  • Page 1 PURE Electric Vehicle PuR Energy Pvt Ltd...
  • Page 2 Before you begin riding, please go through this manual to familiarize yourself with the mechanism and controls of the ETRANCE NEO , and with its proper care and maintenance to ensure a long trouble-free ride. Keeping the batteries in good health is vital for the economy and reliability of the ETRANCE NEO Enjoy the PURE ride! COPYRIGHTS ©...
  • Page 3 Damages to the product, other property or any persons are the responsibility of the buyer and/or rider. By using this product manufactured by or sold under license granted by PURE EV , you...

  • Page 4: Table Of Contents

    PURE Electric Vehicle Content 1 About ETRANCE NEO ......... 1 6 Mandatory Road Signs ........25 Specifications & Features ........1 7 Trouble Shooting ..........26 ETRANCE NEO Kit ...........1 Smart Lock ..............4 2 PURE Lithium Battery ........11 Critical..............11 Important ...............

  • Page 5: About Etrance Neo ......................................... 1 6 Mandatory Road Signs

    Specifications & Features Alloy Rim 60 Kmph Top Speed 60 V Vector Looped Controller Motor: 1.5 KW nominal and 2.2 KW Peak 2.5 KWh Patented High Performance PURE Lithium 67.2V, 10 A Charger Battery Comfortable Seat for 2 PAX LED Display Tyre - Front: 90/100-10, Rear: 3.00—10...
  • Page 6 PURE Electric Vehicle Rear View Mirrors Head Light Left Brake Lever Front Storage Space Front Luggage Hook Key Slot (On/Off, Under Seat Storage, Handle lock) Side Stand External Charging Port Center Stand 10. Pillion Footrest 11. Rear Number Plate 12. Grab Rail 13.
  • Page 7 PURE Electric Vehicle Right Side Handle Controls Left-Side Handle Controls Headlight / Back Light (ON / OFF) Horn Switch Switch Side Indicator Switch Horn Switch High / Low Beam Switch Speed Mode Selection Switch Rear Brake Lever Parking Switch Twist Throttle (Accelerator) Front Brake Lever PuR Energy Pvt.

  • Page 8: Smart Lock

    PURE Electric Vehicle Smart Lock Feel modish with the smart locking system for the ETrance NEO The device allows you to ride your ETrance NEO without any key and is loaded with anti-theft abilities. The transponder that is built into the ignition key carries a unique identification code. The vehicle unlocks when the code on the key matches with the code of the receiver inside the vehicle.
  • Page 9 PURE Electric Vehicle Key Operations Vehicle OFF Vehicle ON The key position as Rotate the key shown in the figure is clockwise to turn for turning off the on the vehicle vehicle Open under Seat Storage Handle Lock Ensure the handle...
  • Page 10 PURE Electric Vehicle Battery Level Indicator LED Display Brake Signal Parking Mode / Speedo Meter High Beam Indicator Odometer Speed Mode Parking Mode On PURE EV has integrated additional safety feature of parking mode. The vehicle remains in “Parking Mode”...
  • Page 11 PURE Electric Vehicle LED Display (Error Codes) PuR Energy Pvt. Ltd.
  • Page 12 Press the parking button on the right-hand side (with “P” symbol). • Choose the speed mode as per your comfort • Slowly twist the throttle to get the ETrance NEO moving. • It is mandatory to use a safety helmet to ensure a safe ride.
  • Page 13 Do’s and Don’ts while riding: • The power to the motor cuts off when brakes are applied. Do not hold on to the brakes when you want the ETrance NEO to run. • It is strongly advised not to apply sudden brakes on wet and sandy surfaces.
  • Page 14 PURE Electric Vehicle After Ride • After ride, turn off the ignition and remove the keys. Ensure, switching off the vehicle using both remote and key. • It is advisable to use the center stand for vehicle to be kept stand still for longer duration.

  • Page 15: Pure Lithium R Battery

    Do not recharge the battery pack near fire or in extremely hot weather. • Do not leave the battery for unattended or overnight charging. • To recharge the battery pack, use the battery charger specifically designed for the purpose and observe the recharging conditions specified by PURE EV PuR Energy Pvt. Ltd.

  • Page 16: Important

    PURE Electric Vehicle • Do not pierce the battery pack with a nail or other sharp objects, strike it with a hammer, or step on • Do not strike or throw the battery pack. • Do not use an apparently damaged or deformed battery pack.

