Installation Instructions
Model:
Description:
Part Number:
Assembly Time:
Before you begin, read through these instructions and check that
all parts are present. Always disconnect negative battery terminal,
prior to installation. Please note that MB Quart cannot assume any
responsibility for damage resulting from incorrect installation.
No.
1
GMR-LED with Housing (MBQT-RAD-1)
2
6.5in Dash Speakers (MBQT-FPOD-1)
3
8" Subwoofer w/Enclosure (MBQT-SUB-1)
4
6.5" Rear Pod Speakers
5
MBQT-ACC-1
6
NA2-400.1 Amplifier
7
NA2-400.2 Amplifier
1
Bojo Tool
2
Panel Clip Pliers
3
10mm open box wrench
4
10mm and 12mm socket
5
½" socket
6
Rachet
7
Small flat head screwdriver
8
Phillips screwdriver
9
3mm and 5mm Allen Wrench
10
¼" and ½" drill bit or stepper bit
11
1" hole saw
12
Drill
13
Rotary tool similar to a Dremel
14
Heat Gun or Lighter
15
Crimper
Honda Talon
Stage 5 Install
MBQT-STG5-1
210 Mins (3.5-Hours)
Parts List
Component Name
Tools Required
Page 1 of 42
Qty
1
2
1
2
1
1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MBQT-STG5-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MB QUART MBQT-STG5-1

Summary of Contents for MB QUART MBQT-STG5-1

  • Page 1 Assembly Time: Before you begin, read through these instructions and check that all parts are present. Always disconnect negative battery terminal, prior to installation. Please note that MB Quart cannot assume any responsibility for damage resulting from incorrect installation. Parts List...
  • Page 2 Disassembly ● Remove hood by turning two latches ● Remove four 10mm bolts, four push pins, and five 5mm allen bolts to remove top of dash ● Remove half mud guard with six push pins Page 2 of 42...
  • Page 3 Disassembly ● Release latch at front of driver and passanger lower cushions to remove ● Remove two 12mm bolts on front of drivers seat ● Slide driver seat forward and remove two 12mm bolts on rear of seat Page 3 of 42...
  • Page 4 Disassembly ● Remove drivers seat ● Remove two push pins on front of passenger seat and then remove the covers ● Remove two 12mm bolts and two 12mm nuts on the passenger seat base Page 4 of 42...
  • Page 5 Disassembly ● Remove passenger seat from vehicle ● Pull top fuse access panel toward front of vehicle and remove Page 5 of 42...
  • Page 6 Disassembly ● Using a small flat head screwdriver push in the center and remove the six clips on the passenger side ● Remove the five push pins on the driver side console like on the passenger side ● Place gear selector to “H” and remove the top of the center console Page 6 of 42...
  • Page 7 Disassembly ● Lift up the bottom half of the steering column rubber boot ● Remove the two push pins behind the rubber boot ● Remove the two push pins on the bottom of steering column cover Page 7 of 42...
  • Page 8 Disassembly ● Remove the bottom steering wheel cover ● Remove one 5mm allen bolt and one push pin from the drivers kick area ● Remove two 5mm allen bolts from behind glove box door Page 8 of 42...
  • Page 9 Disassembly ● Remove one push pin in the back of the glove box ● Remove three push pins from below the glove box ● Remove glove box Page 9 of 42...
  • Page 10 Disassembly ● Remove one 5mm allen bolt and one push pin from passenger kick area ● Remove rear cargo area by turning two latches ● Remove the air intake cover from the passenger rear fender area by removing ten push pins (Each location to follow) Page 10 of 42...
  • Page 11 Disassembly ● Remove two lower push pins ● Remove two upper push pins. (Arrow one is not pictured) ● Remove three push pins from inner lip of fender Page 11 of 42...
  • Page 12 Dash Speaker Installation ● Remove two push pins from outer fender ● Remove two push pins behind the passenger rear shock ● Pull down or remove air intake cover Page 12 of 42...
  • Page 13 Front Speaker Pod Installation ● Drill a ½” hole, 5/8” down from the edge, and 2 ¼” over (Control the depth of bit to not go to deep) ● Pass the wire from the driver side pod through the hole you drilled ●...
  • Page 14 Front Speaker Pod Installation ● Install the M6 x 40mm bolt and washer through the enclosure into the factory bolt location ● Tighten the 5/16” bolt in the fender area ● Repeat previous steps on passenger side Page 14 of 42...
  • Page 15 Radio & Dash Kit Installation ● Place the metal u-bracket at the top of the pocket and mark the bottom portion to be cut out with a rotary tool ● Drill two ¼” holes using the u-bracket as a guide in the back of the pocket ●...
  • Page 16 Radio & Dash Kit Installation ● Slide the dash panel with the bevel and MB Quart logo facing outward like the image ● Pass the wires from the radio through the hole below the u-bracket in the pocket ● Install four M4 cap head bolts...
  • Page 17 Radio & Dash Kit Installation ● Install covers on each side of radio Page 17 of 42...
  • Page 18 Amplifiers and Plate Installation ● Adjust the NA2-400.2 amplifiers gain and crossover settings as pictured. NOTE Gains all to the last “L” on Level HPF to 100Hz going just past “P” on LP LPF is turned all the way down X-Over to HP ●...
  • Page 19 Amplifiers and Plate Installation ● Install the NA2-400.2 amplifier as pictured with four M4 Philips screws, washers, and lock nuts ● Install the rubber c-clamp around the tube as pictured ● Slide the top amplifier mount between the frame and top of dash as pictured Page 19 of 42...
  • Page 20 Amplifiers and Plate Installation ● Install the M6 button head bolt through the plate and c-clamp attaching from the bottom with a washer and lock nut ● Install the NA2-400.1 amplifier next to the two channel amplifier and secure with three M4 Philips screws, washers, and lock nuts NOTE May need to shift amplifier plate...

