Summary of Contents for iLive IVFSD400X
- Page 1 IVFSD400X Dishwasher Operating & Installation Manual...
-
Page 2: Table Of Contents
CONTENTS Technical specifications …………………………………………………….. • Conformity with the standards and Test data …………………………….. 4 • Safety information and Recommendations………………………………….. Recycling ..………………………............• Safety information …………………………………………………………… • Recommendations …...……………………………………………………… • Items not suitable for dishwashing ………………………………………… • Installing the machine ………………………………………………………….. Positioning the machine …………………………………………………….. - Page 3 Loading your dishwasher .……………………………………………………. Top basket…………………………………………………………………... • Alternative basket loads …………………………………………………... • Programme descriptions .…………………………………………………….. Programme items ………………………………………………………….. • Getting familiar with your machine ………………………………………… Switching on the machine and selecting a programme……………..Switching on the machine…………………………………………………. • Programme follow-up ……………………………………………………… •...
- Page 4 Worktop Upper basket with racks Upper spray arm Lower basket Lower spray arm Filters Rating plate Control Panel Detergent and rinse-aid dispenser Cutlery basket Upper basket track latch Super i e r in...
-
Page 5: Technical Specifications
Technical specifications Capacity 1 place settings Height 8 0 mm Height 820 mm (without worktop) Width 598 mm Depth 598 mm Net Weight 4 kg Electricity input 220-240 V, 50 Hz Total Power 00 W Heating Power 800 W Pump Power 100 W Drain Pump Power 30 W... -
Page 6: Safety Information And Recommendations
SAFETY INFORMATION AND RECOMMENDATIONS Recycling • Certain components and the packaging of your machine have been produced from recyclable materials. • Plastic parts are marked with international abbreviations: (>PE< , >PS< , >POM<, >PP<, ) • Cardboard parts have been produced from recycled paper and they should be disposed of into waste paper collection containers for recycling. - Page 7 • Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. • Pay special attention and be sure that the machine does not stand on the electricity supply cable. •...
- Page 8 mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.Cleaning and user maintenance shall not be made by children without supervision.
-
Page 9: Recommendations
For your children’s safety • After removing the machine’s packaging, make sure that the packaging material is out of reach of children. • Do not allow children to play with or start the machine. • Keep your children away from detergents and rinse aids. •... -
Page 10: Items Not Suitable For Dishwashing
Items not suitable for dishwashing: • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials; • Forks, spoons and knives with wooden or bone, or ivory or nacre-coated handles; glued items,items soiled with abrasive, acidic or base chemicals. • Plastic items that are not heat-resistant, copper or tin-coated containers. -
Page 11: Water Connections
Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. Do not grip the machine by its door or panel in order to move Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back and forth during cleaning. -
Page 12: Water Inlet Hose
Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection. -
Page 13: Water Outlet Hose
Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink. -
Page 14: Electrical Connection
Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur. -
Page 15: Fitting The Machine Undercounter
Fitting the machine undercounter If you wish to fit your machine undercounter, check whether you have sufficient space under your countertop and whether the wiring-plumbing is suitable to do so.1 If you decide that the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration. - Page 16 Adjust the machine feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or bent.4 Product Without Insulation With Insulation All Product For 2nd Basket For 3rd Basket Height 820 mm 830mm 835 mm Warning: After removal of worktop, the machine should be placed in such a closed place of which dimensions are shown at fig.
- Page 17 In accordance with the level determined on the test strip, perform the water hardness adjustment of your appliance as speci ed below. • hen the machine is off, press the program button (2). • Press the On Off button (1) to switch on the machine and press and hold the pro- gram button (2) for at least seconds.
- Page 18 Detergent usage Use a detergent specifically designed for use in domestic dishwashers. You can find powder,gel,and tablet detergents in the market that have been designed for household dishwashers. Detergent should be put into the compartment prior to starting the machine. Keep your detergents in cool, dry places out of reach of your children.
- Page 19 Observe the instructions on packagings when using such products. • If such detergents are in the form of tablets, never put them into the interior section or the • cutlery basket of the dishwasher. Always put the tablets into the detergent compartment in the detergent dispenser.
