T ono
R A I L S H O W E R
444116
WELS 3 Star rated, 9L/min
Rail:
Slider to adjust height and angle of hand shower
●
Made from solid brass
●
1.5 metre stainless steel hose
●
(PVC on matte black model)
TONO Hand Piece (MSH116):
Three water-flow settings: normal, massage or combination
●
Easy to clean TPR nozzles
●
Made from ABS
●
IMPORTANT: Please read all of the instructions before installation. Check the product thoroughly for damage. Installation is acceptance
of goods supplied and will void warranty. This product is pre-assembled. Do not disassemble, as this may void the warranty.
Specifications
Please refer to fienza.com.au for the latest product specifications before installing.
Operating Pressure
Min: 150 kPa / 1.5 bar
Max: 500 kPa / 5 bar
Optimum: 150 kPa / 1.5 bar - 500 kPa / 5 bar
Installation of pressure limiting valve recommended
if supply exceeds 500kPa
Operating Temperature
Hot: Max 80°C
Cold: Min. 5°C
Inlet Connections
1/2" BSPP
Suitable Hot Water Units
Storage tank and continuous flow only.
Not suitable for gravity feed.
WELS Rating
3 Star rated, 9L/min
General Information
This product must be installed by a qualified licensed plumber in accordance with AS/NZS 3500 and all applicable local regulations
●
and plumbing codes.
All pipe work must be thoroughly flushed prior to installation.
●
Do not remove the ceramic cartridge from the mixer when installing.
●
After installation all hoses and connections must be checked for leaks.
●
It is the responsibility of the installer to ensure a waterproof seal is achieved between the product and mounting surface.
●
F IEN ZA .COM. AU
I N S TA L L AT I O N G U I D E
28
700
43.5
Item Code: 444116 | Updated: 01/04/2024
60
5.8
28
G1/2
1.5 metre
long hose
Advertisement
Related Manuals for Fienza Tono 444116
Summary of Contents for Fienza Tono 444116
- Page 1 This product is pre-assembled. Do not disassemble, as this may void the warranty. Specifications Please refer to fienza.com.au for the latest product specifications before installing. Operating Pressure Min: 150 kPa / 1.5 bar Max: 500 kPa / 5 bar Optimum: 150 kPa / 1.5 bar - 500 kPa / 5 bar...
- Page 2 I N S TA L L AT I O N G U I D E Installation IMPORTANT: Before commencing installation, turn off the water supply. While not essential, we recommend fitting isolation valves to both the hot ● and cold-water supply. Some showers may not provide an effective shower when used with gravity fed heated water systems or where pressures are less than ●...
- Page 3 I N S TA L L AT I O N G U I D E Joint Slider Body Hand Shower Outlet Hose Screw Cleaning & Care We recommend weekly cleaning with mild soapy water and a microfibre cloth. In highly polluted or coastal locations we recommend cleaning 2-3 times per week.
- Page 4 Conditions for On-Site Warranty Service Calls Fienza will charge a service fee for each visit to an installation by its technician where it is determined that the fault is due to poorly executed or unlicensed installation work or where the product is not a genuine Fienza product or where the product is outside the warranty period.