  • Page 17: Battery Health Tips

    To maximize the battery and charger life, please refer the Battery care and precautions mentioned above. • The charger supplied with your ETrance NEO should only be used for the purpose of charging the battery of the ETrance NEO . Do not use it for any other purposes.
  • Page 18 PURE Electric Vehicle • When not in use, it is recommended to charge the battery every 30 days. • It is mandatory to attend all the camps conducted by the company without fail. • So also, all the upgradations(paid/free) shall be carried out to ensure better health of the vehicle.

  • Page 19: Etrance Neo Charger

    PURE Electric Vehicle ETRANCE NEO Charger The charger provided with the Li-Ion battery is sophisticated and is a special purpose electronic charger. This charger has an additional protective feature which provides protection from output overvoltage, output overcurrent and short-circuit. Fuse...

  • Page 20: Charging Your Li-Ion Battery

    PURE Electric Vehicle Charging your Li-ion Battery • Ensure that the location for charging the battery must be dry, clean, safe, ventilated and dustproof. • Do not place the charger on the battery. • Connect input mains supply plug to the 230V/50hz supply socket with proper grounding.
  • Page 21 PURE Electric Vehicle Steps to Charge Battery Inside the Vehicle 1. Ensure the vehicle ignition is 2. The battery is placed inside the 3. MCB is ON vehicle and properly connected **Do not use extension box 4. Three pin connector of the 5.
  • Page 22 PURE Electric Vehicle Steps to Charge the Battery Away from the Vehicle 1. Ensure the vehicle ignition 3. Disconnect Battery Power 2. MCB is turned OFF is OFF Plug Socket 5. Connect the Charger to the 6. Connect the plug to a three 4.

  • Page 23: Important Safety Information

    PURE Electric Vehicle Important Safety Information Misusing or Incorrect connection to the Battery Charger may Damage the equipment or create Hazardous conditions for user. Read the following Safety instructions and pay special attention to all caution WARNINGS • Use the supplied charger only to charge LITHIUM-ION Batteries. Other uses may cause personal injury and damage.

  • Page 24: Service Policy

    It is mandatory to avail all free and paid service as per the given schedule to claim both the vehicle and individual component level warranty. • The service can be availed only at our PURE EV authorised dealership. • In free service, the labour cost for doing periodic maintenance is free. However, other jobs requested by the customer but not covered in the maintenance schedule are chargeable at actual during the Free service period.

  • Page 25: Warranty Policy: Scope Of Warranty

    • Warranty claim is applicable only to the first owner of the Vehicle. • The vehicle must be sold and serviced by an authorized PURE EV dealer. • The warranty registration card of each vehicle must be filled out by the dealer at the time of delivery of the vehicle, and dealer should retain a counterfoil of the same.
  • Page 26 24 business hrs with the dealer for the same. • PURE EV Reserves the right to carry out the replacement of the defective part with the same part manufactured by another vendor, which is also used by PURE EV •...
  • Page 27 This warranty is not applicable to rental or commercial use of the product. • This warranty exclusively covers systems and components provided by PURE EV . The use of spare parts from unknown sources, like replacement parts from third parties deems the warranty void.
  • Page 28 The content in this subject of warranty may be changed without any notice. All rights are reserved by PURE EV . No one is allowed to make copies of, reproduce, change or modify any part or all the content of warranty without expressed permission of PURE EV PuR Energy Pvt. Ltd.
  • Page 29 PURE Electric Vehicle Mandatory Road Signs PuR Energy Pvt. Ltd.

