KI 6358 Series
Visible Fault Locator
Operation Manual
Safety:
The KI6358 emits visible laser light in the wavelength range of 650-660 nm.
The maximum optical output power is 1.7 mW so that the device meets
Laser Class 1 (IEC 60825-2:2021) power specifications. During normal
operation, the laser light is not dangerous, but we still recommend that you
do not look directly into the laser output or into the end of a fiber connected
to the fault locator.
Application:
The KI6358 is suitable for performing continuity checks and locating faults
on single-mode and multimode optical fibers and components. A range of
up to 5 km can be achieved in certain cases. A single universal adapter
provides matching to all standard 2.5 mm optical fiber connector systems.
The battery lifetime in blink mode is approx. 40 hours for alkaline batteries.
Operation:
The instrument can be switched on or off by depressing the blue button
near the optical adapter for 2 seconds. With the same button the operator
can select between a continuous light mode and a flash mode with approx.
3 Hz. The KI6358 is equipped with a captive dust cap. Remove the cap
when using the device. Replace the cap after use to protect the optical
adapter. The optical connector must be inserted all the way into the
adapter.
Revision: 5 Date: 28 Jul 2023 Page 1 of 4