  • Page 21: Wiring Installation

    Wiring Installation ● Connect the speaker harness to the NA2-400.2 amplifier and route the driver and passenger speaker leads to the appropriate kick area ● Connect bullets of amplifier harness with respective front kick pods ● Plug subwoofer extension harness into the NA2-400.1 amplifier Page 21 of 42...
  • Page 22 Wiring Installation ● Route subwoofer and rear speaker harnesses down toward center console going to the rear of the vehicle NOTE Use a fish tape passed from cabin toward front of vehicle to help pull wires ● Zip tie harnesses along with OEM harness ●...
  • Page 23 Wiring Installation ● Connect the rear speaker y-harness ● Zip tie wires in center console along the OEM harness ● Pass the wires through the rear firewall and upward between airbox and firewall Page 23 of 42...
  • Page 24 Wiring Installation ● Follow OEM wiring on each side zip tieing speaker harnesses moving toward tail lights ● Zip tie wiring along OEM wiring ● Drill ½” hole on either side of the bed area as shown Page 24 of 42...
  • Page 25 Wiring Installation ● Install power harness to each amplifier (Connector with bullets connects to NA2-400.2) ● Connect bullets from power harness to speaker harness (This is if you want to add optional LED rings at the speaker locations) ● Connect Delphi connector on power harness into the radio harness Page 25 of 42...
  • Page 26 Wiring Installation ● If you don’t already have a buss bar installed you can connect to factory wiring (but we highly recommend a buss bar kit) These are available from many aftermarket companies like XTC Power Products ● Plug RCA into the NA2-400.2 and run to the front RCA outputs of the radio ●...
  • Page 27 Wiring Installation ● Drill a 1” hole in the side of the glovebox 3” from the front for the USB / AUX Port ● Place the glove box back in the vehicle (We will install hardware during assembly portion of the manual) ●...

  • Page 28: Subwoofer Installation

    Subwoofer Installation ● Install four brackets with 5/16” bolts and washers leaving them loose ● Place subwoofer enclosure under driver seat area and pass the harness through small opening pictured and pull toward top of center console Page 28 of 42...
  • Page 29 Subwoofer Installation ● Connect the subwoofer enclosure harness to the amplifier harness in center console ● Align plates to seat mount holes and tighten CORRECT ALIGNMENT INCORRECT ALIGNMENT ● All plates aligned Page 29 of 42...
  • Page 30 Rear Speaker Pod Installation ● Place the appropriate rubber insert for your tube diameter in the clamps ● Attach the pod to the roll cage at your desired location and secure with four M6 bolts tightening with a 5mm allen wrench (Repeat process for other pod) ●...
  • Page 31 Rear Speaker Pod Installation ● Crimp the speaker harness to the pod harness ● Use a heat gun or lighter to shrink the connector Page 31 of 42...
  • Page 32 Reassembly ● Push up and install air intake cover ● Install two push pins behind the passenger rear shock ● Install two push pins from outer fender Page 32 of 36...
  • Page 33 Reassembly ● Install three push pins from inner lip of fender ● Install two upper push pins. (Arrow one is not pictured) ● Install two lower push pins Page 33 of 46...
  • Page 34 Reassembly ● Install the air intake cover from the passenger rear fender area by installing ten push pins (Each location to follow) ● Install rear cargo area by turning two latches ● Install three push pins from below the glove box Page 34 of 46...
  • Page 35 Reassembly ● Install one push pin in the back of the glove box ● Install two 5mm allen bolts from behind glove box door ● Install the bottom steering wheel cover Page 35 of 46...
  • Page 36 Reassembly ● Install the two push pins on the bottom of steering column cover ● Install the two push pins behind the rubber boot ● Reposition bottom half of the steering column rubber boot Page 36 of 42...
  • Page 37 Reassembly ● Place gear selector to “H” and install the top of the center console ● Install the five push pins on the driver side console like on the passenger side ● Using a small flat head screwdriver push in the center and install the six clips on the passenger side Page 37 of 42...
  • Page 38 Reassembly ● Install top fuse access panel ● Install passenger seat from vehicle ● Install two 12mm bolts and two 12mm nuts on the passenger seat base Page 38 of 42...
  • Page 39 Reassembly ● Install two push pins on front of passenger seat and then remove the covers ● Install drivers seat ● Slide driver seat forward and install two 12mm bolts on rear of seat Page 39 of 42...
  • Page 40 Reassembly ● Install two 12mm bolts on front of drivers seat ● Release latch at front of driver and passanger lower cushions to install ● Install new full mud guard with kit with 6 push pins previously removed and 8 new push pins in Page 40 of 42...
  • Page 41 Reassembly ● Install four 10mm bolts, four push pins, and five 5mm allen bolts to remove top of dash ● Install hood by turning two latches Page 41 of 42...
  • Page 42 The Bluetooth ® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use such marks by MB Quart is under license. All product names, logos, and brands are property of their respective owners. All company, product and service names used in this literature are for identification purposes only.
