Worldline N86 Quick Manual

Smart pos terminal

Advertisement

Digital Payments
for a Trusted World
POWER ON/OFF
Power on:
Press the 
 button for 2–3 seconds to power on
the terminal.
BATTERY
The battery is included as a standard in the scope
of delivery of the terminal.
1. Remove the battery cover.
2. Install/disassemble battery (ensure that contacts
on the battery match the prongs on the inside
of the device).
3. Insert/remove white socket from battery plug.
SIM CARD
The SIM card is included as a standard in the scope
of delivery of the terminal.
1. Open the battery cover.
2. Insert the SIM card (with contacts face down)
by  carefully sliding it into the slot until the card
is fully inserted.
ATTENTION
To install or remove the SIM card, make sure
the device is turned off to prevent damaging
the card. Do not cover the SIM card
with  stickers or adhesives, this may affect
the  thickness of card and hinder the
smooth insertion or removal.
Smart POS Terminal
N86
Quick guide
Power off or restart the terminal:
Press the 
menu is displayed. Select <Switch off> and your
terminal switches off. Select <Restart> and the terminal
restarts.
 button until the <Switch off; Restart>
SIM card

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N86 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Worldline N86

  • Page 1 Digital Payments for a Trusted World Smart POS Terminal Quick guide POWER ON/OFF Power on: Power off or restart the terminal: Press the   button for 2–3 seconds to power on Press the   button until the <Switch off; Restart> the terminal. menu is displayed.
  • Page 2: Home Screen

    HOME SCREEN Enter the most frequently used apps and functions easy via shortcuts at the device’s home screen. • Settings App (Set up Wifi, Sounds, e.g.) • Payment Application (contains all functions required for daily payment transactions) • Update (manual firmware or terminal software update) SETUP WIFI Enter the devices Settings App in the apps drawer or via shortcut at the device’s home screen.
  • Page 3 PAYMENT APP Your payment app contains all functions for daily payment transactions. While running payment application, four categories are displayed at the bottom of the terminal screen. Payment Enter all payment functions like <Purchase>, <Reversal> or <Credit> in the transaction menu. Configuration Enter the Configuration Menu to view and print various reports on transactions.
  • Page 4: Changing Paper Roll

    PURCHASE Enter the amount that has Insert the card and to be transferred. Transaction enter the PIN via the starts with <OK>. touchscreen. Confirm PIN entry with <OK>. CANCELLATION Enter the Terminal password. To cancel the last transaction, confirm with <OK>. CHANGING PAPER ROLL 1.
  • Page 5: Troubleshooting

    TROUBLESHOOTING Category Error Reason Troubleshooting Power on/ Unable to 1. Run out of battery. 1. Connect terminal with a power Power off issue power on terminal. 2. Battery installation supply. incorrectly. 2. Verify if the battery is inserted 3. AC power connection correctly.
  • Page 6: Security Information

    5. Please contact your terminal manufacturer in case of any problems. Unqualified persons are not permitted to repair the terminal. Your local point of contact can be found at: worldline.com/merchant-services/contacts...