  • Page 30: Trouble Shooting

    PURE Electric Vehicle Trouble Shooting YouTube Videos by PURE EV We have a YouTube channel, where videos for troubleshooting are uploaded. These videos will help as additional assistance in case of any defect or problem in the circumstances where technical assistance or authorized service centers are not available.
  • Page 31 Notes...
  • Page 32 ETRANCE NEO WARRANTY REGISTRATION CARD (DEALER COPY) OWNER’S NAME: ADDRESS 1: ADDRESS 2: MAIL ID: MOBILE NO: + 9 1 CITY: STATE: BATTERY NO: MOTOR NO: VIN NO: SOLD ON DEALER CODE: STAMP & SIGNATURE DEALER CUSTOMER SIGNATURE...
  • Page 34 ETRANCE NEO WARRANTY REGISTRATION CARD (CUSTOMER COPY) OWNER’S NAME: ADDRESS 1: ADDRESS 2: MAIL ID: MOBILE NO: + 9 1 CITY: STATE: BATTERY NO: MOTOR NO: VIN NO: SOLD ON DEALER CODE: STAMP & SIGNATURE DEALER CUSTOMER SIGNATURE...
  • Page 36 FREE SERVICE COUPON ETRANCE NEO (Valid if serviced within 1000 – 1100km or 30 – 45 days from date of sale, whichever earlier.) VIN No: Motor No: Battery No: Customer Name: _______________________________________ Contact Number: _________________ Serviced On: yyyy Sold On:...
  • Page 38 FREE SERVICE COUPON ETRANCE NEO (Valid if serviced within 4300 – 4500km or 90 – 105 days from date of sale, whichever earlier.) VIN No: Motor No: Battery No: Customer Name: _______________________________________ Contact Number: _________________ Serviced On: yyyy Sold On:...
  • Page 40 FREE SERVICE COUPON ETRANCE NEO (Valid if serviced within 8000 – 8500km or 210 – 225 days from date of sale, whichever earlier.) VIN No: Motor No: Battery No: Customer Name: _______________________________________ Contact Number: _________________ Serviced On: yyyy Sold On:...
  • Page 42 FREE SERVICE COUPON ETRANCE NEO (Valid if serviced within 12000 – 12500km or 300 – 315 days from date of sale, whichever earlier.) VIN No: Motor No: Battery No: Customer Name: _______________________________________ Contact Number: _________________ Serviced On: yyyy Sold On:...
  • Page 44 Service Records: Service Distance (Km) Odometer Job Card Date Dealer Sign and Code / Time (Days) Reading Number Free Free Free Free Paid *Please ensure to get this filled by the dealer after every service.
  • Page 45 Service Records: Service Distance (Km) Odometer Job Card Date Dealer Sign and Code / Time (Days) Reading Number Paid Paid Paid Paid Paid *Please ensure to get this filled by the dealer after every service.
  • Page 46 Battery Service Records (Batrics Faraday Service Inward Capacity Outward Capacity Dealer Sign and Code (Ah) (Ah) Free Free Free Free Paid *Please ensure to get this filled by the dealer after every service.
  • Page 47 Battery Service Records (Batrics Faraday Service Inward Capacity Outward Capacity Dealer Sign and Code (Ah) (Ah) Paid Paid Paid Paid Paid *Please ensure to get this filled by the dealer after every service.
  • Page 48 ANNEXURE 1 PROPER CHARGING PROTOCOL Do’s It is recommended to only use the charger provided by the company for charging the batteries. Ensure location for charging the battery must be dry, clean, safe, and dustproof. Connect input mains supply plug to the 230V/50hz supply wall socket with proper grounding. Make sure the earthing is connected.
  • Page 49 In case of long-term storage, remove the battery from the vehicle and store it away from any heat source or direct sunlight, in a well ventilated, dry, and dust-free room. In case of long-term storage, store the batteries at 40% state of charge (SOC). Charge the battery at least once in a month when not in regular use.
  • Page 50 EXPOSURE CONTROL AND PERSONAL PROTECTION Acceptable Not Specified W.R.T Lithium batteries Concentration Facilities Respiratory Self-Contained Berthing Apparatus for organic gasses. Protection Hands Protection Safety Gloves Eye Protection Safety Glasses FIRST AID MEASURES (IN CASE OF ELECTROLYTE LEAKAGE FROM THE BATTERY) Eye contact Flush the eyes with plenty of clean water for at least 18 minutes immediately, without rubbing.
  • Page 51 To recharge the battery pack, use the battery charger specifically designed for the purpose and observe the recharging conditions specified by PURE EV Do not pierce the battery pack with a nail or other sharp objects, strike it with a hammer, or step on it Do not strike or throw the battery pack.
  • Page 52 DECLARATION I,______________________________________, would like to confirm that I have been explained and understood the above mentioned instructions / protocols for safety of PURE Lithium battery. Further I commit to abide by them. Customer Signature Dealer Stamp &...
  • Page 53 Notes...
  • Page 54 www.pureev.in All the trademarks are owned by PUR ENERGY PVT LTD. The company has the rights to change any specifications, designs or features of the products at any point of time without any prior intimation and without any liability. For more details of our products please visit the company website.
