ThermoWorks EXEC Operating Instructions

EXEC™ Operating Instructions
• Accuracy to ±0.9°F (±0.5°C)
• 3-4 second readings
• –40 to 572°F range
Instrument Operation
Press the power button to activate the thermometer. The unit will turn off automatically
after 35 minutes to save battery life. Press and hold the power button for 3 seconds to turn
off EXEC. To activate the backlight, press the power button once while the instrument is
turned on. Press again to turn off.
Insert the stainless steel probe to the desired depth. The measured temperature will be
shown on the LCD display within 3 to 4 seconds.
Using MIN/MAX
Press the MAX/MIN button to read the last highest / maximum
temp measured.
Press once more to read the last lowest / minimum temperature measured.
Press once more to return to normal display.
Press and hold the MAX/MIN button for three seconds then release to reset the memory.
MAX and MIN are reset when the unit is powered off.
For additional cooking tips and doneness temperatures, and to see the full line of ThermoWorks
tools, visit our website at www.thermoworks.com.
Specifications
Probe Range
Accuracy
Display Resolution
Response Time
Display Size
Backlight
Digit Size
Minimum Immersion
Water Resistance
Battery Life
Product Size
Operating Range
• Calibration trim
• IP67 rating
• 180° rotating display
Battery Installation
Replace the battery when low battery symbol 'Bat' flashes. Replace with a
3 volt, type CR1632, button-cell battery or equivalent.
Use a screwdriver of suitable size to open the battery cover
on the back.
Install the battery observing the correct polarity, (+) positive side up,
sliding the battery under the metal clip.
Close the battery cover.
To Select ˚F or ˚C
Press the °C/°F button on the back of the thermometer to select the desired
temperature unit.
Calibration Trim
New from the factory EXEC should read within ±0.9°F. Normally a
calibration adjustment should never be needed. For instructions on
performing a one-point calibration trim go to the EXEC webpage at www.
thermoworks.com.
Care and Cleaning
Clean the probe immediately after each measurement to avoid cross
contamination. Do not expose the thermometer body to temperatures over
122°F (50°C). Do not leave inside ovens. Avoid submersing the entire
thermometer.
Technical Support
For warranty, service, and technical assistance, please contact
ThermoWorks' Technical Support at (801) 756-7705 or email at
techsupport@thermoworks.com.
–40 to 572°F (–40 to 300°C)
±0.9°F (±0.5°C) between 14 to 212°F (–10 to 100°C),
±4.5°F (±2.5°C) between 392 to 572°F (200 to 300°C)
otherwise ±2.7°F (±1.5°C)
0.1°
Units °C/°F
Approx. 3-4 seconds from ambient to 32°F ±0.9°F
Auto Off After 35 minutes
0.45 H x 0.94 W inches (11 H x 24 W mm), automatically rotates 180°
10 seconds
0.29 H x 0.16 W inches (7.5 H x 4.0 W mm)
Probe 4.8 L x 0.1 dia. inches; reduces to 0.67 L x 0.06 (1/16") dia. inches
(125 L x 2.5 dia. mm; reduces to 17 L x 1.5 dia. mm), Thermistor
Approx. 0.25 inch (6.4 mm)
IP67
Battery 3 volt, type CR1632 or equivalent x 1 piece (included)
3,000 hours continuous use
8.3 H x 0.9 W x 0.6 D inches (211.5 H x 23 W x 16 D mm)
32 to 122°F (0 to 50°C)
• Backlight
• Max/Min function
• NIST-traceable certificate
