GigaSpire BLAST u6x/u6xw
Installation Guide
August, 2021
Part # 220-01214 Rev 10
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
August, 2021.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GigaSpire BLAST u6x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Calix GigaSpire BLAST u6x

Summary of Contents for Calix GigaSpire BLAST u6x

  • Page 1 GigaSpire BLAST u6x/u6xw Installation Guide August, 2021 Part # 220-01214 Rev 10 Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 2: Table Of Contents

    Tabletop Dimensions ....................17 Wall Mounting Dimensions ..................18 Tabletop Mounting the GS4227/GS4227W ............. 18 Wall Mounting the GS4227/GS4227W ..............19 Additional Mounting Considerations ..............21 Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 3 Chapter 4: Appendix .............. 35 Specifications ......................35 SFP/SFP+ Specifications ..................36 LED States - Device Turn-up .................. 37 LED States - WPS Functionality ................38 Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 4: About This Guide

    ALERT! Alert indicates the presence of a hazard that can cause damage to equipment or software, loss of data, or service interruption if not avoided. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 5  For external power supplies, the external power supply used in this device is to be Class II or a Limited Power Source (LPS) power supply. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 6: Chapter 1: Gigaspire Blast Overview (U6X, U6Xw)

    Chapter 1 GigaSpire BLAST Overview (u6x, u6xw) The Calix GS4227 and GS4227W are the newest generation of smart home system that integrates optical network termination (ONT) and residential gateway functionality into a single system. It supports virtually any passive optical network (PON) and Ethernet technology, while providing the ultimate Wi-Fi experience.
  • Page 7 Housing - u6x 4.9" L x 4.9" W x 9.9" H Housing - u6xw 5.1" L x 5.1" W x 10.1" H 6.4" Diagonal (corner to corner) Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 8 With the GigaSpire BLAST as the hub, and these 3rd party satellite extenders, consumers can truly gain the whole home/smart home experience. With the Calix integrated system, Calix has redefined how to install and activate residential services at a subscriber’s premises. Using mobile applications and a phone or laptop, a field technician can install and apply the subscriber’s service profile without special equipment or...

  • Page 9: Agency Listing

    Following is a list of standards that apply to this product: Standards FCC Part 15, Sub Part B, class B UL 62368-1/UL1697 EN 300 328 Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 10  10 VDC (min.), 15 VDC (max)  External Power Adapter: 12 VDC, 2 A DANGER! Using non-approved or incorrect power adapters can result in injury. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 11: Site Preparation

    8-pin connector on the UPS. Note: For all models, the power cord configuration must be appropriate for use in the country where the device is being deployed. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 12 8-Pin) GS4227 Raceway Cut-out (Route Incoming fiber to internal SFP+ Cage) 8505b Light Bar GS4227W Raceway Cut-out (Route Incoming fiber to internal SFP+ Cage Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 13: Chapter 2: Installation

    However, it is recommended that when possible, the GS4227 or GS4227W should be placed in a centralized location within the home to yield the best possible results for Wi-Fi coverage. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 14: Installation Variables

     (2) Product Identification Labels with Login Credentials After opening the carton, remove the protective packaging, ensure all components above are present, and prepare for mounting the unit. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 15: Tabletop Dimensions

    2-pin or 8-pin power adapter is 4.9" (1.5m) long. Note: u6xw Dimensions Side View (ref.) 6.4 inches 16.31 cm 10.1 inches 25.68 cm 9.2 inches 23.45 cm 8692 6.4 inches 16.31 cm Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 16: Wall Mounting Dimensions

    Note: 2-pin or 8-pin power adapter is 4.9" (1.5m) long. Tabletop Mounting the GS4227/GS4227W Any Calix GS4227 can be mounted flat on a tabletop, in a tower configuration. Four (4) rubberized feet are pre-installed on the bottom of the unit to provide a non-skid surface when placing the GS4227 on a table or shelf.

  • Page 17: Wall Mounting The Gs4227/Gs4227W

    Wall Mounting the GS4227/GS4227W The Calix GS4227/GS4227W can be wall mounted using the optional wall mount bracket. This model includes a 6mm captive receptacle built into the base for attaching to the captive M6 screw assembled into the wall mount bracket.
  • Page 18 Signal/Power Wiring for the GS4227W although the location (12 VDC) is roughly the same. AC Power to UPS 110/220 VAC, 3 Prong Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 19: Additional Mounting Considerations

     A customized interface panel (see above) for providing LAN, WAN, and POTS ports pre-wired near the unit. This allows for short cable runs and an overall cleaner deployment reducing clumsy and ill-terminated cable runs. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 20 LAN 4 POTS 1 POTS 2 Power In (2-Pin Barrel POTS-RJ11x2 or 8-Pin) Gigabit LAN Ethernet, RJ45 (x4) Fiber Pigtail - to SFP+ cage internal 8220-M Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 21: Chapter 3: Final Set-Up And Testing

