  • Page 1 64x64 channel ADAT Extension for FLX devices User's Manual...

  • Page 2: Table Of Contents

    User's Manual Table of Contents CONNECTORS....................3 1.1. Card......................3 1.2. Breakout box.................... 3 DESCRIPTION....................3 2.1. Box Contents.................... 4 INSTALLATION....................4 3.1. Opening the flexiverter................4 3.2. Flexiverter Inside View................4 3.3. Installing the card..................5 3.4. Installing the breakout box................5 3.5.

  • Page 3: Connectors

    AUX-ADAT-64 CONNECTORS 1.1. Card ➊ Flat ribbon cable to breakout box 1.2. Breakout box ➊ Flat ribbon cable to AUX card ➋ ADAT / SPDIF Inputs and outputs DESCRIPTION The AUX-ADAT-64 provides 64x64 channels of ADAT (on 8xIN, 8xOUT optical connectors).

  • Page 4: Box Contents

    User's Manual For a detailed description of possible configurations, please refer to the manual of your base FLX device. 2.1. Box Contents 1 AUX-ADAT-64 extension card for FLX devices (with slot cover plate)  1 AUX-ADAT-64 breakout box  1 Flat ribbon cable (connection between extension card and breakout box) ...

  • Page 5: Installing The Card

    AUX-ADAT-64 3.3. Installing the card ➊ Remove the screws holding the cover plate, and the blank cover plate  Insert the AUX card from inside, using the supplied cover plate.  ➋ Make sure it is correctly fitted to the card connector ➊...

  • Page 6: Self-Test

    User's Manual SELF-TEST The card can be tested for correct operation by the user. This is done using the self-test mode, in which a special random test pattern is output on all channels. This pattern is looped back via an external cable into the corresponding inputs, where it is checked for consistency.

  • Page 7: Appendix

    AUX-ADAT-64 APPENDIX 7.1. Available AUX cards At the time of writing (2024-07), the following AUX cards are available. More will come, please check www.appsys.ch for updates. Item Description AUX-ADAT 16x16ch ADAT I/O (2x Toslink In+2x out). Supports also S/PDIF AUX-ADAT-64 64x64ch ADAT I/O (8x Toslink In+8x out on external breakout box) AUX-AES3 8x8ch AES3 I/O on 1x DB25, fully transformer isolated...

  • Page 8: Warranty

    About this document All trademarks mentioned in this document are property of the respective owners. All information provided here is subject to change without prior notice. Document Revision: 1 · 2024-07-28 Copyright © 2024 Appsys ProAudio · Printed in Germany IDENT 9.00.xxxxx.00...
