Trencher Mount Kit for Tracked Machine
RT1200 Trencher
Model No. 25469
Model No. 25469E
This product contains a chemical or chemicals known to the State of California to
Safety
Improperly using or maintaining this attachment can result in injury. To reduce the potential for injury, comply
with these safety instructions and those in the traction unit Operator's Manual . Always pay attention to the safety
alert symbol, which means Caution, Warning, or Danger—personal safety instruction. Failure to comply with
the instruction may result in personal injury or death.
WARNING
When the engine is off, attachments in the raised position can gradually lower. Someone below the
attachment may be pinned or injured by the attachment as it lowers.
Always lower the attachment each time you shut off the traction unit.
WARNING
Hydraulic fluid escaping under pressure can penetrate skin and cause injury.
• Make sure all hydraulic fluid hoses and lines are in good condition and all hydraulic connections and
fittings are tight before applying pressure to the hydraulic system.
• Keep your body and hands away from pin hole leaks or nozzles that eject high pressure hydraulic fluid.
• Use cardboard or paper to find hydraulic leaks.
• Safely relieve all pressure in the hydraulic system before performing any work on the hydraulic system.
• Seek immediate medical attention if fluid is injected into skin.
CAUTION
Hydraulic fittings, hydraulic lines/valves, and hydraulic fluid may be hot and can burn you if you touch
them.
• Wear gloves when maintaining hydraulic components.
• Allow the traction unit and trencher to cool before touching hydraulic components.
• Do not touch hydraulic fluid spills.
© 2015—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
WARNING
CALIFORNIA
Proposition 65 Warning
cause cancer, birth defects, or reproductive harm.
Register at www.Toro.com.
Form No. 3394-817 Rev A
Installation Instructions
Original Instructions (EN)
All Rights Reserved *3394-817* A
Printed in the USA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Toro RT1200
Summary of Contents for Toro RT1200
- Page 1 • Wear gloves when maintaining hydraulic components. • Allow the traction unit and trencher to cool before touching hydraulic components. • Do not touch hydraulic fluid spills. © 2015—The Toro® Company Register at www.Toro.com. Original Instructions (EN) All Rights Reserved *3394-817* A...
-
Page 2: Installation
1. Move the machine to a level surface that is below the Install the speed-shift switch as instructed in operator’s manual lifting equipment. for the Center Trencher, RT1200 Traction Unit. 2. If the backhoe is installed on the machine, lower the boom until the bucket is on the ground. - Page 3 Installing the Spacer to the Trencher Attachment Parts needed for this procedure: Spacer Bolts (1 x 2-1/2 inch) Locknut (1 inch) Washer (1 inch) Bolt (1 x 13 inch) Assembling the Spacer to the Trencher Attachment Trencher attachment weight: 227 kg (500 lb) Figure 2 Spacer weight: 137 kg (302 lb) 1.
- Page 4 Figure 4 1. Spacer 4. Washer (1 inch) 2. Trencher back plate 5. Locknut (1 inch) 3. Bolt (1 x 2-1/2 inch) 7. Torque the bolts and the locknuts to 1341 to 1368 N-m (989 to 1009 ft-lb). Figure 3 Assembling the Spacer and Trencher 1.
- Page 5 3. Align the row 2 holes in spacer with the 2 bolts (1 x 13 inch) that you installed in step1 (Figure Figure 8 Figure 6 1. Lower locknut and retainer 3. Row 3 holes (trencher back plate) 1. Mounting plate (machine) 3.
- Page 6 Installing the Speed-shift Switch No Parts Required Procedure Install the speed-shift switch as instructed in operator’s manual for the Center Trencher, RT1200 Traction Unit. Figure 10 1. Lift cylinder 5. 45° elbow fitting (3/8 inch) 2. Cap (3/8 inch) 6. Extend hose 3.
- Page 7 1. Remove the 2 caps (1 inch) and the 1 cap (5/8 inch) from the bulkhead fittings in the hydraulic-attachment panel (Figure 11). Figure 12 1. Bulkhead fitting 5. Case-drain hose (1.3 x (pressure-hydraulic 116 cm or 1/2 x 45-3/4 circuit—A) inch) Figure 11...
- Page 8 Finishing the Trencher Installation No Parts Required Procedure Perform the following procedures as instructed in operator’s manual for the Center Trencher, RT1200 Traction Unit: • Connecting the Wiring Harness to the Hydraulic Motor Figure 14 • Purging Air from the Hydraulic Motor and Lift Cylinder 1.
