Graseby
Model 500
®
and Graseby
Micro 505
Volumetric Infusion Pump
Technical User
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Graseby 500 and is the answer not in the manual?

Questions and answers

Related Manuals for Smiths Graseby 500

Summary of Contents for Smiths Graseby 500

  • Page 1 ® Graseby Model 500 ® and Graseby Micro 505 Volumetric Infusion Pump Technical User Manual...

  • Page 2: Table Of Contents

    S m i t h s M e d i c a l C o n t e n t s C o n t e n t s Who should read this manual ................. 1 Introduction ....................... 1 Contents of the box ................... 2 Checking labels and serial number ..............

  • Page 3: Who Should Read This Manual

    Manual, available on request from information are not needed by most Smiths Medical. users, so they are separated into this stand-alone manual. W h o s h o u l d r e a d t h i s m a n u a l You should be familiar with the use of •...

  • Page 4: Contents Of The Box

    The pump should not be used if damage is evident. Contact your Smiths Medical Service Department V o l u m e t r i c I n f u s i o n P u m p...

  • Page 5: Checking Labels And Serial Number

    Epidural Label Set for the Volumetric replacement parts. Infusion Pump (part number TPF-00306) is available from Smiths Medical. V o l u m e t r i c I n f u s i o n P u m p...

  • Page 6: Functional Inspections And Tests

    T e c h n i c a l U s e r M a n u a l S m i t h s M e d i c a l F u n c t i o n a l i n s p e c t i o n s a n d t e s t s Perform the following tasks when you Power up and self test have taken the pump out of the...
  • Page 7 If any of the following faults occur prime a ‘Standard Adult Set, 8C-820’ with a new pump, contact your (non-checkvalve 20 drop/mL) Smiths Medical Service Department. administration set Product Code • if any LEDs do not light in steps 1, 3 21-0346-25 for the following tests.
  • Page 8 If you have a new pump and it does 6. Press the Run key and then press not behave as described here, the Options key. Verify that the contact your Smiths Medical message display shows the time Service Department. remaining with a value like the...
  • Page 9 If you have a new pump and it does and push it into its slot. Close the not behave as described here, clamp above the cassette. Then close contact your Smiths Medical the door and silence the alarm when Service Department. this message appears:...

  • Page 10: Setting Up

    T e c h n i c a l U s e r M a n u a l S m i t h s M e d i c a l S e t t i n g u p Battery charging Enabling limits Before using the pump for clinical use,...

  • Page 11: Regular Testing

    T e c h n i c a l U s e r M a n u a l R e g u l a r t e s t i n g In addition to the regular testing requirements listed below, Smiths Medical recommends that a qualified technician should carry out annual...

  • Page 12: Menus

    T e c h n i c a l U s e r M a n u a l S m i t h s M e d i c a l M e n u s There are several menus on the pump, The Biomedical menu some of which have an overlap of This menu is the one that also exists in...

  • Page 13: Technician Menu

    S m i t h s M e d i c a l T e c h n i c a l U s e r M a n u a l Te c h n i c i a n m e n u This menu allows you to define how the You cannot move back through the pump behaves by setting values or by...

  • Page 14: Technician Parameters

    T e c h n i c a l U s e r M a n u a l S m i t h s M e d i c a l Technician parameters The numbers on the left of this table show the number of Options key presses to reach the parameter.

  • Page 15: Using Technician Parameters

    S m i t h s M e d i c a l T e c h n i c a l U s e r M a n u a l Using Technician parameters Most parameters enable or disable can be infused for a Primary infusion.
  • Page 16 T e c h n i c a l U s e r M a n u a l S m i t h s M e d i c a l Enabling this feature allows users to Secondary stop use the Options key to put the pump With this parameter enabled, the pump into a mode in which they can change...
  • Page 17 S m i t h s M e d i c a l T e c h n i c a l U s e r M a n u a l When the pump is in use, if the date set Backlight is reached or exceeded, then the This parameter sets the default for how...

  • Page 18: Biomedical Menu

    T e c h n i c a l U s e r M a n u a l S m i t h s M e d i c a l are displayed for security protection. If B i o m e d i c a l m e n u you make a mistake, you must switch the pump off to enter the correct ID.

  • Page 19: Biomedical Menu Parameters

    S m i t h s M e d i c a l T e c h n i c a l U s e r M a n u a l B i o m e d i c a l m e n u p a r a m e t e r s The numbers in the left hand column of this table indicate the number of Options key presses to reach the parameter.
  • Page 20 T e c h n i c a l U s e r M a n u a l S m i t h s M e d i c a l Screen Notes Shows the current rate Rates of 300, 600, setting of the serial port.

