- Page 1 Home Eamon Ceiling Fan User Manual Read and save these instructions before use Model #51906...
-
Page 2: Package Contents
PACKAGE CONTENTS Canopy Canopy Cover Mounting Bracket Screw (x 4) Mounting Bracket Downrod Downrod Clip Downrod Pin Yoke Cover Set Screw (x 2) Yoke Motor Assembly Blade (x 3) Fitter Plate Fitter Plate Screw (x 3) Light Kit Lens Cover Remote Pack HARDWARE CONTENTS Blade Screw (x 9) -
Page 3: Safety Information
THANK YOU Honeywell Ceiling Fans feature a collection of fans in various sizes and specifications to ensure your choice of indoor or outdoor fan delivers optimum performance for your room’s size. You can trust the quality of Honeywell Ceiling Fans to deliver maximum airflow and stylish lighting options. -
Page 4: Care And Maintenance
SAFETY INFORMATION CAUTION: CAN ICES-003 (B) / NMB-003 (B) CAN ICES-005 (B) / NMB-005 (B) This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device (if applicable). -
Page 5: Initial Installation
PREPARATION Before beginning the assembly of this product, ensure all parts are present. Compare all parts with the package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated assembly time: 2 hours Tools required (not included): Electrical tape, Phillips Screwdriver, Safety Glasses, Step Ladder, and Wire Strippers. - Page 6 STANDARD OR ANGLE MOUNT INSTRUCTIONS 1. Remove the downrod pin and downrod clip from the downrod. Then partially loosen the set screws in the yoke at the top of the motor assembly (Figure 3.1). 2. Insert the downrod through the canopy and yoke cover. Feed the wires and braided cable from the fan through the downrod (Figure 3.2).
-
Page 7: Final Installation
SECONDARY HANGING SYSTEM INSTRUCTIONS For installation in the United States: Building codes in the U.S.A. do not require installation of a Secondary Hanging System. If desired, the braided cable can be cut and removed using wire cutters (sold separately). Skip to FINAL INSTALLATION. For installation in Canada: In compliance with building codes in Canada, installation of the Secondary Hanging System is required. - Page 8 FINAL INSTALLATION 4. Insert blade through slot in the side of the motor assembly. Align the holes of one blade with three blade screw holes in underside of the motor assembly. Secure with three blade screws and blade washers. Repeat this step for the remaining blades (Figure 5.4).
- Page 9 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS 1. To operate the fan using the remote, press and release the following buttons (Figure 6.1): LED Indicator - Indicates the three speeds of the fan. It should illuminate when any remote button is pressed. If not, replace the DC3V, CR2032 batteries.
-
Page 10: Troubleshooting
TROUBLESHOOTING If you experience any faults, please check the Troubleshooting section below. If a problem cannot be remedied or you are experiencing difficulty in installation, please contact Customer Service: 1-877-361-3883, Monday - Friday, 8am - 5pm, Central. WARNING: Shut off the power supply before you begin any maintenance task. PROBLEM CORRECTIVE ACTION 1. -
Page 11: Limited Lifetime Warranty
Blade (x 3) 4A084720003 Remote Pack 4L000016880 HW Hardware Bag 4A000026420 The Honeywell Trademark is used under license from Honeywell International Inc. Honeywell International Inc. makes no representations or warranties with respect to this product. This product is manufactured for Hong Kong China Electric Appliance, LTD.