-
Page 20: Loading Your Dishwasher
Level Brightener Dose Indicator Rinse-aid not dispensed r1 is shown on the display. 1 dose is dispensed r2 is shown on the display. 2 doses are dispensed r3 is shown on the display. 3 doses are dispensed r4 is shown on the display. 4 doses are dispensed r5 is shown on the display. -
Page 21: Alternative Basket Loads
Alternative basket loads Lower Basket Top basket... - Page 22 Faulty loads Important Note for Test Laboratories For detailed information on performance tests, please contact following address: "dishwasher@standardte ” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door.
- Page 23 Program Definition Program No 4 (reference) Program No apid ash 0 min. Delicate Wash Eco (Economical) mode Temperatures 40°C 40°C 50°C Food residue type Coffee, milk, tea, cold Coffee, milk, tea, cold Coffee, milk, tea, cold meat, vegetables (not meat, vegetables (not meat, vegetables (not left for a long time) left for a long time)
- Page 24 Program Definition Program No Program No Super 50 min. Temperatures 65 C 65 C Food residue type Soups, sauces, pastries, Soups, sauces, pastries, eggs, pilaf, potatoes, eggs, pilaf, potatoes, oven dishes, and fries oven dishes, and fries Soil level Medium High Amount of detergent B: 25 cm3 / 15 cm3 A: 5 cm3...
- Page 25 Selection of programme and Starting of the Machine You can press the On/Off button (4) When the hygiene function (8) is active, to switch on the product. On/off lights will you can make the washing process be on so long as the machine is on. Press more hygienic by changing the washing the program button (5) to set the suitable temperature and durations of the current...
- Page 26 PROGRAMME SELECTION AND OPERATING THE MACHINE Operating the Machine If you have used any extra function in the washing program that you last used, that function will be active in the next washing program. If you want to cancel that function for the newly selected program, press and hold the button of the relevant function since the corresponding lights go off, or press the...
- Page 27 Changing the Program Cancelling the Program When you want to change the program When you want to cancel the program while a washing program is running on. while a washing cycle is running on. Press and hold the Start/ Press Start/Pause button. Pause button for 3 seconds.
-
Page 28: Maintenance And Cleaning
MAINTENANCE AND CLEANING Note: If the machine door opens during washing or the power is cut off, the machine will go on to the program in case the door is shut or the power is back. Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. -
Page 29: Spray Arms
Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left. -
Page 30: Failure Codes And What To Do In Case Of Failure
FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE ERROR CODE ERROR DESCRIPTION CONTROL Make sure the water input tap is totally open and that there is no water cut. • Inadequate water supply Close the water input tap, separate the water input hose from the tap and clean the filter at •... - Page 31 If one of program monitor lights is on and start/Pause light is on and off, Your machine’s door is open, shut the door. If the programme won’t start Check if the plug is connected. • Check your indoor fuses. • Be sure that the water inlet tap is turned on.
- Page 32 A detergent without phospate used; try one that contains phosphate. • If the dishes won't dry up A programme without a dry operation selected. • Rinse aid dosage set too low • Dishes unloaded too fast. • If there are rust stains on the dishes Stainless-steel quality of the dishes washed is insufficient.
- Page 34 ILVE LIMITED WARRANTY Eurolinx Pty Limited A.B.N. 50 001 473 347 trading (a) damage through misuse (including failure to as ILVE (“ILVE”) maintain, service or use with proper care), neglect, Office: 48-50 Moore Street, Leichhardt N.S.W 2040 accident or ordinary wear and tear (including Post: Locked Bag 3000, Annandale, N.S.W 2038 deterioration of parts and accessories and glass P: 1300 MY ILVE (694 583)
- Page 35 ILVE LIMITED WARRANTY 6. Claiming under the Warranty You are entitled to a replacement or refund for a major Customers will bear the cost of claiming under this failure and for compensation for any other reasonably Warranty unless ILVE determines the expenses are foreseeable loss or damage.
- Page 36 52241598 R30...
