Zone Airflow Zone Pressing a zone name toggles that zone between ON and OFF. Zones are ON when they are the blue colour. There are four different types of zones in MyAir depending on the option you selected when purchasing your system.

  • Page 8: Myzone (Optional)

    4 - MYZONE (OPTIONAL) The MyZone feature makes that particular zone the “information centre” for the air-conditioning unit. That means the set-point for that zone becomes the set- point the air-conditioning unit will work toward. The actual measured temperature of that zone is the temperature sent to the unit for it to make its decisions about whether to start/stop or speed up/down to effectively achieve the set-point while maintaining constant airflow in the MyZone.

  • Page 9: Motion Zone (Optional)

    5 - MOTION ZONE (OPTIONAL) Motion controlled zones vary the temperature in unoccupied zones in order to save energy on air-conditioning empty spaces. For example: You are cooling your home with the master bedroom zone target temp set at 24 with motion enabled.

  • Page 10: Constant Zones

    6 - CONSTANT ZONES Depending on your specific installation, your MyAir system may be set up with electronic constant zones. These are pre-programmed zones that open up to relieve excess air pressure in your air-conditioning system if insufficient zones are open.

  • Page 11: Fresh Air (Optional)

    7 - FRESH AIR (OPTIONAL) If your system is fitted with the optional fresh air feature, you will find a button at the bottom of your zones screen as pictured below. Turning ON fresh air will enable your system to draw in air from outside the home. This feature is particularly useful when the outside temperature is pleasant, such as in the evenings.

  • Page 12: Plans Screen

    8 - PLANS SCREEN Plans allow you to set your air-conditioner up just the way you like it. This even includes which zones to have turned ON and their air flow or target temperature setting. Once your plan is captured, you can have it activated automatically at any time on any day.

  • Page 13: Plans Edit Screen

    9 - PLANS EDIT SCREEN After pressing the Add button you will enter the plans edit screen to add a new plan. From the plans edit screen you can perform the following actions: • Name your plan; • Enable / Disable your plan; •...
  • Page 14 Times Plan will start / stop Set up new Plan PLANS EDIT SCREEN 1. Configure Aircon(s) and Zones to the required setup*. Then press to add a new Plan. *See other help pages for Aircon and Zone setup. Review the Capture Here’s the Plan...

  • Page 15: Setup Screen

    10 - SETUP SCREEN Rename Zones Press this button to change the zone names. You will be presented with a list of all your zones. Press any zone to edit the name. You can use the symbols & or . plus any combination of letters, numbers or spaces.

  • Page 16: Troubleshooting

    SETUP SCREEN Tech Setup This button is used by your air-conditioning professional to configure and commission your system on the day of installation; there are no user settings in this menu. Status Window Warnings about your air-conditioning system will be displayed here, such as low battery warnings for your temperature sensors or air-conditioning unit error codes.

  • Page 17: Smart Device Control

    12 - SMART DEVICE CONTROL MyAir 4 allows you to control your MyAir 4 system from your Android or Apple phone after installing the MyAir 4 app on your phone. Smart Phone control can be used inside your home via your personal WiFi network or remotely using your phone’s internet connection.
  • Page 18 SMART DEVICE CONTROL 7. Find your home WiFi network in the 8. Enter your home WiFi network list and press it. password and press CONNECT. 9. Once you have connected successfully (may take up to 2 minutes) you will see the word CONNECTED below your home WiFi network name.

  • Page 19: Apple Devices

    Type “MyAir 4” into the search box. d. Press Search. e. Select the MyAir 4 App by Advantage Air (it’s free). f. To install, press the blue GET button, and then the green INSTALL button. g. Enter your Apple ID password (it’s case sensitive).

  • Page 20: Android Devices

    12.2 - ANDROID DEVICES The MyAir 4 Android app requires your device to be running Android OS v4.2 or greater. Please check to ensure you device meets this requirement before continuing below. To start downloading items on the Google Play Store app, you need to add a Google account to your device.

  • Page 21: Remote Access

    13 - REMOTE ACCESS MyAir 4 has the ability to control your system from your Android or Apple smart phone when you are outside of the home WiFi network using your phone’s internet connection (Eg 3G/4G). Remote access requires a reliable WiFi connection between your modem/router and your wall-mounted MyAir 4 tablet.
  • Page 22 REMOTE ACCESS 5. It can take up to 5 minutes before remote access is enabled. While your system is enabling remote access, you will notice the status will change numerous times. Once remote access has been successfully enabled, the status will change to AA26.

  • Page 23: Network Troubleshooting

    14 - NETWORK TROUBLESHOOTING Assistance for the homeowner’s I.T. professional: 1. Verify that the smart phone/tablet device is connected to the home WiFi (not using the phone’s internet connection Eg 4G). Also ensure, the phones WiFi signal strength is strong. 2.
  • Page 24 E: warranty@advantageair.com.au E: service@advantageair.com.au Advantage Air Aust Pty Ltd reserves the right to change specifications, modify designs and discontinue items without obligation. Whilst every effort is made to ensure that descriptions, specifications and other information in this document are correct, no warranty is given in respect thereof and the company shall not be liable for any error therein.
