ANTENNA EXPERTS
E-mail
Model # AP-145019
NOTICE:
Installation, maintenance or dismounting of the grid parabolic antenna system requires qualified
and experienced personnel. Antenna Experts Installation instructions have been prepared and
are meant for skilled personnel only.
Antenna Experts disclaims any liability or responsibility as a result of improper or unsafe
installation practices.
MATERIALS AND FINISH:
Following materials are used for the fabrication of Grid Parabolic Antennas and its accessories.
Grid Parabolic Reflector:
Mounting Hardware:
Fasteners:
Dipole Feed:
Insulator:
1 INTRODUCTION:
AP series grid parabolic antenna reflector consists of numbers of grid members to handle the
maximum wind pressure and supplied in assembled condition for quick installation. When
assembled, the antenna can be mounted on a vertical pipe having a outer diameter of 50-75
mm (2-3 Inches).
1.1 GRID PARABOLIC REFLECTOR:
Grid parabolic reflector is supplied complete in assembled condition for quick installation.
1.2 UPPER SUPPORT ARM:
Upper support arm is supplied to hold the antenna from top. Upper support arm includes "U"
bolt hardware and locking nuts/bolts.
1.3 LOWER SUPPORT ARM:
Lower support arm is supplied with the antenna to hold the antenna from lower side. Lower
support arm consists of elevation adjustment mechanism (2 sets of 6 inches long bolts and
double nuts) along with "U" bolt hardware and locking nuts/bolts.
1.4 STOPPER:
A stopper is supplied with the antenna to hold the weight of the antenna during installation and
adjustment/tracking for optimization of the signal strength of the radio link.
1.5 DIPOLE FEED:
Dipole Feed having N-Female termination is supplied with the antenna along with feed holder to
mount the dipole feed on center of parabolic reflector using two studs fixed on the center plate.
:
info@antennaexperts.in
INSTALLATION MANUAL – GRID PARABOLIC ANTENNA
6063T6 Aluminum, Military Color Powder Coating finish.
All stainless steel, Military Color Powder Coating finish.
All Marine Grade Stainless Steel.
All Aluminum with Military Color Powder Coating finish.
PTFE (TEFLON).
: www.antennaexperts.in
Website
1300 – 1600 MHz.
19 dBi. Gain
Advertisement
Related Manuals for Antenna Experts AP-145019
Summary of Contents for Antenna Experts AP-145019
- Page 1 Installation, maintenance or dismounting of the grid parabolic antenna system requires qualified and experienced personnel. Antenna Experts Installation instructions have been prepared and are meant for skilled personnel only. Antenna Experts disclaims any liability or responsibility as a result of improper or unsafe installation practices. MATERIALS AND FINISH: Following materials are used for the fabrication of Grid Parabolic Antennas and its accessories.
- Page 2 2. PACKING LIST Sl. No. Item/Description Quantity 01. Parabolic Reflector in assembled condition. 1 Set. 02. Dipole Feed complete with feed holder. 1 Each. 03. Upper Support Arm complete with “U” bolt. 1 Each. 04. Lower Support Arm complete with “U” bolt. 1 Each.
- Page 3 7. INSTALLATION OF LOWER SUPPORT ARM: Initially the upper support arm are supplied and fixed for horizontal polarization. To change the polarization fix the lower support arm at the lower aluminum square mounting blocks that are welded on the support arc, using the supplied fasteners and other set of holes. Tighten the first nut sufficiently to take up free up/down movements of the support, than tighten the second nut against the first.
- Page 4 11. AZIMUTH ADJUSTMENTS: Before attempting the azimuth tracking, make sure that all the locking nuts/bolts and both the “U” bolts hardware of Upper and Lower support arms are fully loose. Rotate the parabolic reflector in desired direction to obtain the maximum signal strength. Please note that the antenna has +/-5.5 degrees half power beam-width so a very fine adjustment is required.
