- Page 1 QUICK START GUIDE VIENTO 10 AND HD10 USB 603 Portway Avenue, Suite 100 | Hood River, OR 97031 | 855.222.1801 | www.sierraolympia.com Product Export Classification Control Number (ECCN): 60/30Hz: 6A003.b.4.b 9Hz: 6A993 This document does not contain export-controlled technology.
-
Page 2: Safety Conditions
QUICK START GUIDE VIENTO 10 AND HD10 USB TABLE OF CONTENTS Safety Conditions ..................... 1 Export Notice ......................1 Reference Documents ....................2 Introduction ......................2 OEM Base Board ...................... 2 Included Items......................2 Required Equipment ....................3 power ........................3 Set Up ........................ -
Page 3: Reference Documents
Board. Remove the two 0-80 socket head caps screws securing the USB-C Adapter Board and gently pull the Adapter Board straight back to remove it from the stack. In this configuration, all connections to the Viento 10 USB are made through the S2 connector on the OEM Base Board. -
Page 4: Required Equipment
QUICK START GUIDE VIENTO 10 AND HD10 USB o Interface Control Documents 7 REQUIRED EQUIPMENT USB 3.0 Type A to Type C cable or USB 3.0 Type C to Type C cable • 8 POWER The DRS sensor may require more power than some USB 3.0 ports can supply. This will be evident by the camera getting stuck in a reset loop, where you can hear the soft click of the shutter repeatedly trying, and failing, to move. -
Page 5: Revision History
Software (CCS) and serial commands. The combination of both is called the 3D noise filter by DRS, enabling 3D noise filtering results in substantial lowering of NETD. The Viento 10 and HD10 USB is configured with both TNR and SNR on.
