Larson Electronics EPS-1XPBMS-1XPB10 Instruction Manual

Explosion Proof 10A Double Push Button Switch
Momentary and eStop - C I and II, Div. 1&2 - 120VAC
Thank you for your purchase of the Larson Electronics EPS-1XPBMS-1XPB10.
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
• INSTALLATION SHOULD ONLY BE CONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
RELEVANT LOCAL BUILDING CODES.
• RISK OF FIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF FIXTURE'S ELECTRICAL
SYSTEMS. IF NOT QUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•
MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE FIXTURE'S RATED VOLTAGE.
•
TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
•
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
WARNING
TO AVOID THE RISK OF FIRE, EXPLOSION OR ELECTRIC SHOCK, THIS PRODUCT SHOULD BE INSTALLED,
INSPECTED AND MAINTAINED BY A QUALIFIED ELECTRICIAN ONLY, IN ACCORDANCE WITH ALL
APPLICABLE ELECTRICAL CODES.
TO AVOID ELECTRIC SHOCK:
•
BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•
PRODUCT MUST BE CONNECTED TO A WIRING SYSTEM WITH AN EQUIPMENT-GROUNDING
CONDUCTOR.
TO AVOID EXPLOSION:
•
MAKE SURE THE SUPPLY VOLTAGE IS WITHIN THE VOLTAGE RATING.
•
ENSURE THE MARKED T RATING IS LESS THAN THE IGNITION TEMPERATURE OF THE HAZARDOUS
ATMOSPHERE.
•
DO NOT OPERATE IN AMBIENT TEMPERATURES ABOVE THOSE INDICATED ON THE PRODUCT
NAMEPLATE.
•
DO NOT OPERATE IF THE LENS, CORD, SEALS, HOUSING, RECEPTACLES, ETC. IS CRACKED OR DAMAGED.
IF SO, DISCONTINUE USE AND CONTACT MANUFACTURER FOR REPLACEMENT PARTS.
•
ALL FASTENERS SHOULD BE PROPERLY SEATED.
The Larson Electronics EPS-1XPBMS-1XPB10 Explosion Proof Double Push Button Switch is Class I, Division 1 & 2 and Class II,
Division 1 & 2 rated for hazardous locations. This explosion proof switch includes one momentary switch and one estop, which provides
manual starting and stopping of small AC and DC motors to support basic features of machines lacking electrical circuits for control.
The unit offers versatile wiring configurations, making it suitable for up/down controls for pendant control stations and other similar
applications.
MOUNTING
This unit has external mounting lugs on the body.
WIRING
Standard pigtail(flying leads) wiring
We strongly encourage a licensed electrician install this product
where weatherproofing may be required. Universal voltage driver permits operation at 600V max.
Warning: Check product label for correct input voltage!
Attach supply line wires to the appropriate light fixture wires as shown in the
diagram 
Secure each pair of wires according to the diagram. Utilize a junction box or similar
device and take precautionary
installed in a location where water may come in contact with the unit. Ensure the unit is
properly grounded and that wiring is done according to all local and national electrical/
building codes.
Larson Electronics, LLC
Instruction Manual
steps for weatherproofing
(877) 348-9680
Phone:
, in all locations especially in outdoor areas
all connections if
Fax: (903) 498-3364
EPS-1XPBMS-1XPB10
www.larsonelectronics.com
1 of 2