    Removal Tab Grasp tabs with Thumbs and pull Removal Tab back away from u6x Grasp tabs with Thumbs and pull back away from u6x 8599 Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 22 9. Reinstall the access panel once you are assured that the SFP+ module is correctly installed and is providing a path to the network. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 23 Access Panel Removed Fiber Access Fiber Pigtail Stays Detent (Fiber Exit Point) SFP+Cage 8601 Example deployments using Ethernet or Fiber u6x with Fiber Interface Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 24: Installing Sfp+ Modules In A Gs4227W (U6Xw)

    In addition to the SFP+ cage itself, strategically located guides allow you to wrap the incoming fiber or Ethernet cable around any of several posts and raceways in the unit. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 25 5. Route the cable out to the corner of the unit (directly below the interface panel). Ensure the cable passes through the channel molded into the main chassis of the GS4227W. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 26: Gs4227/Gs4227W Reset Behavior

    Residential Gateway or as a subtended WAP or Satellite. Hardware-invoked resets behave differently depending on how long the reset button is pressed, as described below. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 27 Support user, TR-69 management settings reset to ACS URL and login credentials, SPID, etc., factory defaults all of which reset to defaults. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 28: Powering The Gs4227/Gs4227W - No Ups

     The AC power cord that runs from the UPS to the AC wall outlet is 8-feet long. Make sure an AC outlet is available within that distance. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 29 .6875 inches 16.8 cm 6.625 inches 6084 1. Pre-drill mounting holes (to accept an 8-32 pan head screw - not provided) of the appropriate size. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 30: Connecting To The Internet

    If the device is configured as a Residential Gateway, connect an Ethernet Cable to its WAN port from the WAN modem (ONU, cable modem, or DSL modem). Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 31  Number of radios: 2 (2.4 GHz and 5 GHz)  Wi-Fi Protocol supported: 802.11a/b/n/g/ac/ax  Credentials: Login and password printed on the product label in the gift box. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 32: Chapter 4: Appendix

    LAN Data/IPTV: Four (4) 10/100/1000 BASE-T Ethernet   Wi-Fi multimedia (WMM) USB-IF Compliance, USB 2.0 ports, RJ-45 connection REMOTE  WAN: SFP+ cage MANAGEMENT Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 33: Sfp/Sfp+ Specifications

    100-02168 - 10GE BIDI SFP+, Single Mode single fiber Downstream transceiver, 20Km, 1270nm, LC, I-Temp 100-05723 - 10GE BIDI SFP+, Single Mode single fiber Downstream transceiver, 60Km, 1270nm, LC, I-Temp Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 34: Led States - Device Turn-Up

    LEDs. Boot-up Failure Off and Red (800 msec)  Unit boot-up failed (if SW Note: All four LEDs are on. can control the LEDs) Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.

  • Page 35: Led States - Wps Functionality

    SSID (2.4 seconds. and 5.0 GHz). WPS LED behavior takes priority even if Alexa is used during the pairing period. Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 36 (single top LED is lit). Refer to LED Stats - GS4227 Turn-up (on page 26) for additional information Proprietary Information: Not for use or disclosure except by written agreement with Calix. August, 2021.
  • Page 37 Calix Safety and Regulatory Statements - GigaSpire NOTE: This Safety and Regulatory Statements Guide applies to all GigaSpire devices that may or may not include a Wi-Fi radio. Disregard any statements made here if the feature or function is not present on any particular model.
  • Page 38 ALIMENTATION ÉLECTRIQUE • Connectez le cordon d’alimentation uniquement à uneprise d’alimentation CA conforme aux spéci cations GigaSpire. • Ne modi ez jamais le cordon d’alimentation CA. Si nécessaire, faites installer la bonne prise par un électricien quali é ou appelez votre fournisseur de servicepour obtenir de l’aide.
  • Page 39 CALIX, INC. AND THE ENVIRONMENT At Calix Inc., we understand and a re committed to reducing any impact our operations and products may have on the environment. To minimize this impact, Calix Inc. designs and builds its products to be as environmentally friendly as possible, by using recyclable, low toxic materials in both products and packaging.
  • Page 40 RADIATION EXPOSURE STATEMENT The minimum distance between the user and/or any bystander and the radiating structure of the transmitter is 20 cm. NOTICE OF WIRELESS RADIO LAN USAGE IN THE EUROPEAN COMMUNITY This device is restricted to indoor use when operated in the European Community using channels in the 5.15-5.35 GHz band to reduce the potential for interference.
  • Page 41 (https://www.calix. com/declarations). Par la présente, Calix Inc. Cet accès qui déclare haut débit sans  l terminal est conforme à la directive 2014/53 / UE. Le texte intégral de français [French] la déclaration de conformité C’est disponible en ligne à partir des déclarations de site Calix (https://www.calix.com/declarations).
