  • Page 1 SMAJAYU(SHENZHEN) CO.,LTD SMAJAYU R26-V2 base User Manual SMAJAYU(SHENZHEN) CO.,LTD Address:Room 213-214, Building 1, Mingliang Science Park, No. 88, Zhuguang Web: www.smajayu.com North Road, Taoyuan Street, Nanshan District, Shenzhen, China,518055. Eml: support@smajayu.com & tech@smajayu.com...

  • Page 2: Table Of Contents

    SMAJAYU(SHENZHEN) CO.,LTD CONTENT Preface ..................................2 The R26-V2 base can be used for two purposes: ..............2 1. R26-V2 Device ..............................2 1.1 Device List ............................... 2 1.2 Device Hardware ...........................2 1.3 R26-V2 Main Body: ..........................4 2 R26-V2 as base station ........................... 6 2.1 Set R26-V2 as base station .......................6...

  • Page 3: Preface

    SMAJAYU(SHENZHEN) CO.,LTD Preface The R26 base can be used for two purposes: 1. Work as a radio base station or mobile station with other radio RTK or agricultural systems; 2. For static measurements This article will explain these two usages in detail Tip: After you receive the new machine, press and hold the power button to turn it on.
  • Page 4 SMAJAYU(SHENZHEN) CO.,LTD Ⅱ. Data Cable POW/COM plug which connects to R26-V2. DC power supply plug. DB9 data configuration plug. USBD raw data export and save plug. Address: Room 213, Building 1, Mingliang Science Park, No. 88, Zhuguang North Road, Taoyuan Street, Nansh Web：...

  • Page 5: R26-V2 Main Body

    SMAJAYU(SHENZHEN) CO.,LTD Ⅲ. Power Adapter nput: British Standard Plug. Output: DC Plug. Ⅳ. Radio Antenna Frequency: 450-470MHZ. Dimension: 280mm. Ⅴ. Device Box 1.3 R26-V2 Main Body: Figure 6 R26-V2 Main Body Address: Room 213, Building 1, Mingliang Science Park, No. 88, Zhuguang North Road, Taoyuan Street, Nansh Web：...
  • Page 6 SMAJAYU(SHENZHEN) CO.,LTD Still recording button: Press and hold for 4 seconds to turn on or off the still recording mode : Recorder light: red, flashes when the static recording mode is turned on, otherwise off. : Satellite light: red, RTK Fix is flash..

  • Page 7: R26-V2 As Base Station

    2 R26-V2 as base station NOTE: 1. If you buy R26-V2 base+rover, then you will receive two R26s, one R26 is set as Base, and the other is set as Rover (For Rover settings, please refer to Section 3.1 and 3.2 in the R26-V2 rover user manual) 2.

  • Page 8: Static Measurement Guide

    SMAJAYU(SHENZHEN) CO.,LTD (3) Device --> Base --> Set the protocol(CSS) and frequency of the base station --> Set Base Startup，See the picture below. Tips: The unactivated software can only simply set the base station or mobile station, if you want to unlock all the surveying and mapping functions, please contact us to buy R26-V2 rover + handheld to get the activated software.

  • Page 9: Static Measurement Data Export

    SMAJAYU(SHENZHEN) CO.,LTD 3.2 Static measurement steps ⑴ Set up R26-V2 at the control point ⑵ Record the instrument number, point name, instrument height and start time. ⑶ Power on, set R26-V2 to static mode (two ways) ①Press and hold the still recording button for 4 seconds to turn on still recording mode.
  • Page 10 SMAJAYU(SHENZHEN) CO.,LTD (2)The computer will pop up the disk, and you will copy the. dat measurement file in the disk to the folder you specified. Address: Room 213, Building 1, Mingliang Science Park, No. 88, Zhuguang North Road, Taoyuan Street, Nansh Web：...
  • Page 11 SMAJAYU(SHENZHEN) CO.,LTD (2) Open the software and perform the following operations to convert the file. Software download link： Software download link: https://www.dropbox.com/sh/2xwlnanxgatdt0u/AAA0rxWEzxeWC9vPmaSkxytha?dl=0 Address: Room 213, Building 1, Mingliang Science Park, No. 88, Zhuguang North Road, Taoyuan Street, Nansh Web： www.smajayu.com...
  • Page 12 SMAJAYU(SHENZHEN) CO.,LTD Address: Room 213, Building 1, Mingliang Science Park, No. 88, Zhuguang North Road, Taoyuan Street, Nansh Web： www.smajayu.com an District, Shenzhen...
  • Page 13 SMAJAYU(SHENZHEN) CO.,LTD Address: Room 213, Building 1, Mingliang Science Park, No. 88, Zhuguang North Road, Taoyuan Street, Nansh Web： www.smajayu.com an District, Shenzhen...
