19. ExternalDC 9V jack (EXT DC
ev)
20. Telephone record jack fl-EL
REC)
21. Remote controljack (REMOTE)
22. Earphone jack (EARPHONE)
23. Cradle bracket -both sides-
24. Hand controlcradle
2 2
Foot control
31. Back switch (BACR
32. Play switch (P[.AY)
33. Fast forward switch (FFWD)
Hand control
25. Microphone
26. lndex button (INDEX)
27. Fast forward button (FFWD)
28. Hand controlswitch
29. Speaker
30. Dictation indicator (DICT)
3 0
2 9
2 8
€-
FffiI
ts
Connectlons
For dlctatlon/conference recordlng
Attach the hand control cradle to the left
or right side of the unit by pressing itonto
the cradle bracket.
Hand control
AC edaptor
PREPARATIONS
For transcrlptlon
AC adaptor
For telephone recordlng
I
I
Connection cord
(not included)
Telephone with
REC OUT jack
Telephone without
BEC OUT jack
Tclcphone plckup
(SANYO SRD.So, not Inctuded)
