UT25CL User Manual
or
. The default level is " ".
5
Backlight/Mute button: Short press to turn on/off the backlight; long press to turn on/off the
mute mode.
6
LEVEL button (Enabled when transmission is stopped): Short press to enter/exit the LEVEL
setting.
7
CODE button (Enabled when transmission is stopped): Short press to enter/exit the CODE
setting.
8
Power button: Long press this button for >1s to turn on the transmitter; or long press >1s in
power-on state to turn off the transmitter.
9
The buzzer is designed in here.
4.3 Descriptions of Display
0
The symbol "
supply.
1
The symbol "
supply.
2
The symbol " " appears when the input/output port is connected with an AC/DC
power supply greater than 480V.
3
When the input/output port is connected with DC power supply, and the red input
port is connected with DC negative pole and the black port is connected with
positive pole, the symbol "一" appears.
4
When the input/output port is connected with DC power supply, and the red input
port is connected with DC positive pole and the black port is connected with
negative pole, the symbol "
5
The actual measured voltage (when the input voltage is ≥8V).
6
A voltage symbol
7
Battery power level (including 4 levels)
8
When signal is emitted, this dynamic symbol will be refreshed cyclically.
9
Auto-off (APO symbol)
10
This is the current code value. When setting the code, the current set code (code
value: 0~7) will be displayed. The default code is 5.
" appears when the input/output port is connected with AC power
" appears when the input/output port is connected with DC power
" appears.
10