  • Page 21: Service Functions Menu

    S m i t h s M e d i c a l T e c h n i c a l U s e r M a n u a l S e r v i c e F u n c t i o n s m e n u The Service Functions menu allows you Using the Service Functions menu to set the date and time on the pump...

  • Page 22: Service Functions Menu Parameters

    S e r v i c e F u n c t i o n s m e n u p a r a m e t e r s Screen Notes Information for Smiths Medical Service Department use. Use this to set the time 1.

  • Page 23: Sensors Screen

    S m i t h s M e d i c a l T e c h n i c a l U s e r M a n u a l Sensors screen Value = 0 Value = 1 Door Closed Open...

  • Page 24: Specifications

    S p e c i f i c a t i o n S m i t h s M e d i c a l S p e c i f i c a t i o n s General Weight 5 kg (11 pounds).
  • Page 25 Test solution Sterile water or normal saline at room temperature (70°F ±5°/21°C ±3°). Smiths Medical standard (primary), 20 drops/mL, non-checkvalve administration set (8C820). Testing conditions Model 500 Fluid level in the solution container 46 cm (18 inches) above top of the pump, rate set at 999 mL/h and volume to be infused of 49 mL.
  • Page 26 S p e c i f i c a t i o n S m i t h s M e d i c a l Power AC power supply Internally configured for either 100-120 V AC, 200 mA, 50/60 Hz. 220-240 V AC, 80 mA, 50/60 Hz.
  • Page 27 S p e c i f i c a t i o n S m i t h s M e d i c a l Primary and Secondary Infusions: Rate range Model 500 Range Increment 0.1 to 99.9 mL/h 0.1 mL/h 1 to 999 mL/h 1 mL/h...
  • Page 28 S p e c i f i c a t i o n S m i t h s M e d i c a l Volume Over Time Infusions: Rate range Model 500 Range Increment 0.1 to 99.9 mL/h 0.1 mL/h 1 to 999 mL/h 1 mL/h...
  • Page 29 S p e c i f i c a t i o n S m i t h s M e d i c a l Drug amount modes/range Mode Range Increment MG drug/bag 0.01 to 99.99 0.01 0.1 to 999.9 1 to 99999 Gm drug/bag 0.01 to 99.99...
  • Page 30 0.1 to 3.0 mL/h Accessories For a complete list of Administration Sets, please contact Smiths Medical or your local distributor. V o l u m e t r i c I n f u s i o n P u m p...
  • Page 31 S p e c i f i c a t i o n S m i t h s M e d i c a l Symbols used on the pump Front panel symbols Inside battery door symbols Battery is charging/mains Attention: dangerous power applied.

  • Page 32: Standards

    European Council Directive 93/42/EEC concerning medical devices. 0473 The number 0473 identifies the Notified Body under which the Quality Systems operated within Smiths Medical are assessed. Disposal When the time comes to dispose of the pump, its batteries, or any of its accessories, do so in the best way to minimise any negative impact on the environment.

  • Page 33: Trumpet Curves

    Tr u m p e t c u r v e s The curves were developed while The trumpet curve represents the worst testing the Model 500 using a Smiths case rate error in any given observation Medical Standard Adult Set, 8C-820 window over the whole infusion period.
  • Page 34 S p e c i f i c a t i o n S m i t h s M e d i c a l V o l u m e t r i c I n f u s i o n P u m p S —...
  • Page 35 S m i t h s M e d i c a l T e c h n i c a l U s e r M a n u a l - I n d e x I n d e x AC cord retainer 4 Damaged pump 2 Acceptance test 4...
  • Page 36 I n d e x - T e c h n i c a l U s e r M a n u a l S m i t h s M e d i c a l Occlusion Alarm default rate S - 7 approx values of settings S - 7 rate entry parameter 13...
  • Page 37 S m i t h s M e d i c a l T e c h n i c a l U s e r M a n u a l - I n d e x Service Functions menu description 19 Unpacking pump 2 overview 10...
  • Page 38 Smiths Medical International Limited Smiths Medical International Limited Watford, Hertfordshire, UK, WD24 4LG www.smiths-medical.com Made in Malaysia Part No. 0166-0202-D Jan 2005 Smiths Medical - A part of Smiths Group plc © 2005 Smiths Medical family of companies. All rights reserved...
