Everest ESPT-2G-2S Owner's Manual

Upright reach-ins top mounted condensing unit
Hide thumbs Also See for ESPT-2G-2S:
Table of Contents

Advertisement

Quick Links

Download this manual
Upright Reach-Ins
Top Mounted Condensing Unit
Owner's Manual
ESPT-1G-1S, ESPT-2G-2S, ESPT-1S-1S, ESPT-2S-2S,
ESR1, ESRH2, ESR2, ESRH4, ESWR2, ESR3, ESF1,
ESFH2, ESF2, ESWF2, ESF3, ESRFH2, ESRF2A,
ESWRF2, ESWQ3, ESRF3, ESR1D2, ESR2D2,
ESR2D4, ESRF2D2, ESWQ2D2, ESGR1, ESGRH2,
ESGR2, ESGRH4, ESGWR2, ESGR3A, EGSH2,
EGSDH2, EGSH4, EGSWH4, EGSH6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESPT-2G-2S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Everest ESPT-2G-2S

Summary of Contents for Everest ESPT-2G-2S

  • Page 1 Upright Reach-Ins Top Mounted Condensing Unit Owner’s Manual ESPT-1G-1S, ESPT-2G-2S, ESPT-1S-1S, ESPT-2S-2S, ESR1, ESRH2, ESR2, ESRH4, ESWR2, ESR3, ESF1, ESFH2, ESF2, ESWF2, ESF3, ESRFH2, ESRF2A, ESWRF2, ESWQ3, ESRF3, ESR1D2, ESR2D2, ESR2D4, ESRF2D2, ESWQ2D2, ESGR1, ESGRH2, ESGR2, ESGRH4, ESGWR2, ESGR3A, EGSH2,...
  • Page 2 this page intentionally left blank...

  • Page 3: Table Of Contents

    Upright Reach-Ins Top Mounted Condensing Unit ESPT-1G-1S, ESPT-2G-2S, ESPT-1S-1S, ESPT-2S-2S, ESR1, ESRH2, ESR2, ESRH4, ESWR2, ESR3, ESF1, ESFH2, ESF2, ESWF2, ESF3, ESRFH2, ESRF2A, ESWRF2, ESWQ3, ESRF3, ESR1D2, ESR2D2, ESR2D4, ESRF2D2, ESWQ2D2, ESGR1, ESGRH2, ESGR2, ESGRH4, ESGWR2, ESGR3A, EGSH2, EGSDH2, EGSH4, EGSWH4, EGSH6 Contents Hydrocarbon Guidelines ....

  • Page 4: Hydrocarbon Guidelines

    Hydrocarbon Guidelines This section applies to R290 Hydrocarbon units only. To identify the refrigerant type, see the data plate in the cabinet interior. WARNING - THIS UNIT USES R290, A HYDROCARBON, PROPANE REFRIGERANT THAT IS ENVIRONMENTALLY FRIENDLY BUT IS ALSO HIGHLY FLAMMABLE AND EXPLOSIVE. PLEASE READ THIS MANUAL CAREFULLY AND FOLLOW ALL SAFETY PRECAUTIONS CONTAINED HEREIN TO AVOID THE RISK OF FIRE OR EXPLOSION.
  • Page 5 General service and repairs must be performed only by professionals authorized by Everest Refrigeration. • Component shall be replaced with Everest-issued, like components to minimize the risk of possible ignition resulting from incompatible parts or improper repairs. • Do not modify, re-appropriate, or remove any functional part(s) from the unit.

  • Page 6: Installation Instructions

    Installation Instructions This section applies to all Everest products. Correct installation ensures proper performance and longevity of your appliance. Professional installation by a trained refrigeration technician and electrician is recommended. Warranty is void if the following guidelines are not met.
  • Page 7 Shelf Installation 1. Attach the shelf clips onto the pilasters by inserting its top hook into a pilaster notch followed by the bottom hook. Do not use pliers or other crimping tools to modify the shape of the shelf clips. This will result in shelf mounting instability.
  • Page 8 Product Load Level & Shelf Placement Product Load Level for ES Series Solid Door Load Level 12" Load Level 12" Airflow Guard Load Level 12" Shelf Front Rear Load Level 12" Air Vent Air Flow Front Rear Side View Installation Instructions...

  • Page 9: Pan Configuration

    Pan Configuration Some Upright Reach-In models come with drawers. Drawer pans are not included and must be purchased separately from third party sources. Most standard sized pans will fit as long as it follows the pan configuration. Not all models will accommodate standard full sized pans. ESR1D2 [Standard: (1) pan divider per drawer included] / 6"...

