- Page 1 SURFACE AND VOLUME RESISTANCE PROBE M 803B Operating Manual www.electrotechsystems.com (215) 887-2196 D01893 Rev B...
-
Page 2: Table Of Contents
Table of Contents I. Important Safety Information ..................2 Informations Importantes d’inocuite ................4 II. Description of Contents ..................... 6 III. Optional Accessories ....................7 IV. Set-Up Guide ......................8 V. Functionality ......................10 V. Specifications ......................11 VII. Repair and Maintenance ..................12 VIII. -
Page 3: Important Safety Information
I. Important Safety Information This symbol accompanied by the This symbol accompanied by the This symbol indicates the presence word “WARNING” calls attention to word “CAUTION” indicates a of hazardous AC or DC voltages an act or a condition which can potentially hazardous situation constituting the risk of electric lead to serious personal injury or... - Page 4 POWER POWER CORD: Use only the power cord specified for this equipment and certified for the country of use. If the power (mains) plug is replaced, follow the wiring connections specified for the country of use. When installing or removing the power plug, hold the plug, not the cord. The AC supply must be single phase, with RMS Voltage in range 90 –...
-
Page 5: Informations Importantes D'inocuite
Informations Importantes d’inocuite Ce symbole accompagné du mot Ce symbole accompagné du mot Ce symbole indique la présence (WARNING) attire l’attention sur un d’une climatisation dangeureuse (CAUTION) indique une situation ou d’un courant continu constituant acte ou une condition qui peut potentiellement dangereuse qui, si elle n’est pas évitée, pourra entraîner des blessures graves ou... - Page 6 ALIMENTATION CORDON D'ALIMENTATION: Utilisez uniquement le cordon d'alimentation spécifié pour cet équipement et certifié pour le pays d'utilisation. Si la fiche d'alimentation (secteur) est remplacée, suivez les connexions de câblage spécifiées pour le pays d'utilisation. Lors de l'installation ou du retrait de la fiche d'alimentation, tenez la fiche, pas le fil.
-
Page 7: Description Of Contents
Item Item Qty. Description The Model 803B Resistance/Resistivity Probe design has ETS 803B been adopted as the industry standard for measuring the resistance characteristics or planar material. Cable assembly that is used for the connection between the 3-wire cable assembly 803 B and a measuring device. -
Page 8: Optional Accessories
M 809B Resistance Verification Fixture (per ANSI/ESD STM 11.11) Utilize the M 809B to confirm the M 803B Probe is measuring correctly by verifying the alignment of the concentric rings and the low measurement range using an array of 20 resistors (10 MΩ/1%). The reverse side has a resistor of 1 TΩ/5% that checks both the high range measurement accuracy and... -
Page 9: Set-Up Guide
IV. Set-Up Guide Set-Up Guide 803B probe/Resistance Meter Hookup for Surface Resistivity Measurement (ASTM D257-14) Surface Resistance and Resistivity Model 803B Probe hookup to a resistance meter for measuring surface resistance/resistivity. The Teflon sense cable is connected to the Inner electrode (Black banana Jack) and the voltage cable is connected to the Outer Electrode (Red banana Jack). - Page 10 803B probe/Resistance Meter Hookup for Volume Resistivity Measurement (ASTM D257-14) Volume Resistivity Model 803B Probe hookup to a resistance meter for measuring volume resistance/resistivity. The Teflon sense cable is connected to the inner electrode (Black Banana Jack) and the voltage cable is connected to the plate (the same plate as 803B probe/Resistance Meter Hookup for Volume is used for the ground plane for surface...
-
Page 11: Functionality
V. Functionality The Model 803B Probe will accurately measure the surface resistance/resistivity of any smooth surface that is greater than 2.5" in diameter. The standard 2.2 kg (5-pound) probe weight is sufficient for the electrodes to make total contact with the material surface of most film and foam materials. The Model 803B Resistance/Resistivity Probe design has been adopted as the industry standard for measuring the resistance characteristics or planar material. -
Page 12: Specifications
V. Specifications ELECTRICAL Ω to 10 Ω Measurement Range: 10 Contact electrodes: Nickel coated graphite silicone Ω Volume resistance: As low as 10 Insulation: Teflon® MECHANICAL Electrode Dimensions: Outer ring: 8 mm dia. x 3 mm width x 3 mm thick (2.5” dia. x 0.125” width x 0.125” thick) Inner disk: 30.5 mm dia. -
Page 13: Repair And Maintenance
Replacement cables are available from ETS. See Troubleshooting Guide. To return equipment to ETS for repair or service it is first necessary to obtain an RMA number. Please call 215-887-2196 or email service@ets2.com. You can also utilize the contact form found on our website at www.electrotechsystems.com. -
Page 14: Troubleshooting Guide
Problem Possible Causes Corrective Actions Improper connections of See Setup Guide test cable Broken wire(s) on test cable Get replacement test cable from ETS Reading too high or over-scale Excessive contaminants on Clean conductive electrode(s) with Isopropyl conductive electrodes alcohol... -
Page 15: Warranty
X. Warranty Limited Warranties. Seller warrants that all goods manufactured and delivered hereunder shall (a) conform to any samples, drawings, specifications, or other written documents provided to Seller by Buyer or approved by Buyer to Seller and (b) be free from all defects in workmanship and material.
