SELWOOD D150R Operating & Service Manual

SELWOOD D150R
Operating & Service Manual
The products of Selwood Limited, are designed,
developed and produced in the company's Chandler's
Ford factory Many features are covered by worldwide
patents. Product names such as Spate, Simplite and
Seltorque, are registered trademarks.
As all products are subject to continuous development,
the company reserves
specifications and information given in this manual
without prior notice.
Whilst every care has been taken in the preparation of
this publication the information it contains must not be
regarded as binding.
Amendments to this publication will only be issued to
cover those design changes, which fundamentally alter
the build or operation and servicing procedures. They
will be distributed through the company's dealers and
agencies.
Your attention is drawn to the following symbols used
throughout this manual:-
CAUTION
This caution symbol draws attention to special
instructions or procedures that, if not correctly
followed, may result in damage to, or destruction of
equipment.
WARNING
This warning symbol draws attention to special
instructions or procedures that, if not strictly
observed, may result in personal injury.
WARNING
A WARNING SYMBOL WITH THIS TYPE OF
TEXT DRAWS ATTENTION TO SPECIAL
INSTRUCTIONS OR PROCEDURES WHICH, IF NOT
STRICTLY OBSERVED MAY RESULT IN SEVERE
PERSONAL INJURY, OR LOSS OF LIFE.
Additional copies of this manual are available
from Selwood Pt No 1508030000
Published by Selwood Limited
© Selwood Limited January 2008
Instructions for Ordering
Replacement Parts
1. Always quote the pump serial number located on
the plate fastened to the bearing and air pump
mechanism housing.
2. Always quote the part number(s) (ten digits) of the
component(s), NOT the item number(s).
3. Always quote the description of the component(s).
Items usually supplied together as sub-assemblies will
have the sub-assembly part number printed at the
bottom of the relevant page.
Selwood D150 Manual
the right to alter the
HEALTH AND SAFETY AT WORK 1974
As manufacturers of pumps and associated equipment
we wish to inform you that, in compliance with Section
6 of the Act, safety precautions should be taken with
our products.
We take every care to ensure as is reasonably
practicable that our products are safe and without risk
to health when properly used.
appropriate health and safety precautions must be
taken, and in particular you are requested to have
special regard to the
requirements leaflet P769, which accompanies each
pump on despatch from our premises.
Our products also conform to the EEC Machinery
Safety Directive and carry the C.E. mark.
CALIFORNIA USA
PROPOSITION 65 WARNING
Diesel engine exhaust and some of its
constituents are known to the State of
California
defects, and other reproductive harm.
Pumps and engines may be fitted with
seals or 'O' rings manufactured from
VITON or similar material.
When temperatures
(720° F) a corrosive acid is produced,
which cannot be removed from the skin.
If signs of material decomposition are
evident, or if in doubt, always wear
disposable heavy-duty gloves.
Nevertheless,
operational and safety
to cause cancer, birth
WARNING
reach 400° C