  • Page 10: General Safety

    General Safety This section applies to all Everest products. Use your appliance according to its designed function as specified in this Owner’s Manual. Warranty is void if the following guidelines are not met. • Before the unit is used, it must be installed and connected according to the installation instructions provided in this manual.

  • Page 11: Electrical Safety

    Electrical Safety This section applies to all Everest products. Basic safety precautions must be observed when using electrical appliances in addition to the following. Warranty is void if these guidelines are not met. Everest units come as 115 volts, 60 hertz, Do not use extension cords, adapter plugs or single phase.

  • Page 12: Operation

    Operation This section applies to all Everest products. Use according to the described and intended functions. Warranty is void if these guidelines are not met. Starting your Everest Product After plugging in the unit, the current temperature and compressor symbol will appear on the digital temperature control’s LED display.
  • Page 13 Carel ‘Easy’ Digital Temperature Control Everest units are equipped with a Carel Digital Temperature Control. The type of controller is dependent on the model and production date. Evaporator Fan Running Compressor Running Alarm in Progress Power / Up Button Temperature...
  • Page 14 Setting the Temperature ( continued ) 2. Toggle through the desired temperature by pressing UP or DOWN The number increases or decreases by a decimal point. 3. The recommended setting is 35.0°F (2.0°C) for refrigerators and -4.0°F (-20.0°C) for freezers. The available temperature setting range is 33.0°F to 54.0°F (1.0°C to 12.0°C) for Refrigerators and -10.0°F to 54.0°F (-23.0°C to 12.0°C) for Freezers.
  • Page 15 Carel ‘ir33’ Digital Temperature Control Everest units are equipped with a Carel Digital Temperature Control. The type of controller is dependent on the model and production date. Evaporator Fan Running Program Button Compressor Running Up Button / Alarm in Progress...
  • Page 16 Initiating Manual Defrost The controller has an automatic defrost cycle in place so initiating manual defrost is not necessary unless there is an abnormal accumulation of ice around the evaporator coil. 1. Press and hold down the Manual Defrost Button until the Defrost Symbol appears on the LED display.

  • Page 17: Care And Maintenance

    Care and Maintenance This section applies to all Everest products. Regular care and maintenance of your appliance will significantly extend service life and dependability. In severe cases, lack of upkeep will contribute to the rapid decline in performance and component health. Care and maintenance is the product owner’s personal responsibility.
  • Page 18 Condenser Coil Cleaning Instructions This section applies to all Everest products. The condenser coil requires monthly cleaning to keep the metal fins clear of lint, dust, and grease buildup. A clogged condenser coil severely reduces your product’s energy efficiency and places strain on the compressor and other components, leading to advanced failure.
  • Page 19 Condenser Coil Cleaning Instructions ( continued ) 5. The grease and cleaning solvent will pool at the base of the metal fins. Brush the fins and wipe off any accumulated residue. 6. Repeat the above steps until the metal fins are clean. You should be able to see in through and in between the metal fins.

  • Page 20: Door Reversal Instructions

    Door Reversal Instructions Some products have field-reversible doors to accommodate specific kitchen layouts. Door reversals must be performed by qualified technicians. A second person is required. Safety Goggles must be worn to protect against spinning parts. A warranty is void if the following guidelines are not met.
  • Page 21 Door Reversal Instructions (Continued) 5. Extra precaution must be taken for the following steps. Release the door tension from the door spring by inserting a sharp pointed implement into one of the door hinge shaft’s unoccupied tension lock screws C- 2 6.

  • Page 22: Troubleshooting Guide

    Troubleshooting Guide In most cases, your Everest product may be exhibiting behavior that is typical of standard operation. Observe the following when troubleshooting symptoms. ‘cht’ or ‘CHt’ appears on the LED alternating The compressor operates continuously or for with the current temperature and accompanied prolonged periods.
  • Page 23 The cabinet temperature is too warm. Condensation in the interior cabinet. The condenser coil may be clogged with dust, The door or door gasket may not be sealing grime or debris. Clean it following the instructions properly. Check product placement in the cabinet on pages (15,16).

  • Page 24: Warranty Information

    The product data plate is a permanently affixed label that contains the model, serial, barcode numbers, and refrigeration data of your Everest product. The tag is located on the rear or side of the unit exterior. Please retain this information for warranty-related purposes.
  • Page 25 Warranty Certificate YEAR YEAR YEAR PARTS & LABOR ELECTRICAL COMPRESSOR...
  • Page 26 A Step Above The Standard 201 W. Artesia Blvd., Compton, CA 90220 Tel: 800-444-6285 / 310-323-6586 Fax: 310-323-7524 / 310-761-1127 www.EVERESTref.com v111623...
