Cleerline SSF-02E-Cleaver Manual

Adjusting SSF-02E-Cleaver
Before attempting to adjust cleaver please be sure soft
peel has been removed using fingernails and fiber is long
enough to lay across both black pads.
STEP 1
Remove top crosshead screw that holds trash bin.
STEP 2
Remove bottom crosshead screw that holds trash bin.
STEP 3 Use allen wrench located underneath the cleaver to loosen
both screws located on the side of the cleaver. Turn both
1 full turn to the left.
STEP 4
Locate 2 screws on top of the blade carriage sliding block
and use allen wrench to remove both screws completely.
CLEERLINE TECHNOLOGY GROUP, LLC
8404 El Way Drive #2B, Missoula, MT 59808
Web: www.cleerlinefiber.com
USA & CAN: 866-469-2487
Copyright 2012 Cleerline Technology Group, LLC.
Figure 1
Figure 2
Figure 3
Figure 4
